Y
Pb
Service Port
Name
Service Port
YPBPR
COAXIAL
EARPHONE
PC AUDIO IN
ANT 75 Ω
VGA IN
AV INPUT
HDMI IN
POWER SOCKET
Pr
COAXIAL
(Left Side)
R F
(Back Side)
Function Description
For Upgrade Use.
Connect to the composite terminal of your DVD/VCR
Digital Audio Output
Earphone output
PC audio input
Connect to ANT or cable source
VGA signal from computer output
Connect to HDMI of DVD or other equipment
DC 12V
4A
6
VIDEO
R
L
Getting Started
