HASE Luno Owner's Manual

Gas fired direct-vent heater installation and operating instructions
Hide thumbs Also See for Luno:
Table of Contents

Advertisement

Quick Links

See also: Instructions for Use Manual
WARNING: FOLLOW THE INFORMATION IN THESE
INSTRUCTIONS EXACTLY, IF NOT, A FIRE OR EXPLOSION
MAY RESULT CAUSING PROPERTY DAMAGE, PERSONAL
INJURY OR LOSS OF LIFE.
WARNING: DO NOT STORE OR USE GASOLINE OR ANY
OTHER FLAMMABLE VAPORS AND LIQUIDS NEAR THIS
OR ANY OTHER GAS APPLIANCE.
WHAT TO DO IF YOU SMELL GAS:
Do not try to light any appliance.
Do not touch electrical switches; do not use the phone in your
building.
Immediately call your gas supplier from a phone outside the
structure. Follow your gas supplier's instructions.
If you cannot reach your gas supplier, call the fire department
or 911.
A qualified installer, service agency, or gas supplier must perform
installation and service of this appliance. In the Commonwealth of
Massachusetts, all installation of gas lines and gas fittings must be
performed by a licensed gas fitter or licensed plumber.
(Model 8160)
Gas Fired Direct-Vent Heater
OWNER'S MANUAL
INSTALLATION AND
OPERATING INSTRUCTIONS
PLEASE READ THIS ENTIRE OWNER'S
MANUAL BEFORE YOU INSTALL AND USE
YOUR NEW LUNO GAS HEATER. SAVE THIS
DOCUMENT FOR FUTURE REFERENCE.
AVERTISSEMENT: ASSUREZ-VOUS DE BIEN SUIVRE LES
INSTRUCTIONS DONNÉ DANS CETTE NOTICE POUR
RÉDUIRE AU MINIMUM LE RISQUE D'INCENDIE OU POUR
ÉVITER TOUT DOMMAGE MATÉERIEL, TOUTE BLESSURE
OU LA MORT.
NE PAS ENTRESPOSER NI UTILISER D'ESSENCE NI
D'AUTRE VAPERURS OU LIQUIDES INFLAMMABLES
DANS LE VOISINAGE DE CET APPRAREIL OU DE TOUT
AUTRE APPAREIL.
QUE FAIRE SI VOUS SENTEZ UNE ODEUR DE GAZ:
Ne pas tenter d'allumer d'appareil.
Ne touchez à aucun interrupteur. Ne pas vous servir des
téléphones se trouvant dans le batiment où vous vous
trouvez.
Appelez immédiatement votre fournisseur de gaz depuis
un voisin. Suivez les instructions du fournisseur.
Si vous ne pouvez rejoindre le fournisseur de gaz, appelez
le service dos incendies.
L'installation et service doit être exécuté par un qualifié installer,
agence de service ou le fournisseur de gaz.
hase - Luno Model 8160
Manual # 6400-40457
Revised: 7/27/2011

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Luno and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for HASE Luno

Summary of Contents for HASE Luno

  • Page 1 INSTALLATION AND OPERATING INSTRUCTIONS PLEASE READ THIS ENTIRE OWNER’S MANUAL BEFORE YOU INSTALL AND USE YOUR NEW LUNO GAS HEATER. SAVE THIS DOCUMENT FOR FUTURE REFERENCE. WARNING: FOLLOW THE INFORMATION IN THESE AVERTISSEMENT: ASSUREZ-VOUS DE BIEN SUIVRE LES INSTRUCTIONS EXACTLY, IF NOT, A FIRE OR EXPLOSION INSTRUCTIONS DONNÉ...
  • Page 2 HearthStone Quality Home Heating Products, Inc. Luno Model #8160 Intentionally Blank...

  • Page 3: Information Sheet

    Address: Phone: E-mail Website: Gas Supplier: Address: Phone: E-mail Website: Read this Owner’s Manual before installing, or operating your Luno. Retain this manual for future reference. SERVICE RECORD Date Who Performed Work Work Performed Notes: WHAT WHEN Firebox Cleaning..... annually Glass Cleaning....

  • Page 4: Table Of Contents

    FIRE LOG PLACEMENT ........................14 LIGHTING THE UNIT FOR THE FIRST TIME ..................15 INITIAL ADJUSTMENTS ........................16 ROUTINE MAINTENANCE AND CARE ....................18 PARTS LIST:............................21 BOLTING YOUR LUNO GAS STOVE TO A PERMANENT STRUCTURE ........21 HIGH ALTITUDE INSTALLATIONS ....................22 TROUBLESHOOTING .........................23 RATING LABEL ...........................26...

  • Page 5: Introduction

    Clearances to with home depressurization. combustibles must be maintained, as specified in the The Luno will provide you with years of practical and “Clearances to Combustibles” section of this manual convenient service. However, as with any gas...

  • Page 6: Specifications

    MINIMUM INLET PRESSURE - (in.w.c./kpa) 5.0/1.24 11.0/2.88 MAXIMUM INLET PRESSURE- (in.w.c./kpa) 7.0/1.74 13.0/3.22 MINIMUM INPUT RATING (btu/hr) 16,000 15,000 MAXIMUM OUTPUT (btu/hr) 0-2000 ft 20,400 20,200 Table 1 - Luno Fuel and Output Specifications Figure 1 – Luno 8160 Dimensions...

  • Page 7: Owner's Information

    317 Stafford Ave. Morrisville, Vermont 05661 ERVICE AUTION If you believe your Luno is in any way, not performing AILY PERATION properly, immediately discontinue operation until the unit is inspected and approved by qualified service The Luno is easily operated by the homeowner once personnel.

  • Page 8: Installer's Information

    * Phillips head screwdriver damaged or incomplete heater. * 7/16-inch wrench * Other parts as required by state or local code The Luno requires a pilot shield. This shield is *Safety Glasses shipped with the unit. Ensure the shield is *Gloves installed over the pilot with the open end to the left (when you are facing the front of the unit).

  • Page 9: Hearth & Floor Protection Requirement

    Use the provided tool to The Luno may be placed directly on a non- apply pressure on the door seal before installing the combustible surface or wood floor. When installing screws (see Figure 2).
  • Page 10 HearthStone Quality Home Heating Products, Inc. Luno Model #8160 Figure 2 – 8160 Clearance to Combustibles Wall pass-through Minimum12" pipe section 2” minimum vent pipe clearance to combustibles. 90 degree elbow Termination Minimum 24" pipe section 1" rear clearance to...
  • Page 11 HearthStone Quality Home Heating Products, Inc. Luno Model #8160 Acceptable Direct-Vent TERMINATION Cap locations. Figure 4: Termination Location & Clearances...

  • Page 12: Venting Information

    HearthStone Quality Home Heating Products, Inc. Luno Model #8160 ENTING NFORMATION ONNECTION 1. The Luno Direct Vent approved installation only with the vent connecting components listed; Simpson Dura-Vent Direct Vent GS, AmeriVent Direct, Selkirk Direct Temp™ or Secure Vent systems. Use the...
  • Page 13 HearthStone Quality Home Heating Products, Inc. Luno Model #8160 NOTE: These positions are based on lab results, and can have some variance. Figure 7: Venting Configurations & Restriction Settings...
  • Page 14 16’ measured from the stove top) Do not vent the Luno jointly with any other solid fuel or gas appliance. Vent the Luno directly to the outside of the building using a proper termination as listed in this manual.

  • Page 15: Electrical Connections

    EMOTE ONTROL HERMOSTAT heating system, or a nearby sunny or drafty window. The Luno 8160 comes equipped with a programmable ON/OFF/Thermostat remote control. Do not place the thermostat transmitter directly We recommend the use of the thermostatic remote behind or too close to the unit, otherwise heat from...

  • Page 16: Gas Supply & Connections

    (figure 10), are not covered by warranty. ONNECTIONS Gas Supply The gas supply connection is made to the Luno’s gas Inlet control valve at the middle, lower rear of the stove, using a 3/8” male NPT fitting.

  • Page 17: Fire Log Placement

    Always wear gloves and safety goggles while handling the log set. Place only the Fire log set supplied with the Luno in the firebox. Do not place any other logs, wood logs, or other materials in the firebox. If the log set is damaged or broken contact your dealer for replacement.

  • Page 18: Lighting The Unit For The First Time

    MOKE AND UMES ARNING When lit for the first time, the Luno will emit some smoke and fumes. This is normal “off-gassing” of the paints and oils used in the manufacturing and assembly of the unit. Open windows to vent the room if necessary. The off gassing and fumes will subside after the first 10 to 20 minutes of operation.

  • Page 19: Initial Adjustments

    NITIAL DJUSTMENTS Once the Luno is set in place, connected and assembled If the pilot will not stay lit after several tries, turn as described in the “Clearances To Combustibles”, the gas control knob “OFF” and call a qualified “Venting...
  • Page 20 The flame on the pilot should look like Figure 10. for at least 10 minutes to allow the entire unit to reach Controlling the Luno by the remote or wall-mounted temperature, and for the flame pattern to stabilize. thermostat may become erratic, nonexistent, or the unit...

  • Page 21: Routine Maintenance And Care

    The Luno requires minimal routine maintenance and care. gasoline, and other flammable vapors and liquids. Check Ensure the Luno is cool and off when being cleaned, or that the flow of combustion and ventilation air is not serviced. Once a year, the unit, and venting system should obstructed.
  • Page 22 HearthStone Quality Home Heating Products, Inc. LUNO 8160 Gas-Fired Direct- Vent The door is held closed with two machine screws, one on the top above the door, and one below the lower right corner of the door. To access these screws you must remove both the top stone and open the lower control access door located just below the front door.
  • Page 23 HearthStone Quality Home Heating Products, Inc. LUNO 8160 Gas-Fired Direct- Vent stove. You can use 240 grit sandpaper to easily repair, or fractures may also appear in the stone after a stove is blend in minor scratches used. Such changes are normal and do not affect the...

  • Page 24: Parts List

    TOVE TO A ERMANENT TRUCTURE When installing the Luno in a mobile home it is required that you attach it to the structure. To do this, we have provided a rear attachment kit with the unit. Locate the 2 steel plates and remove them from the packaging.

  • Page 25: High Altitude Installations

    HearthStone Quality Home Heating Products, Inc. LUNO 8160 Gas-Fired Direct- Vent LTITUDE NSTALLATIONS For installations from 610-1370 meters altitude (2000- 4500ft) the orifice sizes (DMS) should be 38 for NG and 53 for LP. See the rating label for more information. For...

  • Page 26: Troubleshooting

    HearthStone Quality Home Heating Products, Inc. LUNO 8160 Gas-Fired Direct- Vent ROUBLESHOOTING Symptom Possible Cause Corrective Action 1. Pilot will not light. A. Insufficient gas pressure, air in A. Using the piezo sparker, try to light the pilot. If it the pilot line, or dirty or kinked will not light, check the inlet gas pressure.

  • Page 27: Troubleshooting

    A. Flames should begin to turn more yellowish after 20 minutes. about 20 minutes of burning. B. If the blue color persists; adjust the air shutter for a proper burn. hase - Luno Model 8160 Manual # 6400-40457 Revised: 7/27/2011...
  • Page 28 HearthStone Quality Home Heating Products, Inc. LUNO 8160 Gas-Fired Direct- Vent Troubleshooting Symptom Possible Cause Corrective Action A. Potentially dangerous A. Check the appliance input rate and reduce if 8. Floating flames, incomplete combustion due to necessary. The air intake/exhaust flow system may...

  • Page 29: Rating Label

    HearthStone Quality Home Heating Products, Inc. LUNO 8160 Gas-Fired Direct- Vent ATING ABEL...
  • Page 30 HearthStone Quality Home Heating Products, Inc. LUNO 8160 Gas-Fired Direct- Vent Qualifying for warranty coverage To obtain performance of any obligation under this document, the Original Purchaser must, within the applicable warranty time period, contact their dealer, or Hearthstone at the address below, for instructions regarding the return of defective parts for repair, the return of the Stove for repair, or a Dealer service call.
  • Page 31 NOTES:...
