- Page 1 CDUSB-2 CD/USB/SD PLAYER 2U Item ref: 170.663UK User Manual...
-
Page 2: Package Contents
Damage caused by misuse is not covered by the warranty Introduction Thank you for choosing the CDUSB-2 CD/USB/SD player as part of your playback system. This product has been developed to provide a flexible, high quality audio source for PA, background music and DJ applications. -
Page 3: Front Panel
Front Panel Power Press in to power the unit up Disc drawer Load a CD here (print side up) using the Open/Close button (13) IR receiver Infra red detector for the signal from the remote control Source select Press to switch through CD - USB - SD - CD - USB - SD etc. Multi-function display Illuminated display with track, name, time and status info Vinyl... -
Page 4: Remote Control
Left + Right RCA line output Remote Control The CDUSB-2 is supplied with a handheld infra red remote control. Before use, insert 2 x AAA batteries into the rear compartment, observing the polarity as indicated. Most of the front panel controls are duplicated on the remote control handset. -
Page 5: Operation
Press Play/Pause to initiate playback and use further controls as detailed in the panel layouts above. The CDUSB-2 can be operated either by front panel controls or the supplied handheld IR remote control. Before use, insert the 2 x AAA batteries into the remote control, observing the correct polarity as indicated inside the rear compartment. -
Page 6: Specifications
Specifications Power supply 100-240Vac, 50/60Hz (fig 8) Power consumption Anti-shock 20 seconds Pitch bend Up to ±16% USB input v.2.0 320GB max (500GB max self-powered) SD card slot SD cards up to 8GB Output connection L+R RCA Frequency response 20Hz - 20kHz (±2dB) >90dB <0.1% Channel separation...
