  • Page 1 IPC2 Full HD IP Bodied Camera User Manual...

  • Page 2: Safety Information

    Safety Information CAUTION RISK OF ELECTRIC SHOCK. DO NOT OPEN. CAUTION : TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK) NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. Precaution Precaution This exclamation point symbol is This exclamation point symbol is intended to alert the user to the intended to alert the user to the...

  • Page 3: Important Safety Instructions

    Important Safety Instructions 1. Read these instructions - All safety and operating instructions should be read before the product is installed or operated. 2. Keep these instructions - The safety, operating and user instructions should be retained for future reference. 3.

  • Page 4: Product And Accessories

    Introduction - Product & Accessories Please check if camera and accessories are all included in the product package. Camera C-Mount Adaptor Camera Holder Mount Camera Holder Manual CD Quick Manual Screw-2pcs NOTE : The C-Lens and CS-Lens are not included in the product package. C-Lens and CS-Lens is optional.

  • Page 5: Part Name

    Introduction - Part Name Micro SD Memory Card Slot Covers the inner cover, lens, and main body to protect them. Power Indicator When the power turns on, the indicator will light on. RJ-45 Connector Used to connect a PoE or LAN cable. Used for earth-grounding.

  • Page 6: Specification

    Introduction - Specification Model Number IPC2 Image Sensor 1/2.8” 2MP CMOS Resolution Colour: 0.5 Lux Minimum Illumination B&W: 0.01 Lux Day / Night AUTO / DAY / NIGHT Focus Manual Shutter Speed 1/25 ~ 1/30,000 Sec Sensor I/O 1 Input / 1 Output Video Output BNC: VBS 1.0 Vp-p...

  • Page 7: Installation

    Installation - Installation Disconnect the power before proceeding. Mounting the Lens CS-Lens: Turn the optional CS-Lens clockwise to insert it. C-Lens: Turn the C mount adaptor clockwise to insert it and do the same with the C-Lens. CS-Lens C-Lens Fix the Camera Holder By tightening two camera holde screws provided, attach the camera holder on the camera.
  • Page 8 Installation - Installation Connection Lens Connector Connect the lens control cable to the lens connector. Connecting Cables Connect the power, video, audio, alarm and network cables respectively. See the section ‘Installation - Cabling’ for detail. Lens Connector Adjusting Zoom and Focus By turning screws of the lens, adjust the Zoom and Focus after setting the position and view angle of camera.
  • Page 9 Installation - Cabling Network Connection Connect the crossover cable into the RS-45. Video Output(BNC Cable) The BNC cable is used to connect to a monitoring display. Power Connection Please, check the voltage and current capacity of rated Network power carefully. Connection Rate Power Current Consumption...

  • Page 10: Inserting/Removing An Sd Memory Card

    Installation - Inserting/Removing an SD Memory Card The memory card is an external data storage device that has been developed to offer an entirely new way to record and share video, audio, and text data using digital devices. Micro Recommended SD Card Specification (Not Included) - Type: Micro SD (SDHC) - Manufacturer: Transcend, Kingston, Toshiba, Sanddisk...

  • Page 11: Network Setup

    Network Setup - IP Installer 1. Run IP Installer Manual CD > Software > Run ‘IP Installer.exe’ If you run the program, it will automatically search all IP cameras connected to the current PC within LAN. If you click one of the lists, corresponding information on IP and port setting will be shown on the right.
  • Page 12 Network Setup - IP Installer Port Setting: Configure Port Setting. 2. IP Installer details Search: IP installer searches and lists all IP You don’t need to change the setting when connected to IP cameras connected to the current PC within camera via IP router or within LAN.

  • Page 13: Quick Start Of Network Connection

    Network Setup - Quick Start of Network Connection Please follow the steps below to complete Configure the IP Camera’s TCP/IP settings as you normally do any other PCs on your network by providing a proper IP the initial setup of the network function. address, subnet mask, default gateway, and DNS server.

  • Page 14: Initial Setup Via A Crossover Cable

    Network Setup - Initial Setup via a Crossover Cable This section provides a guide on how to Now you will be able to access the viewer software within the IP Camera. connect the IP Camera to your PC/Laptop for initial setup. Open Internet Explorer and type the IP address of 192.168.1.80 (default IP of the IP Camera from the factory) into the Address Bar Please follow the instructions in the order...

  • Page 15: Ddns Registration

    Network Setup - DDNS Registration If you have DYNAMIC IP service from your Internet Service Provider (ISP), you can’t tell the current IP address of the IP Camera. To solve this problem, you have to register to our DDNS service. At first, you have to check if you are using dynamic addressing.

  • Page 16: Guide To Network Environment

    Network Setup - Guide to Network Environment Please configure the IP Camera at the 5. The following descriptions are several basic network scenarios. Determine which scenario describes your network. installation site. You must determine your If your network does not match one of the scenarios below network scenario in order to configure the IP and you are unsure how to setup your IP Camera, contact Camera with the proper TCP/IP settings.
  • Page 17 Network Setup - Setup Case A, B Configure your IP Camera's TCP/IP properties Case A: as follows : Dynamic IP + Personal Router [Most SOHO] Network Type : STATIC (even though you have Dynamic IP from your ISP, use STATIC on the IP Camera) Camera Internet Address : A private IP address such as...
  • Page 18 Network Setup - Setup Case C, D Case C: Case D: Static(Fixed) IP [Dedicated line directly Dynamic IP + DSL/Cable Modem [Connected to the IP Camera] directly to the IP Camera] Camera Camera Phone Line or CATV Cable/xDSL Modem (ISP Provided) Public Line Gateway or Router at ISP...

  • Page 19: Port Forwarding

    Network Setup - Port Forwarding After entering the correct TCP/IP settings, you are ready for ‘Port Forwarding’(Cases A, B). Please record the TCP/IP settings of your IP Camera for future reference. You may need this information to access your IP Camera and to configure ‘Port Forwarding’...
  • Page 20 Network Setup - Starting IP Camera After forwarding correctly the Web Port, Video Port, Control Port and two Audio Ports through your router (if applicable), install the IP Camera in a proper location. Locate the serial number located on the label attached to the bottom of the IP Camera, you will need this for DDNS registration.

  • Page 21: Web Viewer Screen

    Web Viewer Screen - Basic Screen Web viewer is optimized with Windows XP or above version Control tab button. Click it to extend the panel to control and explorer browser. the function of web-viewer. See the next page for detail. Live video display.

  • Page 22: Control Tab

    Web Viewer Screen - Control Tab When the image goes unsmoothly because of bad network connection, it stored image during setup time and shows the image on the live view screen. User will see the delayed images as much as setup time. Video stream button.
  • Page 23 Web Viewer Screen - Control Tab Speaker Control. Enable/Disable Audio stream received from the camera and Volume control of the speaker in the computer. Mic Control. Enable/Disable the Audio stream to the camera. Motion Detection. Enable or Disable motion detection function.

  • Page 24: Camera Setup

    Camera Setup - Camera Setup 1 (1M Camera Only) Bright 0 ~ 9 (10 Steps, Default: 4) Contrast 0 ~ 9 (10 Steps, Default: 4) Saturation 0 ~ 9 (10 Steps, Default: 4) Sharpness 0 ~ 9 (10 Steps, Default: 4) White Balance Mode Auto / Indoor / Outdoor Auto: The camera performs white balance automatically.
  • Page 25 Camera Setup - Camera Setup 2 (2M Camera Only) Flickerless(Read Only) Day & Night Auto: In this mode, the IR cut filter is removed automatically depending on the light condition around. Day: In this mode, the IR cut filter is applied to the image sensor all the time.

  • Page 26: Video Setup

    Setup - Video Setup Live Video Channel Setup Resolution Setup the multiple codec and Video according to the Select the video resolution. environment of installed camera. Using selected channel Available resolution can be depends on the codec setup between on the ‘Web-Viewer > Control Tab > Video Format’. the channels.
  • Page 27 Setup - Video Setup Bitrate Mode GOP(Group of Pictures) Size Select the bit rate control scheme of video compression Set up the number of frames (P-frame) which contain only from CBR (Constant Bit Rate) or VBR (Variable Bit Rate). changed information based on basic frame (I-frame). Regarding videos with lots of movement, if you set GOP size bigger, only the number of P-frames is bigger.

  • Page 28: Audio Setup

    Setup - Audio Setup Input Gain Adjust the input gain of audio. Output Gain Adjust the output gain of audio. Output gain 0 is mute. Click ‘Apply’ to make above setting effective.

  • Page 29: Tcp/Ip Setup

    Setup - TCP/IP Setup Network Type Preferred DNS Server Define network IP address type from the Static Mode for the Define the DNS server IP address. Format is same as the IP fixed IP or the Dynamic Mode by the dynamic IP address. address.

  • Page 30: Ddns Setup

    Setup - DDNS Setup DDNS Disable If it is selected, DDNS service does not work. Basic DDNS Please register the camera in net4c site so as to use net4c DDNS. Insert the serial number shown on the screen in the serial entry field.
  • Page 31 Setup - HTTPS Setup Secure Connection System Install a public certificate Secure Connection System chooses a method of security A certificate issued by Certificate Authority can be installed connection. to the camera and the installed certificate can be deleted. <How to install or delete the certificate> HTTP 1) Input the description(name) of a certificate.

  • Page 32: Snmp Setup

    Setup - SNMP Setup SNMP V3 Secure Setup - The information of camera system can be known and configured with SNMP. - The changes for configuration use version 3 and username and password should be certified at that time. Username Username is the information of user account for user authentication.
  • Page 33 Setup - Status This menu will show you all the information of Network setting in the camera. However, you cannot change those here.

  • Page 34: Alarm Input Setup

    Setup - Alarm Input Setup Input Device Setup Action Select input device type from OFF / N.O. / N.C. Define a counter action from Alarm Output / Alarm Image Transfer / Camera Action when Alarm Input is detected. Operation Action Description Ignore this Input sensor.

  • Page 35: Motion Detection Setup

    Setup - Motion Detection Setup Activation Time Action Select activation time from Always / Only Scheduled Time. Define a counter action from Alarm Output / Alarm Image transfer when motion is detected. An alarm is activated whenever motion is Always detected.

  • Page 36: Schedule Setup

    Setup - Schedule Setup Schedule function enables to transfer series of still images in Activation Time a time interval specified via E-mail or FTP. (For more detail, Select activation time from Always / Only Scheduled Time. see ‘Transfer Setup’ in this chapter) Always Transfer image at all times.

  • Page 37: Transfer Setup

    Setup - Transfer Setup Transfer Mode Click ‘Apply’ to make above setting effective. Image Transfer method is selected from FTP and E-Mail (SMTP). To use image transfer, FTP and SMTP in the next sections must be configured properly. SD Card Record If it is set to On, the image is saved into the SD card as well.
  • Page 38 Setup - FTP Setup To transfer/save the image to the relevant sites through FTP, Port then FTP needs to be setup. Define the FTP Server Port. If Port is not appropriate, it is impossible to access to FTP Server. Use Passive Mode Check it to use Passive mode for FTP transfer.

  • Page 39: Smtp Setup

    Setup - SMTP Setup To send/save the image to the relevant sites by Email, SMTP E-Mail Sender needs to be setup. Define the e-mail address of E-Mail Sender. It will be displayed as the sender when the camera sends an E-mail. Plain, SSL/TLS Select Security mode of SMTP from Plain or SSL/TLS.

  • Page 40: Sd Card Setup

    Setup - SD CARD Setup Total size / Free size Capacity Warning E-mail Total capacity of SD card and the remainder of it are If it is set ON and remained space of SD card reach to less displayed. than 8MB, a warning e-mail will be sent to the e-mail account set in SMTP menu.

  • Page 41: Users Setup

    Setup - Users Setup Users Modify List all the user accounts for authentication. Modify the information of the user accounts registered. For admin account, only Password and Auto Login function can be modified. Register a new user Delete Delete the selected user account. Admin account cannot be deleted.

  • Page 42: Date/Time Setup

    Setup - Date/Time Setup Current Date & Time Synchronize with the time server Shows the current date and time setting in the Camera. In this mode, date/time is automatically updated using the Time Server selected. After selecting the Time Zone Synchronize with my computer properly, Time Server must be selected.

  • Page 43: Firmware Update

    Setup - Firmware Update Firmware Version Warning: It shows the current Firmware Version in the system. 1. Do not turn off the power of camera during the Firmware update. Otherwise, the system can be stuck to be unstable. Firmware Filename If updating is finished, the system will be rebooted Designate the Firmware file name in your computer by automatically.

  • Page 44: Default Set

    Setup - Default Set Reset to the Factory Defaults Return the setup to the Factory Default. Reset all Settings to the Factory Defaults. Except Except Network related settings, reset all Network Settings others to the Factory Defaults. Warning: If you click ‘Apply’, you will lose all setting data. If needed, please, make a note for further installation.
  • Page 45 Setup - Restart If you click the ‘RESTART’ menu, a message box will be shown to confirm. Click the ‘Ok’ button to restart.
  • Page 46 Setup - System Start, Network Connection Status(Including IP Address), Changing System Time, Changing Video Setup, Network Setup and Event(Alarm / Motion) Alert will be recorded. 1000 PCS of Log can be stored and the recorded data won't be deleted.

  • Page 47: Sd Card Search

    SD Card Search - Search Date of stored image Choosing the date to find the stored events. Stored Events(Schedule / Motion / Alarm) The interval of stored time and number of stored images in the Event Setup can be different. Page No.
  • Page 48 Appendix A : Current TCP/IP Settings If your IP settings are obtained automatically, you could use the MS-DOS prompt (or Command Prompt) to determine your IP address. For information on how to do this, please read the FAQ. 1. Windows 98 / ME Users 2.
  • Page 49 Appendix - B : Changing IP address and subnet mask 1. Windows 98 / ME Users 2. Windows 2000 or XP Users 3. Windows Vista or 7 Users Start Start Start Setting Control Panel Control Panel Control Panel Network and Network and Dial-up sharing center Connection or...

  • Page 50: C : Port Forwarding

    Appendix - C : Port Forwarding After assigning the IP Camera a web server For Linksys BEFSR41 Cable/DSL routers: port and video server port you must use Port 1) Open a web browser and type http://192.168.1.1 into you Forwarding. (for cases A, B) Address bar.
  • Page 51 Appendix - C : Port Forwarding For Netgear RP614 routers: 1) Input http://192.168.0.1 in address bar of web browser. http://192.168.0.1 is the default IP address. 2) If it asks ID and password, input admin as ID and password as password. 3) Click “Port Forwarding”...
  • Page 52 My POWER light is not on? I can’t connect!! Power is not being supplied to the unit. Please use the power In the case of a connection failure. supply shipped with the unit and verify that a power source is active from the attached power outlet used to connect the >...

  • Page 53: Specifications

    Specifications - Dimension Unit: mm...
  • Page 54 GENIE CCTV LTD. CCTV House, City Park, Watchmead, Welwyn Garden City, Hertfordshire, AL7 ILT Tel: +44 (0) 1707 330541 Fax: +44 (0) 1707 330543 www.geniecctv.com Edition. GN-February 2014...
