00326A SCC-931T(P)-eng 9/25/02 12:30 PM Page 2 Important Safety Instructions Read these instructions. This symbol indicates high voltage CAUTION Keep these instructions. is present inside. It is dangerous RISK OF ELECTRIC to make any kind of contact with Heed all warnings. SHOCK DO NOT OPEN any inside part of this product.
00326A SCC-931T(P)-eng 9/25/02 12:30 PM Page 4 Table of Contents Chapter 1 Chapter 1 SCC-931T(P) Overview SCC-931T(P) Introduction SCC-931T(P) Overview SCC-931T(P) Part Names and Functions Chapter 2 Installing SCC-931T(P) Checking the Contents of the Package Precautions for Installation and Use This chapter briefly introduces the SCC-931T(P) and Preparing Cables describes its key features, part names and functions.
00326A SCC-931T(P)-eng 9/25/02 12:30 PM Page 6 SCC-931T(P) Introduction SCC-931T(P) Part Names and Functions The SCC-931T(P) Anti-Vandal Dome Camera is a dome-typed surveillance Front View device that offers the best features of surveillance for banks, retail stores, commercial buildings, industrial settings, and etc. It is designed to with- stand intentional or accidental impact or vandalism, and is waterproof, dustproof, and shockproof.
00326A SCC-931T(P)-eng 9/25/02 12:30 PM Page 8 SCC-931T(P) Part Names and Functions Chapter 2 Camera Operation Switches (Setup Switches) The functions of the camera operation switches change depending on whether Installing SCC-931T(P) the SCC-931T(P) is currently in the usual operation mode (i.e., the setup menu is not showing on the screen) or the setup menu mode.
00326A SCC-931T(P)-eng 9/25/02 12:30 PM Page 10 Before Installation Checking the Contents of the Package PLASTIC ANCHOR 2 ea. ❙ ❙ for ceiling installation Be sure to check that the following items are included in the package. ASSY SCREW TAPPING 2 ea. ❙ ❙ for ceiling installation (TH M4 X L30 BLK + 0 RING) ASSY SCREW MACHINE 2 ea.
00326A SCC-931T(P)-eng 9/25/02 12:30 PM Page 12 Before Installation Precautions for Installation and Use SCC-931T(P) - Installation Examples Please check whether the installation site can sufficiently support the weight of It can be directly installed on ceilings. the SCC-931T(P) before installation. It can be directly installed on pipes coming down from the ceiling.
00326A SCC-931T(P)-eng 9/25/02 12:30 PM Page 14 Preparing Cables Installing SCC-931T(P) The following cables are required to install and use the SCC-931T(P). For installing directly on a ceiling 1. Choose an installation site that can sufficiently support the weight of the equip- Power Adapter Cable Video Cable ments to be installed.
00326A SCC-931T(P)-eng 9/25/02 12:30 PM Page 16 Installing SCC-931T(P) For installing on a pipe 6. Adjust the LENS direction. 1. Choose an installation site that can sufficiently sup 1) Turn the STOPPER RING counter-clockwise as shown in the port the weight of the equipments to be installed. illustration to move the LENS body and COVER LENS.
Page 10
00326A SCC-931T(P)-eng 9/25/02 12:30 PM Page 18 Installing SCC-931T(P) 5) Remove the CAMERA body from the CASE. 6. Remove the DOME COVER to adjust the LENS (Completely separate the power cable from the direction. video cable.) 1) Use the supplied L WRENCH to unfasten the 4 6) Disconnect the power and video cables from the BOLTS for CASE fixing by turning them counter- PCB and arrange them so that they can be passed through the PIPE...
Page 11
00326A SCC-931T(P)-eng 9/25/02 12:30 PM Page 20 Installing SCC-931T(P) 7) Route the cables through the PIPE assembly hole on the side of the PIPE, 9) After arranging the connected power align the INDEX KEY arrow mark ( ) of the CAMERA body to the groove cable and video cable inside the PIPE on the CAMERA, mount the CAMERA body and turn it clockwise all the way and then pulling them out, put together...
00326A SCC-931T(P)-eng 9/25/02 12:30 PM Page 22 Connecting Cables and Checking Operations 4. Decide on the type of power source you want to use and then adjust the power 1. First connect one end of the BNC cable to the VIDEO OUT. selection switch located at the bottom of the power adapter.
00326A SCC-931T(P)-eng 9/25/02 12:30 PM Page 24 Structure of the Setup Menu CAMERA ID SETUP ON... CAMERA ID Chapter 3 CAMERA ID ON.../OFF POSITION SETUP ALC... IRIS AREA SETUP Setup Menu Overview ALC.../MANU... BLC SETUP LEVEL SETUP AUTOFOCUS AF/ONEAF/MF LEVEL SETUP MENU...
00326A SCC-931T(P)-eng 9/25/02 12:30 PM Page 26 CAMERA MENU Organization ALC (Auto Light Control) CAMERA ID If you set the IRIS to ALC and press the [ENTER] key, a submenu screen where In the CAMERA ID menu, you can assign an ID to the SCC-931T(P) that appears on you can set the video output level and BLC will be displayed.
00326A SCC-931T(P)-eng 9/25/02 12:30 PM Page 28 CAMERA MENU Organization SIZE SIZE AUTO FOCUS In the AUTO FOCUS menu, you can specify the Focus method. You can set the Focus to ONEAF, AF, or MF. Using the [LEFT, RIGHT, TOP, AF (Auto Focus) BOTTOM] keys POSITION...
00326A SCC-931T(P)-eng 9/25/02 12:30 PM Page 30 CAMERA MENU Organization SHUTTER AGC/MOTION In the SHUTTER menu, you can specify the speeds of the high-speed electronic AGC (Auto Gain Control) shutter, AUTO low-speed shutter, and FIX low-speed shutter. You can specify whether to control the AGC GAIN when the obtained video is The high-speed electronic shutter supports 7 shutter speeds from 1/100 seconds to below a certain level of brightness because it was recorded under insufficient 1/10K seconds, and the AUTO low-speed shutter and the FIX low-speed shutter...
00326A SCC-931T(P)-eng 9/25/02 12:30 PM Page 32 CAMERA MENU Organization When the SHUTTER is set to the low illumination mode in the setup MEUN, use the UP/DOWN keys to position the cursor to the MOTION and use the [LEFT/RIGHT] keys to execute the MOTION function. Use the LEFT key move toward the SLOW, the RIGHT key to move toward the Set the WHITE BAL menu to ATW.
00326A SCC-931T(P)-eng 9/25/02 12:30 PM Page 34 CAMERA MENU Organization CTRL TYPE SYNC This function is not used on the SCC-931T(P). RS485 Select INT when using the interal synchronization. LINE... is necessary when syn- Select the Baud Rate (4800, 9600, 19200, or 38400 bps) and Camera Address chronizing the camera phases to operate multiple cameras by using the external (0~255) for RS485 communication.
Page 19
00326A SCC-931T(P)-eng 9/25/02 12:30 PM Page 36 CAMERA MENU Organization You can store up to 10 Zoom and Focus positions with the PRESET. The PRESET CAMERA ID OFF... CTRL TYPE function can be used when you connect the SSC-1000(Controller[Sold Separately]) IRIS ALC...
00326A SCC-931T(P)-eng 9/25/02 12:30 PM Page 38 CAMERA MENU Organization MOTION DET You can move the cursor to the SENSITIVITY position and use the [LEFT/RIGHT] You can set the MOTION detection sensitivity and the MOTION detection area. keys to set the sensitivity for MOTION detection (LOW, MEDIUM, HIGH). The MOTION DET fuction detects moving objects and can be used to detect After setting the position in the same way you did with BLC AREA, press the intruders’...
00326A SCC-931T(P)-eng 9/25/02 12:30 PM Page 40 External Connector Pin Specifications SCC-931T(P) - Product Specifications CN 753 : Camera Power Input and Video Signal Output ITEM DESCRIPTION Product Type Anti-Vandal Dome Camera Pin No Pin Specifications Power Source Voltage AC 24V ± 10% (NTSC:60Hz ± 0.1Hz, PAL:50Hz ± 0.1Hz), DC12V +10% ~ -5% Video Signal Output Power Consumption...
Page 22
00326A SCC-931T(P)-eng 9/25/02 12:30 PM Page 42 SCC-931T(P) - Product Specifications ITEM DESCRIPTION Back Light Compensation Off/On (Area Setting) Sense Up Off/Auto 2x~28x/Fix 2x~128x Digital Zoom Off/On(x10), PIP Motion Detection Off/On (Area/Sensitivity Setting) Video Control POSI/NEGA, MIRROR, Detail Setting Signal Output Composite Video Out : 1.0 Vp-p 75 ohms/BNC Lens Focal length : 3.6 ~ 43.2 mm...
