Genie WIP1VD Quick Start Manual

IP Camera

Quick Start Guide

1.Package
After you receive your device, please check the following accessories.
The pictures here are for reference only.
Quick Start
Camera
CD
Guide
2.Overview
1 Lower Dome
2 Mounting Base
Cable Connection
DC12V
Drill Water-proof
Screws
Template
Cap
3
2 4
1
Network Cable
3
Power Cable
4
Network Cable
Router
Internet
Network Cable
Network Cable
Modem
Network Cable Connection
1
3. Installation
Please make sure that the wall or ceiling is strong enough to withstand 3
times the weight of the camera.
① Drill the screw holes and the cable hole on the wall according to the drill
template.
② Loosen the screws to remove the lower dome from the camera.
③
Route the cables and connect the power cable and network cable.
④ Secure the mounting base with camera to the wall with screws as shown
below.
Screwdriver
⑤ Install the lower dome back to the camera and secure it with the screws.
4. IE Network Connection
You can connect the IP camera through LAN/WAN access. Here take the
IE browser (6.0) for example.
4.1 LAN
In LAN, there are two ways to access. 1. Access through IP-Tool;
2. Directly Access through IE Browser
Computer
4.1.1 Access the camera through IP-Tool
① Make sure that the camera and the PC are well connected to the LAN.
1
3
2
