Axis Thermal Camera Accessories and Spare Parts Installation Guide
Accessories and Spare Parts
This Installation Guide provides instructions for installing and replacing accessories and spare parts
for AXIS Q1921/-E/Q1922/-E, including AXIS T92E23/T92E24 Thermal Camera Housing.
To install the camera on the network, please see the Installation Guide provided with the camera.
For other details about the camera, see the User Manual, available from www.axis.com

Installation steps

1. Check the package contents against the list below.
2. Hardware overview. See page 6.
3a. Replace the lens. See page 8.
3b. Install the housing. See page 11.
3c. Replace the protective window. See page 13.

Package contents

The package contents vary depending on accessories and spare parts.
Item Models/variants/notes
Lens 10 mm/19 mm/35 mm/60 mm
Housing AXIS T92E23/T92E24 Thermal Camera Housing
Wall bracket
Torx T20 screwdriver
Allen key
Camera screw and washer
Front kit Front panel
Frame with premounted protective window and window heater cable
Front panel screw (4x)
Printed materials Axis Thermal Camera Accessories and Spare Parts Installation Guide (this document)
Drill template
Axis Warranty document
Axis Thermal Camera

Installation Guide

Page 5
