- Page 1 OPERATING MANUAL 4 Ports Output Balance Charger/Discharger For LiPo/LiFe/LiIon/NiMH/NiCd/Pb Batteries...
-
Page 2: Table Of Contents
TABLE OF CONTENTS 1. Features........................2. Exterior of the unit....................... 3. Warnings and safety notes..................4. Program flow chart...................... 5. Lithium polymer balance charge program connection diagram......6. Lithium battery(LiPo/Lilo/LiFe) program..............6.1 Charging Lithium battery at balance mode.............. 6.2 Charging Lithium battery..................6.3 'FAST' charging Lithium battery................ -
Page 3: Features
1.Features Thank you for purchasing TURNIGY 4X100W charger. This is a rapid charge/discharger with built in balancer.Please read this entire operating manual completely and attentively before using. Operating software optimized for ease of use and maximum safety The user can adjust charger's settings and parameters. However, the charger also features an AUTO charge function that sets output current during the process of charging or discharging;... - Page 4 1.Features Processing time limit The user can set the maximum charge/discharge time. If the time limit is reached, the process will be terminated automatically. Programmable memory The charger can store up to ten (10) different charge/discharge profiles for your convenience. These stored profiles can be recalled quickly, with no additional program required.
-
Page 5: Exterior Of The Unit
2.Exterior of the unit LCD Screen Menu Control Buttons INPUT DC 11~18V Ventilation Fan Battery Scokets balancing port Battery Scokets... -
Page 6: Warnings And Safety Notes
3. Warnings and safety notes Never leave the charge unsupervised when it is connected to its power supply. If any malfunction is observed immediately terminate the process and refer to the operation manual. Keep away the unit from dust, damp, rain, heat, direct, sunshine and vibration. Do not dorp it. - Page 7 3. Warnings and safety notes - Batteries that require a different charge technique from NiCd, NiMH, Lilo, LiPo, LiFe or Pb. - Faulty or damaged battery. - Battery fitted with an integral charge circuit or a protection circuit. - Batteries installed in a device, or which are electrically linked to other components. - Batteries that are not expressly stated by the manufacturer to be suitable for the currents the charger delivers during the charge process.
- Page 8 3. Warnings and safety notes Discharging The typical purpose of discharge is to determine the residual capacity of the battery, or to lower the voltage of battery to a defined level. When you discharge the battery you also have to pay attention on the process same as charging. To avoid the battery becoming deepdischarged, set the final discharge voltage correctly.
-
Page 9: Program Flow Chart
4. Program flow chart LiPo BALANCE LiPo CHARGE LiPo FAST CHG LiPo STORAGE LiPo DISCHARGE START PROGRAM SELECT 2.0A 7.4V (2S) 2.0A 7.4V (2S) 2.0A 7.4V (2S) 2.0A 7.4V (2S) 2.0A 7.4V (2S) LiPo BATT ENTER START Lilo BALANCE Lilo CHARGE Lilo FAST CHG Lilo STORAGE Lilo DISCHARGE... -
Page 10: Lithium Polymer Balance Charge Program Connection Diagram
Take care to maintain correct polarity! This diagram shows the correct way to connect your battery to the TURNIGY 4X100W while charging in the balance charge program mode only. WARNING: Failure to connect as shown in this diagram will damage this charger. -
Page 11: Lithium Battery(Lipo/Lilo/Life)Program
6. Lithium battery(LiPo/Lilo/LiFe)program These programs are only suitable for charging and discharging Lithium batteries with a nominal voltage of 3.3V, 3.6V and 3.7V per cell. These batteries need to adopt different charge technique is termed a constant voltage(CV) and constant current(CC) method. The charge current varies according to the battery capacity and performance. -
Page 12: Charging Of Lithium Battery
6. Lithium battery(LiPo/Lilo/LiFe)program 6.2 Charging of Lithium Battery This charging mode is for charging Li-Po/Ion/Fe battery without balance lead. Note: We recommends charging lithium batteries with a balance lead in the balance mode only. The left side of the first line shows the type of battery you choose. -
Page 13: Storage' Control Lithium Battery
6. Lithium battery(LiPo/Lilo/LiFe)program This displays the number of cells you set up and the processor detects. R shows the number of cells detected by the charger and S is the number of cells set by you at the previous screen. If both numbers are identical you can start charging by press Start/Enter button. -
Page 14: Discharging Lithium Battery
6. Lithium battery(LiPo/Lilo/LiFe)program 6.5 Discharging Lithium battery The value of discharge current on the left can not exceed 1C, and the value on the right can not be under the voltage recommended by the manufacturer to avoid deep discharging. Press Start/Enter for more than 3 seconds to start discharging. -
Page 15: Pb( Lead-Sulphuric Acid) Battery Program
7. Pb( lead-sulphuric acid) battery program This is programmed for charging Pb(lead-sulphuric acid) battery with nominal voltage from 2 to 36V. Pb batteries are totally different from NiCd or NiMH batteries. They can only deliver relatievely lower current compare to their capacity, and similar restrictions definitely apply to charge. -
Page 16: Nimh/ Nicdbattery Program
8. NiMH/NiCd battery program These programs are for charging or discharging NiMH (Nickel-Metal-Hydride) or NiCd (Nickel-Cadmium) battery commonly used for R/C model aplications. To alter the value at the display, press Start/Enter key to make it blink then change the value using INC or DEC key. -
Page 17: Charge-To-Discharge & Discharge-To-Charge Cycle Nimh/ Nicd Battery
8. NiMH/NiCd battery program 8.3 Charge/discharge & discharge/charge cycle of NiMH/NiCd battery You can set up sequence on the left and the number of NiMH CYCLE CHG＞DCHG cycles on the right. Range of the cycle number is 1-5. Start Batt type '>... -
Page 18: Battery Memory Set
9. Battery memory set The charger can store up to 10 different charge/discharge profiles for your convenience, and the stored profiles can be recalled quickly without having to go through the setup process. Enter the battery memory program, you can change the battery BATT MEMORY【1】... - Page 19 9. Battery memory set SAVE PROGRAM ENTER DEC INC Save the program set by pressing the Start/Enter button for more SAVE PROGRAM SAVE than three seconds. ENTER ＞3 seconds START BATT MEMORY【1】 This screen indicate the saved profile. LiPo 7.4V(2S) next flash Once you've saved a charge profile, you can load those settings to use later.
-
Page 20: Program Set Up
10. Program set up It will be operated with the default value of the essential user settings when it is connected to a DC 11~18V batttery for the first time.The screen displays the following information in sequence and the user can change the value of parameter on each screen. When you are willing to alter the parameter value in the program, press Start/Enter key to make it blink then change the value with INC or DEC key. - Page 21 10. Program set up The beep sounds at every time pressing the buttons to confirm DEC INC your action. The beep or melody sounded at various times during Key Beep operation to alert different mode changes. Buzzer These audible sounds can be on or off. DEC INC This program monitors the voltage of input battery.
-
Page 22: Lipo Battery Meter
11. Lipo battery Meter PROGRAM SELECT Press the Start/Enter button to enter the LiPo Battery Meter. LiPo BATT METER Start Enter 4.19 4.15 4.18V The screen indicate each cell's voltage. 0.00 0.00 0.00V The screen indicate the total voltage, the highest voltage, MAIN 12.52V H4.190V L4.160V... -
Page 23: Additional Charge Information
12. Various information during the process You can inquire various information on LCD screen during charging or discharging process. When you press DEC button the charger shows the establishment of user settings. And also you can monitor the voltage of individual cell by pressing INC button when the individual connection cable is linked to the Lithium battery being processed. -
Page 24: Warning And Error
13. Warning and error messages It incorporates a variety of functions for the systems to verify processes and the state of the electronics. In case of an error the screen will display the cause of error and emit an audible sound. Incorrect polarity connected. -
Page 25: Specifications
14. Specifications Stated values refer to one charger Operating voltage range DC 11.0~18.0 Volt Charge Power 400W(100Wx4) Discharger Power 32W(8Wx4) Charge current range 0.1A-10A Discharge current range 0.1A-5A Cell Count 1~15 NiCd/NiMH cells 1~6 LiPo/LiIon/LiFe cells 1-10 Lead-Acid cells (2V - 20V) Current Drain for Balancing Lithium 200mA/Cell Net weight... -
Page 26: Warranty And Service
15. Warranty and service We warrant this product for a period of one year(12 months) from the date of purchase. The guarantee applies only to such material or operational defects, which are present at the time of purchasing the product. During that period, we will replace without service charge any product deemed defective due to those causes.
