Conexant HCF V.90 User Manual

56k usb modem
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
5
6
K
U
S
B
5
6
K
U
S
C
o
n
e
x
a
n
C
o
n
e
x
a
n
User's Guide
M
o
d
e
B
M
o
d
e
t
H
C
F
V
.
9
0
t
H
C
F
V
.
9
0
m
m

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HCF V.90 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Conexant HCF V.90

Summary of Contents for Conexant HCF V.90

  • Page 1 User’s Guide...

  • Page 2: Radio Frequency Interference Statement

    Conexant HCF V.90 56K USB Modem User’s Guide FCC Requirements This equipment complies with Part 68 of the FCC Rules. On the bottom of this equipment is a label that contains, among other information, the FCC Registration Number and Ringer Equivalence Number (REN) for this equipment.
  • Page 3 Conexant HCF V.90 56K USB Modem User’s Guide Notices to Australian users: The modem card must only be used in a data terminal equipment (DTE) e.g. computer, that has a screw down cover (lid). As unsafe voltages (TNV) exist on the modem card, disconnect the modem card from the telephone line while the cover (lid) of the DTE (computer) is removed.

  • Page 4: Table Of Contents

    Conexant HCF V.90 56K USB Modem User’s Guide TABLE OF CONTENTS Chapter 1 Introduction ............5 1.1 Introduction..........................5 1.2 Features ............................5 1.3 What’s in the Package ......................5 Chapter 2 Specifications...........6 2.1 Specifications...........................6 2.2 System Requirements ......................6 Chapter 3 Hardware Installation........7 Chapter 4 Driver Installation ..........8 4.1 Installing Windows 98......................8...

  • Page 5: Chapter 1 Introduction

    Chapter 1 Introduction 1.1 Introduction Thank you for choosing this HCF V.90 56K USB Modem. It is not only the most cost-effective solution to connect your PC to the Internet, but also increase the usage of the CPU and decrease the cost of ownership. It reduces the time and pain during installation procedure.

  • Page 6: Chapter 2 Specifications

    Conexant HCF V.90 56K USB Modem User’s Guide Chapter 2 Specifications 2.1 Specifications Computer Interface USB V1.1 Line Interface RJ-11 for POTS line Data Protocols V.90, K56flex, V.34, V.32bis, V.32, V.22bis, V.22, V.23, V.21, Bell 212A and 103 Data Sp eed 56k, 54k, 52k, 50k, 48k, 46k, 44k, 42k, 40k, 38k, 36k, 34k, 33.6k,...

  • Page 7: Chapter 3 Hardware Installation

    Conexant HCF V.90 56K USB Modem User’s Guide Chapter 3 Hardware Installation Plug the connector of the USB Modem into the USB port of your PC. Plug one end of telephone cord into the modem’s “LINE” jack, which is shown on the modem’s bracket labeled “LINE”.

  • Page 8: Chapter 4 Driver Installation

    Conexant HCF V.90 56K USB Modem User’s Guide Chapter 4 Software Installation Power on your computer and modem and then start Windows 98/2000. Windows 98/2000 will detect the modem automatically. 4.1 Windows 98 When you see the message of V.90 modem with USB interface appearing, insert the driver CD came with the modem.
  • Page 9 CD-ROM drive) or use Browse to search the location, and click Next to start the search. Windows has found the location of the driver for Conexant USB HCF V.90 Data, Fax, Voice Modem, click Next to start the installation...
  • Page 10 Conexant HCF V.90 56K USB Modem User’s Guide This installation has been done; click Finish to end this procedure...

  • Page 11: Installing Windows 2000

    Conexant HCF V.90 56K USB Modem User’s Guide 4.2 Installing Windows 2000 Windows will detect the modem automatic; please insert the driver CD supplied and clicks Next. Select Search for a suitable driver for my device [recommended], then click Next.
  • Page 12 Conexant HCF V.90 56K USB Modem User’s Guide Select Specify a location, then click Next. Please type I:\Hcf_Usb\Win2K or use Browse… to find the driver directly, then click OK (I is the letter of CD-ROM drive). Windows will found a driver for this device, then click Next.
  • Page 13 Conexant HCF V.90 56K USB Modem User’s Guide Click Yes to continue. Click Finish to end this procedure.

  • Page 14: Chapter 5 Diagnostics

    Start / Settings / Control Panel, and double-click on the Modems icon. To test the modem by clicking on the Diagnostics tab. Then select the COM Port where Conexant HCF V.90 Data Fax Voice USB is setting and click More Info… to start the test.
  • Page 15 Conexant HCF V.90 56K USB Modem User’s Guide If your modem is responding to AT commands and functioning correctly, it means that your modem is working properly. Click OK to end this procedure.

  • Page 16: Diagnostics In Windows 2000

    5.2 Diagnostics in Windows 2000 Move your cursor as following sequence Start\Settings\Control Panel. Then double-click on the Phone and Modem Options icon. Click on the Modems tab, then select Conexant HCF V90 Data Fax Voice USB Modem and click Properties.
  • Page 17 Conexant HCF V.90 56K USB Modem User’s Guide Click on the Diagnostics tab. To test the modem by clicking Query Modem. If your modem is responding to AT commands and functioning correctly, it means that your modem is working properly. Click OK to end this...

  • Page 18: Chapter 6 Uninstalling

    Conexant HCF V.90 56K USB Modem User’s Guide Chapter 6 Uninstalling 6.1 Uninstalling in Windows 98 Move your cursor as following sequence Start / Settings / Control Panel and Double-click on the Add/Remove programs icon.
  • Page 19 Conexant HCF V.90 56K USB Modem User’s Guide Select Conexant HCF USB Modem and click on the Add/Remove… button. Click Yes to remove the modem.
  • Page 20 Conexant HCF V.90 56K USB Modem User’s Guide Click OK to end this procedure.

  • Page 21: Uninstalling In Windows 2000

    Conexant HCF V.90 56K USB Modem User’s Guide 6.2 Uninstall in Windows 2000 Move your cursor as following sequence Start \ Settings \ Control Panel. Then double-click on the Add/Remove Hardware icon. Click Next to continues.
  • Page 22 Conexant HCF V.90 56K USB Modem User’s Guide Select Uninstall/Unplug a device, then click Next. Select Uninstall a device and click Next to continue...
  • Page 23 Conexant HCF V.90 56K USB Modem User’s Guide Select Conexant HCF V90 Data Fax Voice USB Modem, then click Next to continue. Select YES, I want to uninstall this device, then click Next to continue.
  • Page 24 Conexant HCF V.90 56K USB Modem User’s Guide Click Finish to end this procedure.
