Summary of Contents for Conexant 201
- Page 1 201 (ER/ES) User’s Manual 201 ADSL Ethernet Modem...
- Page 2 201(ER/ES) User ’s Manual 201(ER/ES) User s Manual Copyright© 2002 SEROME Electronics Inc. All Rights Reserved. No part of this publication may be reproduced or distributed in any form or by any means, or stored in a database or retrieval system, without the prior written permission of SEROME Electronics, Inc.
- Page 3 201(ER/ES) User ’s Manual 201(ER/ES) User s Manual FCC NOTICE THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERA TION IS SUBJECT TO THE FOLLOWING TWO CONDITION: (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDERSIRED OPERA TION.
-
Page 4: Table Of Contents
201(ER/ES) User s Manual Contents Chapter 1. Introduction What is ADSL ------------------------------------- 5 201 Layout and LED Description ------------------- 6 201 Specification ------------------------------- 9 Chapter 2. Before Installation Safety Check---------------------------------------11 The climate condition Check--------------------------- 11 System Requirement Check --------------------------- 12 201 Package Check ---------------------------- 13 Chapter 3. -
Page 5: Chapter 1. Introduction
201(ER/ES) User s Manual Chapter 1. Introduction This chapter provides the brief concept of ADSL, and the external form and specification of 201. This chapter covers the following topics : What is ADSL 201 Layout and LED Description 201 Specification... -
Page 6: 201 Layout And Led Description
ADSL was specifically designed to exploit the one-way natur e of most multimedia communication in which large amounts of information flow toward the user and only a small amount of interactive control information is returned. 201 Layout and LED Description... - Page 7 201(ER/ES) User ’s Manual 201(ER/ES) User s Manual 201 (Front view) Front Panel LED layout (LED numbering from the left side)
- Page 8 201(ER/ES) User ’s Manual 201(ER/ES) User s Manual LEDs Color Status Meaning Green - Solid - Power Detected - Off - Power Off Green - Solid - Device passed self test - Flashing - Device failed self test DATA Green...
-
Page 9: 201 Specification
201(ER/ES) User ’s Manual 201(ER/ES) User s Manual 201 (Back side view) (Back Panel numbering from left side) Location Lable Port Function LINE ADSL Line Port Connects telephone Line cable in ADSL line. PHONE Telephone Connects the telephone cable in your telephone. -
Page 10: Chapter 2. Before Installation
VPI: 0~255 , VCI :0~65,535 <<Notice >> The connection speed of 201 may vary depending on your ADSL service, the ADSL line condition, your PC specification and the distance between ADSL modem and Central Office of your local ADSL service provider. -
Page 11: Safety Check
201(ER/ES) User ’s Manual 201(ER/ES) User s Manual This chapter provides basic safety information before installation. Please read this chapter very carefully before installation. This chapter covers following topics: Safety Check The climate condition Check System Requirements Check 201 Package Check... -
Page 12: System Requirement Check
For installing 201 in safe and being used properly, please be aware of the climate Condition first. 201 is connected either Desktop PC or Laptop PC, so check the climate conditions of your PC and follow those instruction first. It’s recommendable that 201 is being used in same temperature and humidity. -
Page 13: 201 Package Check
The performance of 201 depends on your system specification, so following specification is recommended. OS : Windows 98/98SE CPU :Pentium II 350MHz or higher System Memory(RAM): 64MB or higher LAN Card : Connect Ethernet Port 201 package Check When opening 201 Package, please check the following items in the Package. -
Page 14: Chapter 3. Installation Of 201
201 (ADSL Ethernet Modem) Direct UTP Cable (RJ-45) Power Adaptor Telephone Line Cable (RJ-11) Items : Quantity 201 (ADSL Ethernet Modem) : 1 Power Adaptor Telephone Line Cable (RJ-11) CD(Manual & USB Driver) Direct UTP Cable (RJ -45) Chapter 3. Installation of 201... -
Page 15: Installation 201
201(ER/ES) User ’s Manual 201(ER/ES) User s Manual This chapter provides the brief concept of ADSL, and the external form and specification of 201. This chapter covers the following topics: Installation 201 Connect and Disconnect the Internet Installation 201 Start Internet Explorer to view or reset the configuration of the ADSL... - Page 16 201(ER/ES) User ’s Manual 201(ER/ES) User s Manual Enter “admin” at [User Name], “conexant” at [Password] as below and click [OK] button to proceed. ADSL Home Page : If it is connected, the homepage as below is to appear.
- Page 17 201(ER/ES) User ’s Manual 201(ER/ES) User s Manual ADSL Status Information : You can check the connection status and the connection speed(Upstream and Downstream).
