Summary of Contents for Sound Devices MP-1
-
Page 1: Microphone Preamplifier
MP-1 Microphone Preamplifier User Guide and Technical Information Sound Devices, LLC E7556 State Rd. 23/33 Reedsburg, WI 53959 USA Voice +1 (608) 524-0625 Fax +1 (608) 524-0655 www.sounddevices.com ©2001–2007 Sound Devices, LLC... -
Page 2: General Description
With its rugged mechanical and electrical construction, compact size and high-quality components, the MP-1 will provide years of superb audio performance under the most punishing field conditions. Features Audio Performance •... -
Page 3: Specifications
Specifications Frequency Response: 20 Hz to 22 kHz, +0.1, -0.5 dB, –1 dB at 50 kHz (relative to 1 kHz level with 150 ohm source) 100k Gain: 0 dB to 66 dB input to output, switch selectable Gain Accuracy: +0.6, –0.1 dB with reference to front panel gain markings (150 ohm source, 100k ohm load impedances) Equivalent Input Noise: –126 dBu (–128 dBV) minimum... -
Page 4: Front Panel Controls And Indicators
MP-1 Microphone Preamplifier User Guide and Technical Documentation Front Panel Controls and Indicators SOUND DEVICES MP-1 MIC PRE FLAT GAIN (dB) LIMITER POWER 1. LIMITER/Peak LED 4. Rotary Gain Switch Bi-color LED illuminates red at 3 dB below Selects the amount of gain from input to out- PHANTOM clipping;... -
Page 5: Operational Notes
Limiter The MP-1 has a built in peak responding limiter which can be turned on or off by the switch on the front panel. The MP-1 limiter is really two completely separate limiters activated by the one switch; the first limiter keeps the input gain stage from clipping, and the second limiter limits the output to +17 dBu. -
Page 6: Limitation Of Liability
User Guide and Technical Documentation Batteries The MP-1 is designed to operate on two AA alkaline cells for approximately 26 hours with typical sig- nals (without phantom power). The audio performance of the MP-1 does not vary throughout the life of the batteries. -
Page 7: Ce Declaration Of Conformity
Sound Devices, LLC 300 Wengel Drive Reedsburg, WI 53959 USA declares that the product, MP-1 is in conformity with and passes: EMC-product family standard for audio, video, audio-visual and EN55103-1 (1997) entertainment lighting control apparatus for professional use. Part 1:... -
Page 8: Warranty And Technical Support
Sound Devices hosts a user support forum. The URL is: http://forum.sounddevices.com Sound Devices cannot guarantee that a given computer, software, or operating system configuration can be used satisfactorily with the MP-1 Preamplifier based exclusively on the fact that it meets our minimum system requirements. page 10...
