IMPORTANT INSTRUCTIONS &
ELECTRIC HEATER Model No.: GL2029US
Article No. :
READ AND SAVE THESE INSTRUCTIONS
READ CAREFULLY BEFORE ATTEMPTING TO ASSEMBLE, INSTALL, OPERATE OR
MAINTAIN THE PRODUCT DESCRIBED.
PROTECT YOURSELF AND OTHERS BY OBSERVING ALL SAFETY INFORMATION.
FAILURE TO COMPLY WITH INSTRUCTIONS COULD RESULT IN PERSONAL
INJURY AND/OR PROPERTY DAMAGE.
WARNING! To reduce the risk of fire, electric shock, or personal
injury, read all the instructions before using this heater.
Homeowner's
OPERATING MANUAL
1-GL2029USC (Curved) 1-GL2029USP (Panoramic)
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Celsi GL2029US
Summary of Contents for Celsi GL2029US
-
Page 1: Important Instructions
Homeowner’s IMPORTANT INSTRUCTIONS & OPERATING MANUAL ELECTRIC HEATER Model No.: GL2029US Article No. : 1-GL2029USC (Curved) 1-GL2029USP (Panoramic) READ AND SAVE THESE INSTRUCTIONS READ CAREFULLY BEFORE ATTEMPTING TO ASSEMBLE, INSTALL, OPERATE OR MAINTAIN THE PRODUCT DESCRIBED. PROTECT YOURSELF AND OTHERS BY OBSERVING ALL SAFETY INFORMATION. -
Page 2: Table Of Contents
TABLE OF CONTENTS SECTION 1: WARNINGS & ELECTRIC SPECIFICATIONS 1.1 Important Instructions ....................3,4 1.2 Specifications ......................4 SECTION 2:STRUCTURE AND PARTS.................4 SECTION 3: INSTALLATION 3.1 Tools required ......................5 3.2 Unpacking the heater ....................5 3.3 Locating your electric heater ................5, 6, 7 SECTION 4: Grounding....................8 SECTION 5: OPERATING INSTRUCTIONS 5.1 Operating the appliance using the manual keypad...........9... -
Page 3: Section 1: Warnings & Electric Specifications
SECTION 1 WARNINGS & ELECTRIC SPECIFICATIONS 1.1 IMPORTANT INSTRUCTIONS When using electrical appliances, basic precautions should always be followed to reduce the risk of fire, electric shock and injury to person, including the following: CAUTION- High temperature, keep electrical cords, drapery, and other furnishings at least 3 feet (0.9m) from the front of the heater and away from the side and rear. -
Page 4: Specifications
heater on soft surfaces, like a bed, where openings may become blocked. A heater has hot and arcing or sparking parts inside. It must NOT be used in potentially dangerous locations such as flammable, explosive, chemical-laden or wet atmosphere. This heater is intended for use in general use only. -
Page 5: Section 3: Installation
SECTION 3 INSTALLATION 3.1 Tools required Magnetic Phillips Screw Driver Rotary Hammer 3.2 Unpacking the Heater WARNING! Do NOT use this appliance if any part has been under water. Immediately call a qualified service technician to inspect and to replace any part of the electrical system if necessary. - Page 6 Install your heater： Respectively loosen the two screws of the wall mounting bracket on the top of appliance with a screwdriver, Then take out the wall mounting bracket (see fig.1) Choose a solid and plain wall and then put the mounting bracket on the position where you want to install the heater.
- Page 7 Fig. 2 Fig. 3 Fig. 4 3.EF.40.Rev. 1.0...
-
Page 8: Section 4: Grounding
Fig. 5 Fig. 6 SECTION 4 GROUNDING Plug the power supply cord into a wall outlet (120Vac, 60Hz).The cord has a plug as shown at A. An adapter as shown at C is available for connecting three-blade grounding-type plugs to two-slot receptacles. -
Page 9: Operating The Appliance Using The Manual Keypad
BOOT UP PROCEDURE. Once the Manual ON/OFF switch has been turned to the ON position the screen should appear white for a few seconds after which the ‘BOOT-UP’ sequence will begin. This can take up to 2 minutes during which an hourglass icon will be seen. When the BOOT-UP is complete the following icon will be seen on the screen. -
Page 10: Important Note Regarding The Use Of The Remote Control Handset
Unlike most remote handsets which require the tip of the handset to be pointed towards the appliance the Celsi handset transmits from the underside as shown below. This prevents the requirement to rotate and point the remote when the buttons are pushed. -
Page 11: Button Description
5.2.1 Button Description. ON/STANDBY: Press this button to turn the fire ON or OFF. Press this button to mute the sound or to restore the sound. MUTE: Press this button to change the manual heat setting to Low, High or Off. Lo/Hi/Off: For further information see page 10 titled ‘How to change the manual heat setting’... -
Page 12: How To Use The Function Settings
icon shows the current thermostat heat setting. This icon will stay on screen for 3 seconds. If no other buttons are pressed during this time, the icon will disappear from the screen and continue to run at this thermostat setting. When the thermostat icon is on screen, the thermostat heat setting can be changed by pressing buttons to increase or decrease the regulated temperature. -
Page 13: How To Change The Flame Image
5.2.4.1 How to change the Flame Image. Use the button as described above so that the flame image icon is displayed on screen. Press the buttons to change the flame image. There are four flame images to choose from and you will see the image change as you scroll through the selections. -
Page 14: How To Change The Brightness
5.2.4.5 How to change the Brightness. Use the button as described above so that the brightness icon is displayed on screen. Press the buttons to change the screen brightness. There are 3 brightness settings to choose from and you will see brightness change as you scroll through the selections. -
Page 15: To Reset The Heater
Do not attempt to service the unit yourself. SECTION 7 SERVICING AMERICAN ELECTRIC FIREPLACES LLC 1005 N.COMMONS DRIVE AURORA ILLINOIS 60504 U.S.A Tel: (+1) 630 723 0071 Email: tech@aef-us.com Model No.: GL2029US Article No. : 1-GL2029USC (Curved) 1-GL2029USP (Panoramic) 3.EF.40.Rev. 1.0...
