Summary of Contents for BTC 9013RF
- Page 1 封 面 9013RF Wireless Keyboard & Mouse Kit User’s Guide Version 1.1...
- Page 2 封面內頁 The information in this document is subject to change without notice and does not represent a commitment on the part of the vendor. No warranty of representation, either expressed or implied, is made with respect to the quality, accuracy or fitness for any particular purpose of this document. The manufacturer reserves the right to make changes to the content of this document and/or the products associated with it at any time without obligation to notify any person or organisation of such changes.
-
Page 3: Table Of Contents
What's in this package ...1 System Requirements ...2 Hardware Installation...3 Software Installation ...7 4.1 Keyboard Driver Installation...7 4.2 Mouse Driver Installation ...7 Using the Keyboard and Mouse ...8 5.1 Using the Keyboard ...8 5.2 Using the Mouse Driver...11 Troubleshooting ...14... -
Page 5: Introduction
1 Introduction Congratulations on your purchase of this wireless RF keyboard and mouse! This keyboard and mouse will finally free you of the constraints of your desktop by providing a wireless connection between your keyboard/mouse and your PC. Pass around the keyboard or mouse during meetings without having to bother... -
Page 6: System Requirements
The system supporting ACPI or APM II (for power management buttons) ATX mother board and ATX power supply (for power management buttons) Available PS/2 keyboard port and mouse port. Please refer to table below for the other system requirements for the features. Function Windows NT 4.0 /... -
Page 7: Hardware Installation
(Remember your selection.) Back View of Receiver Step 3: Connect the receiver to your PC by plugging in the receiver’s PS/2 mouse connector into the mouse port of your PC and the PS/2 keyboard connector into the keyboard port. Mouse Connector Step 4: Take the keyboard and make sure the batteries on the back are installed correctly. - Page 8 Step 5: Use the slide switch on the back of the keyboard to select the same channel as the one selected in step 2 on the receiver. ID Button Step 6: Take the mouse and make sure the batteries on the back are installed correctly. (Follow the polarity signs in the battery compartment.) CHANNEL SWITCH...
- Page 9 Step 3: Press the ID button on the bottom of the keyboard once. ID Button Remarks: You must follow the procedure above to set the ID of receiver, mouse and Once the receiver ID button is pressed you have 35 seconds to keyboard.
- Page 10 When changing the batteries of keyboard or mouse, there is no need to reset all the ID’s. Simply reset one of them. When keyboard batteries are low, a battery low icon system tray. When mouse batteries are low, a battery low icon system tray.
-
Page 11: Software Installation
CD included in the box. Make sure the driver CD is in your computers CD-ROM drive. Run the setup.exe in the \9013RF\mouse software directory of the driver CD. Follow the on screen instructions to finish the installation procedure. -
Page 12: Using The Keyboard And Mouse
ACPI keys. When the option is enabled, the driver will take Windows' place to process these keys. Note: For detailed information, please read the online help by right clicking the mouse on the KeyMaestro Keyboard icon task bar and selecting Help. Power Off... - Page 13 Multimedia Keys There is a row of multimedia keys on the top of keyboard. The functions are described as below: Help Shortcut Search Favorites Folder WWW Home Volume Control Mute Play/Pause Stop Display the help file on the screen. Provide you to create an easy access to the documents and programs you use most often.
- Page 14 Previous/ Fast Backward Next/ Fast Forward Eject skip backward to the previous file/track or play backward fast when pressing once quickly. play backward fast when pressing on the button. Note: The Fast Backward function only supports Microsoft CD Player Version 4.0 (under Windows NT4.0), Microsoft CD Player Windows 95, Microsoft CD Player Windows 98 and Microsoft CD Player Version 5.0...
-
Page 15: Using The Mouse Driver
Using the Mouse Driver After installing the mouse driver as described in Chapter 4 you will be able to startup the Mouse Control Panel by right clicking on the KeyMaestro Mouse icon after restarting your machine. The Mouse Control Panel (KeyMaestro Mouse Properties) window... - Page 16 Forward Quick Jump Function Introduction Also, after installing the mouse driver and invoking the KeyMaestro mouse driver program you will have access to 9 special function icons by pressing the scroll wheel once. These 9 functions are: Mouse Control Panel...
- Page 17 Clicking once more on the scroll wheel will close these icons. Note: For more detailed information please read the online help by right clicking on the KeyMaestro Mouse bar and select Help. Set the cursor to the horizontal scroll bar to scroll the document horizontally.
-
Page 18: Troubleshooting
If the plugs appear normal then reinsert the plugs into their respective connectors on your PC. Make sure the mouse plug is inserted in the mouse connector on your PC and the keyboard plug is inserted into the keyboard connector on your PC. - Page 19 Installation. Also check your hardware requirements meet those listed in this manual 11. Use the mouse only on a clean, flat, non-slippery surface in order to ensure smooth and accurate cursor action. 12. Keep all items away from direct sunlight, moisture, dirt, extreme heat and abrasive chemical (cleaning) solutions.
- Page 21 FCC GUIDELINES This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions may cause harmful interference to radio communications.
- Page 23 封底內頁...
- Page 24 封底 3100505760 v1.1 May 2003 Printed in China...
