2001ARF
Wireless Keyboard & Mouse Kit
User's Guide
Version 1.2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 2001ARF and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for BTC 2001ARF

  • Page 1 2001ARF Wireless Keyboard & Mouse Kit User’s Guide Version 1.2...
  • Page 2 The information in this document is subject to change without notice and does not represent a commitment on the part of the vendor. No warranty of representation, either expressed or implied, is made with respect to the quality, accuracy or fitness for any particular purpose of this document.
  • Page 3: Table Of Contents

    Table of Contents Introduction...1 What's in this package ...1 System Requirements ...2 Hardware Installation...2 Software Installation ...6 4.1 Keyboard Driver Installation ...6 4.2 Mouse Driver Installation ...6 Using Keyboard and Mouse ...7 5.1 Using the Keyboard...7 5.2 Using the Mouse Driver...8 Troubleshooting ...11...
  • Page 5: Introduction

    Internet Explorer 5.0 or later version!). And last but not least, this package also provides a special driver that provides unique shortcut functions. In order to enjoy your 2001ARF kit to the fullest it is recommended that you first read this manual carefully before installation of the 2001ARF keyboard and mouse kit.
  • Page 6: System Requirements

    The system supporting ACPI or APM II (for power management buttons) ATX mother board and ATX power supply (for power management buttons) Available PS/2 keyboard port and mouse port. Please refer to below table for the other system requirements for the 2001ARF’s various features. Windows NT 4.0 /...
  • Page 7: Hardware Installation

    3 Hardware Installation Step 1: Make sure your PC is switched off. Step 2: Connect the receiver to your PC by plugging in the receiver’s green connector into the mouse port of your PC and the purple connector into the keyboard. Mouse Connector Step 3: Take the keyboard and make sure the batteries on the back are installed correctly.
  • Page 8 3. Make sure the receiver is placed in a location where is relatively free of strong electromagnetic or transmission sources in order to ensure optimal reception of the keyboard and mouse signal. ID Button Setting This wireless keyboard kits have 255 sets ID in each unit. This extra ID-recognition function helps to protect against interference from other RF keyboards in the same environment.
  • Page 9 Remarks: You must follow the procedure above to set the ID of receiver, mouse and keyboard. Once the receiver ID button is pressed you have 35 seconds to complete the entire process, or you will need to begin again. Once the keyboard and receiver are plugged in, the yellow receiver light will flash.
  • Page 10: Software Installation

    After finishing the hardware installation as described above and starting up your PC, you should be able to immediately take advantage of the wireless function of the 2001ARF wireless keyboard and mouse kit. If the keyboard and mouse are not working properly, then please check Chapter 6 Troubleshooting for tips on how to solve your problem.
  • Page 11: Using Keyboard And Mouse

    5 Using Keyboard and Mouse 5.1 Using the Keyboard Besides the usual keys, this keyboard also has extra-dedicated keys, which provide the following ACPI and Internet functionality: Please note: In order to use these keys under Windows NT 4.0, Windows 95 or Windows 98 it is necessary to have the KeyMaestro keyboard driver installed.
  • Page 12: Using The Mouse Driver

    5.2 Using the Mouse Driver After installing the mouse driver as described in Chapter 4 you will be able to start up the Mouse Control Panel by left double-clicking on the KeyMaestro Mouse icon after restarting your machine. You can also invoke the Mouse Control Panel by choosing Start→Programs→MMaestro→KeyMaestro Mouse Driver.
  • Page 13 The Definition of Mouse Extra Function: Function Let you to open 8 special functions quickly. For the detailed, please refer to the ”Quick Jump Function Quick Jump Introduction” in next section. Replace the "double click" movement to activate an application or function, it can save the valuable Double Click mouse-clicks.
  • Page 14 Vertical Scroll Bar Windows Explorer Size Grip Minimize All Windows Recall the Last Active Window Exit Clicking once more on the scroll wheel will close these icons. Note: For more detailed information please read the online help by right clicking on the KeyMaestro Mouse icon select Help.
  • Page 15: Troubleshooting

    6 Troubleshooting When the keyboard or the mouse doesn't work properly, please check the following: Take out the receiver’s connector and check both the receiver’s mouse and keyboard plug for possible broken pins. If the plugs appear normal then reinsert the plugs into their respective connectors on your PC. Make sure the mouse plug is inserted in the mouse connector on your PC and the keyboard plug is inserted into the keyboard connector on your PC.
  • Page 16 11. Keep all items away from direct sunlight, moisture, dirt, extreme heat and abrasive chemical (cleaning) solutions. 12. Should the receiver, the keyboard or mouse become accidentally immersed or splashed by liquids, switch off your PC immediately, unplug all items and refer to your dealer for further assistance.
  • Page 17 FCC GUIDELINES This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions may cause harmful interference to radio communications.
  • Page 19 封底內頁...
  • Page 20 3100504921 Version 1.2 February 2003 Printed in China...
