Specifications - Sound Devices MP-1 User Manual And Technical Information

Portable, battery-powered microphone preamplifier with phantom power
Table of Contents

Advertisement

Specifications

Frequency Response:
Gain:
Gain Accuracy:
Equivalent Input Noise:
Output Clipping Level:
Input Clipping Level:
Dynamic Range:
THD + Noise:
Common Mode Rejection Ratio:
Input:
Output:
Low Cut:
Phantom Power:
Limiter:
Internal Voltage Rails:
Power:
Power LED:
Polarity:
Operating Temperature Range:
Dimensions:
Weight: (unit only):
Certification:
20 Hz to 22 kHz, +0.1, -0.5 dB, –1 dB at 50 kHz (relative to 1 kHz level with 150 ohm source)
+1
+0
-1
-2
d
B
-3
u
-4
-5
-6
10
20
50
100
200
500
1k
2k
5k
Hz
0 dB to 66 dB input to output, switch selectable
+0.6, –0.1 dB with reference to front panel gain markings
(150 ohm source, 100k ohm load impedances)
–126 dBu (–128 dBV) minimum
(150 ohm source, flat weighting, 22–22 kHz bandwidth, gain setting 36 dB or greater
+22 dBu minimum with 100k ohm load
+20 dBu minimum with 600 ohm load
+4 dBu minimum at the 0 or +18 dB gain setting
122 dB minimum at the +18 dB gain setting
0.05% maximum (from 50 Hz – 22 kHz @ +4 dBu output level, +46 dB gain setting)
100 dB minimum at 80 Hz
60 dB minimum at 10 Hz
Transformer-balanced, 2000 ohm input impedance
Transformer-balanced, 130 ohm output impedance
80 Hz or 160 Hz (switch selectable), 6 dB per octave
12-volt or 48-volt (switch selectable) per DIN 45 596 specification
Limits to +17 dBu output level 10:1 limiting ratio; 5 mS attack time, 100 mS release time;
Amber/Red LED indicates limiting/clipping
±15 V, regulated
2 AA batteries, 24 hours life typical with +4 dBu signal into 600 ohms, no phantom power.
Green indicates power and good battery. Red indicates power with low batteries. LED turns red when
approximately 4 hours of battery life remain.
Mic input to line output is non-inverting
0° to 70° C 32° to 160° F
43 mm x 94 mm x 140 mm (h x w x d)
(1.7" x 3.7" x 5.55")
0.56 kg, 1.24 lbs (unit only)
0.86 kg, 1.90 lbs (packaged)
Meets FCC Part 15 Class B
Eligible to bear CE mark (see conformance statement)
10k
20k
50k
100k
page 5
