INSTALLER: Leave this manual with party responsible for use and operation.
OwNER: Retain this manual for future reference.
Call your dealer for questions on Installation, Operation, or Service.
NOTICE: DO NOT discard this manual!
Model(s):
Hot Air Furnace: SF1500A & SF2500A
"Ce manuel est disponible en Français sur demande"
PLEASE READ THIS ENTIRE MANUAL BEFORE YOU INSTALL AND/OR USE YOUR NEw BOILER. FAILURE TO
FOLLOw INSTRUCTIONS MAY RESULT IN PROPERTY DAMAGE, BODILY INJURY, OR EVEN DEATH.
IF THIS HARMAN BOILER IS NOT PROPERLY INSTALLED, A HOUSE FIRE MAY RESULT. FOR YOUR SAFETY,
FOLLOw INSTALLATION DIRECTIONS.
CONTACT LOCAL BUILDING OR FIRE OFFICIALS ABOUT RESTRICTIONS AND INSTALLATION INSPECTION
REQUIREMENTS IN YOUR AREA.
CONTACT YOUR LOCAL AUTHORITY (SUCH AS MUNICIPAL BUILDING DEPARTMENT, FIRE DEPARTMENT, FIRE
PREVENTION BUREAU, ETC.) TO DETERMINE THE NEED FOR A PERMIT.
Installation & Operating Manual
SAFETY NOTICE
SAVE THESE INSTRUCTIONS
Please read this entire manual before
installation and/or use your new boiler.
Failure to follow these instructions could
result in property damage, bodily injury
or even death.
• Do not store or use gasoline or other flammable vapors
and liquids in the vicinity of this or any other appliance.
• Do not overfire - If any external part starts to glow, you
are overfiring. Reduce feed rate. Overfiring will void
your warranty.
• Comply with all minimum clearances to combustibles
as specified. Failure to comply may cause house fire.
Safety Notice
IF THIS HARMAN BOILER IS NOT PROPERLY
INSTALLED, A HOUSE FIRE MAY RESULT. FOR YOUR
SAFETY, FOLLOw INSTALLATION DIRECTIONS.
!
Tested and approved for solid-fuel only (wood, coal).
Burning of any other type of fuel voids your warranty.
!
Check building codes prior to installation.
• Installation MUST comply with local, regional, state and
national codes and regulations.
• Contact local building or fire officials about restrictions
and installation inspection requirements in your area.
wARNING
CAUTION
CAUTION
3-90-70744R13_11/13
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Harman SF1500A
Summary of Contents for Harman SF1500A
- Page 1 PLEASE READ THIS ENTIRE MANUAL BEFORE YOU INSTALL AND/OR USE YOUR NEw BOILER. FAILURE TO FOLLOw INSTRUCTIONS MAY RESULT IN PROPERTY DAMAGE, BODILY INJURY, OR EVEN DEATH. IF THIS HARMAN BOILER IS NOT PROPERLY INSTALLED, A HOUSE FIRE MAY RESULT. FOR YOUR SAFETY, FOLLOw INSTALLATION DIRECTIONS.
-
Page 2: Table Of Contents
Table of Contents Harman® Central Heating Appliances are built and Packing List tested to be complete Home Heating solutions. As with any Central Heat system, a backup heating system may Installation be required in the event of power outages or during appliance service or maintenance. -
Page 3: Packing List
Packing List for SF1500 & SF2500 Automatic Draft Control Blower - (Sold Separately) (2) Blower Brackets - (Included with blower) Filter Box Kit (3 pieces) + Filter Fan Control / High Limit 3-Speed Fan Switch Thermostat Junction Box Relay (4) 1/4 X 3/4 bolts & (4) Filter Box Mounting Clips 36” Flex Conduit Filter (1) Straight Conduit Fitting (1) Elbow Conduit Fitting Filter Box Kit Ash Pan Shaker Handle Filter Box Owner’s Manual Mounting Clips Warranty Registration Blower Flex Conduit & Fittings Automatic Draft Control Blower Brackets Fan Control / High Limit 3-Speed Fan Switch... -
Page 4: Installation
Installation To ensure a safe installation, it is recommended that this furnace be installed by a qualified installer. The sheet metal top and sides can be easily removed to reduce the chance of dents or scratches on the painted surfaces. To remove the sheet metal, first lift off the top section. Now, the sides can be removed by lifting up and out away from the furnace. Caution: This furnace must not be installed closer than 24 inches at the sides and 30 inches from the rear to combustible materials. - Page 5 Installation Venting Guidelines. Bolt the automatic draft control to the Your Harman hot-air furnace must be vented to it’s own bottom door. Be sure separate flue-lined “Class A” chimney, not less than 8” X 8” to hold the unit straight in size. The chimney must be capable of providing a draft while tightening. After reading of at least .06” water column on a draft meter, in the automatic draft order to function properly. The Chimney must be a minimum...
-
Page 6: Mounting Blower & Filter Box
Installation Mounting The Blower And Filter Box Position the filter box between the brackets on the rear of the furnace, with the bottom of the box resting on the flange at the bottom of the furnace. Insert the mounting clips into the bracket slots to secure the filter box. (see Figure 2) Next, install the blower brackets onto the blower being sure to install the rubber feet into the brackets. All hardware, brackets, etc. for the blower, will be found in the carton with the blower. Next, position the blower in the filter box, centered behind the inlet hole and allow approximately 1/8 in. space between the rear of the furnace and the blower outlet. Now, install the filter rail onto the filter box. NOTE: The filter rail is best installed on the side toward the shaker handle, so that any pipes from the hot water coil do not interfere with filter installation or removal. NOTE: Before proceeding with the installation of the access door, it is suggested that the wiring be completed. The access door is installed by slipping the flange on the bottom of the access door over the bottom rail of the filter box opening, then push the top of the door against the top of the filter box opening and secure with a sheet metal screw. Filter box mounting clips 1/8 in. space between blower and furnace Figure 2 3-90-70744R13_11/13... -
Page 7: Wiring
Installation - wiring wiring Before beginning any wiring, study the appropriate wiring diagram for your unit. Also refer back to figures C or D for an example of what the completed job will look like. It is your responsibility to follow all state and local electrical codes. Locate the best place to route the power for the blower, and drill a 7/8” hole in the filter box. This hole size will accommodate a “romex” connector. Attach the blower and power wires as shown on the appropriate wiring diagram. Once you have the plenum installed, the fan control with high limit switch can be installed. The Fan control/high limit switch is packaged with a jumper between the two sets of terminals inside. REMOVE THE JUMPER WIRE INSIDE THE FAN CONTROL. The fan control should be installed in the right side of the plenum and 12 to 18 inches above the top of the furnace. A separate conduit should be run from the fan control to the junction box. Mount the thermostat in a central location of the area you want to heat. Run two wires to the junction box, from the heating terminals on the thermostat. 22 gauge or thicker wire is acceptable. -
Page 8: Duct Work
Duct work and Operating Instructions Duct work. This figure shows a typical duct system layout. Be sure the entire system is properly sized to provide the correct static pressure for optimum Return Air blower performance. Have any new duct Supply Trunk system designed by a HVAC professional. Operating Instructions Adjusting Automatic Draft Control - In order Plenum for your new furnace to function, the controls must be properly adjusted. The heat output is regulated by the automatic draft control, on the bottom door of the furnace. Refer to the illustrations at right; The electric draft motor... -
Page 9: Operation
Loading - Coal should never be added unless there is always closing the bottom door before open i ng the top door. a reasonably hot fire. The coal bed should be bright and Now load the firebox with wood to the desired fullness. All vigorous. If the fire is burning hot and there is a deep bed of Harman furnaces may be loaded with wood as full as possible coals, full loads of coal can be added at any time. However, for high output and long burn time. Then close the door and if there is not a deep bed of coals, it is best to add small allow all the wood to catch fire. The bottom door may again be amounts of coal at first. -
Page 10: Safety Tips
Operating Instructions/Safety Tips The amount of shaking is critical. Too much will disrupt the With the exception of start up or increasing heat from a low fire bed and too little will restrict the air flow. fire, or re m oving ashes, the bottom door should be kept closed. Never install a Harman furnace to a chimney with a The proper amount normally occurs when red coals first start history of down drafts. to drop through the grates into the ash pan. KEEP CHILDREN AwAY - MAY CAUSE SERIOUS BURNS. Ashes - Ashes should never be allowed to accumulate in the ash pit so that they in any way impede the flow of com b ustion CAUTION air to the fire. Excess ash ac c umulation can cause the fire to go out and also can cause severe damage to the grates because of the absence of a cooling flow of air beneath them. -
Page 11: Maintenance
Maintenance The spiral chamber is basically self-cleaning. However, if there is a draft problem and you have been burning wood for a long time with little heat demand, the spiral chamber may need cleaning. Soft coal will also require more frequent cleaning. To clean, remove stovepipe and scrape the creosote from the front and top of the chamber and remove. The rear of the chamber will not accumu l ate creosote. NOTE: 1/8” to 1/4” of creosote in the spiral chamber is normal. Creosote can be burned off by burning coal for a few days. Firebricks may become cracked during the course of normal operation. A cracked brick that is still in place is still doing its job and need not be re p laced immediately. If a brick is broken and has fallen out of place, it should be replaced immediately. The firebrick used in the Harman furnaces are inexpensive and easy to replace. The blower manufacturer recom m ends the blower motor to be oiled once a year with 10 to 20 drops of light weight oil [check instructions packed in blower box). 3-90-70744R13_11/13... -
Page 12: Specifications
Specifications SF1500 SF2500 Complete Complete Heating Capacity- square ft. 2200 3200 Approximate BTU Input 90,000 120,000 Blower Size 1000 cfm 1000 cfm Automatic Draft Standard Standard Filter Box & Filter Standard Standard 3-Speed Fan Switch Standard Standard Fan Control / High Limit Standard Standard Thermostat... -
Page 13: Coil Installation
Special Instructions Coil Installation: Hot Water Out Cold Water In Temp / Pressure Automatic Relief Valve Air Valve Pressure Relief Valve (Must be within 2 feet of coil) Rear of Furnace 10 Feet Maximum Drain Valve Existing Water Heater Plumbing Diagram For Thermo-Siphon Method - Maximum Distance = 10 Feet Place one of the supplied nuts on each leg of the coil. Place the coil through the holes on the back of the furnace, and adjust the nuts so that the pipes stick out about 1¼ to 1½ inches from the rear of the furnace. Place the flat washers and gaskets over each pipe and tighten the nuts. You are now ready to run the piping. - Page 14 Special Instructions Hot Water Out Cold Water In Pressure Automatic Aquastat, close on rise. Relief Valve Air Valve Optional Pressure Relief Valve (Must be within 2 feet of coil) Drain Optional Gate Valve Valve to Control Rate of Flow Circulator Pump Distance Between Units = 10 Feet or More Circulating Pump Method - Distance = 10 Feet or More This method is used when the water heater tank is more than ten feet away from the furnace or the furnace is on a higher...
-
Page 15: Service Parts
SF1500A Service Parts wood/Coal Hot Air Furnace Beginning Manufacturing Date: N/A Ending Manufacturing Date: Active 1-70-03232 IMPORTANT: THIS IS DATED INFORMATION . Parts must be ordered from a dealer or Stocked Hearth and Home Technologies does not sell directly to consumers distributor. - Page 16 SF1500A Service Parts Beginning Manufacturing Date: N/A Ending Manufacturing Date: Active IMPORTANT: THIS IS DATED INFORMATION . Parts must be ordered from a dealer or Stocked Hearth and Home Technologies does not sell directly to consumers distributor. . Provide model number and serial number when requesting service parts from your dealer or distributor. at Depot...
- Page 17 SF2500A Service Parts wood/Coal Hot Air Furnace Beginning Manufacturing Date: N/A Ending Manufacturing Date: Active 1-70-03235 IMPORTANT: THIS IS DATED INFORMATION . Parts must be ordered from a dealer or Stocked Hearth and Home Technologies does not sell directly to consumers distributor.
- Page 18 SF2500A Service Parts Beginning Manufacturing Date: N/A Ending Manufacturing Date: Active IMPORTANT: THIS IS DATED INFORMATION . Parts must be ordered from a dealer or Stocked Hearth and Home Technologies does not sell directly to consumers distributor. . Provide model number and serial number when requesting service parts from your dealer or distributor. at Depot ITEM DESCRIPTION COMMENTS...
-
Page 19: Warranty
warranty Hearth & Home Technologies LIMITED LIFETIME wARRANTY Hearth & Home Technologies, on behalf of its hearth brands (”HHT”), extends the following warranty for HHT gas, wood, pellet, coal and electric hearth appliances that are purchased from an HHT authorized dealer. wARRANTY COVERAGE: HHT warrants to the original owner of the HHT appliance at the site of installation, and to any transferee taking ownership of the appliance at the site of installation within two years following the date of original purchase, that the HHT appliance will be free from defects in materials and workmanship at the time of manufacture. After installation, if covered compo- nents manufactured by HHT are found to be defective in materials or workmanship during the applicable warranty period, HHT will, at its option, repair or replace the covered components. HHT, at its own discretion, may fully discharge all of its obligations under such warranties by replacing the product itself or refunding the verified purchase price of the product itself. The maximum amount recoverable under this warranty is limited to the purchase price of the product. This warranty is subject to conditions, exclusions and limitations as described below. wARRANTY PERIOD: Warranty coverage begins on the date of original purchase. In the case of new home construction, warranty coverage begins on the date of first occupancy of the dwelling or six months after the sale of the product by an independent, authorized HHT dealer/ distributor, whichever occurs earlier. The warranty shall commence no later than 24 months following the date of product shipment from HHT, regardless of the installation or occupancy date. The warranty period for parts and labor for covered components is produced in the following table. The term “Limited Lifetime” in the table below is defined as: 20 years from the beginning date of warranty coverage for gas appliances, and 10 years from the beginning date of warranty coverage for wood, pellet, and coal appliances. These time periods reflect the minimum expected useful lives of the designated components under normal operating conditions. Warranty Period HHT Manufactured Appliances and Venting Components Covered Parts Labor Wood Pellet Coal Electric Venting Wood All parts and material except as covered by Conditions,... - Page 20 warranty wARRANTY CONDITIONS: • This warranty only covers HHT appliances that are purchased through an HHT authorized dealer or distributor. A list of HHT authorized dealers is available on the HHT branded websites. • This warranty is only valid while the HHT appliance remains at the site of original installation. • This warranty is only valid in the country in which the HHT authorized dealer or distributor that sold the appliance resides. • Contact your installing dealer for warranty service. If the installing dealer is unable to provide necessary parts, contact the nearest HHT authorized dealer or supplier. Additional service fees may apply if you are seeking warranty service from a dealer other than the dealer from whom you originally purchased the product. • Check with your dealer in advance for any costs to you when arranging a warranty call. Travel and shipping charges for parts are not covered by this warranty. wARRANTY EXCLUSIONS: This warranty does not cover the following: • Changes in surface finishes as a result of normal use. As a heating appliance, some changes in color of interior and exterior surface finishes may occur. This is not a flaw and is not covered under warranty. • Damage to printed, plated, or enameled surfaces caused by fingerprints, accidents, misuse, scratches, melted items, or other external sources and residues left on the plated surfaces from the use of abrasive cleaners or polishes. • Repair or replacement of parts that are subject to normal wear and tear during the warranty period. These parts include: paint, wood, pellet and coal gaskets, firebricks, grates, flame guides, batteries and the discoloration of glass. • Minor expansion, contraction, or movement of certain parts causing noise. These conditions are normal and com- plaints related to this noise are not covered by this warranty. • Damages resulting from: (1) failure to install, operate, or maintain the appliance in accordance with the installation instructions, operating instructions, and listing agent identification label furnished with the appliance; (2) failure to install the appliance in accordance with local building codes; (3) shipping or improper handling; (4) improper opera- tion, abuse, misuse, continued operation with damaged, corroded or failed components, accident, or improperly/ incorrectly performed repairs; (5) environmental conditions, inadequate ventilation, negative pressure, or drafting caused by tightly sealed constructions, insufficient make-up air supply, or handling devices such as exhaust fans or forced air furnaces or other such causes; (6) use of fuels other than those specified in the operating instructions; (7) installation or use of components not supplied with the appliance or any other components not expressly authorized and approved by HHT; (8) modification of the appliance not expressly authorized and approved by HHT in writing;...
- Page 21 3-90-70744R13_11/13...
- Page 22 At Harman, we build each product to a standard, not a price. (Signature of Boxer) Your premium quality hearth product designed and assembled by the experienced and skilled members at Harman in Halifax, PA, USA. Proudly Printed On 100% Recycled Paper...
