封面內頁
封面內頁
9001URF
USB Wireless Keyboard & Mouse Kit
User's Guide
Version 1.3

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 9001URF and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for BTC 9001URF

  • Page 1 封面內頁 封面內頁 9001URF USB Wireless Keyboard & Mouse Kit User’s Guide Version 1.3...
  • Page 2 The information in this document is subject to change without notice and does not represent a commitment on the part of the vendor. No warranty of representation, either expressed or implied, is made with respect to the quality, accuracy or fitness for any particular purpose of this document. The manufacturer reserves the right to make changes to the content of this document and/or the products associated with it at any time without obligation to notify any person or organisation of such changes.
  • Page 3: Table Of Contents

    Table of Contents Introduction ...1 What's in this package ...1 System Requirements ...2 Hardware Installation...3 Software Installation ...7 4.1 Keyboard Driver Installation...7 Using the Keyboard and Mouse ...8 5.1 Using the Keyboard ...8 5.2 Using the Mouse...10 Troubleshooting ...11...
  • Page 5: Introduction

    1 Introduction Congratulations on your purchase of this USB wireless RF keyboard and mouse! This keyboard and mouse will finally free you of the constraints of your desktop by providing a wireless connection between your keyboard/mouse and your PC. Pass around the keyboard or mouse during meetings without having to bother about a cable blocking your way or write e-mails and surf the Internet from the comfort of your living room couch! This keyboard and mouse kit consists of a keyboard, a mouse and a receiver.
  • Page 6: System Requirements

    2 System Requirements Microsoft Windows 98, Windows ME, Windows 2000 or Windows XP operating system Microsoft Internet Explorer 5.0 or later version (for the Internet keys) Standard sound card (for CD and Video operation) The system supporting ACPI or APM II (for power management buttons) ATX mother board and ATX power supply (for power management buttons) USB port...
  • Page 7: Hardware Installation

    3 Hardware Installation Slide Switch Setting Step 1: Take the receiver and select channel CH1 or CH2 by using the slide switch on the side of the receiver. (Remember your selection.) Back View of Receiver Step 2: Connect the receiver to your PC by plugging in the receiver’s USB plug into your PC.
  • Page 8 Step 4: Use the slide switch in the battery compartment of the keyboard to select the same channel as the one selected in step 2 on the receiver. ID Button Step 5: Take the mouse and make sure the batteries on the back are installed correctly.
  • Page 9 ID Button Setting This wireless keyboard kits contains 2 channels, and each channel contains 255 sets ID. This extra ID-recognition function helps to protect against interference from other RF keyboards in the same environment. The word CONNECT labels the ID button on each unit. The LED under ID button of receiver shows connecting condition.
  • Page 10 When the receiver’s connector is plugged in, the yellow receiver light will flash. Once the IDs of mouse, keyboard and receiver are set, it will remain steadily lit. Please note that do not press on any key when you set ID of keyboard, or the setting will fail.
  • Page 11: Software Installation

    4 Software Installation After finishing the hardware installation as described in this manual and starting up your PC, you should be able to immediately take advantage of the wireless function of the wireless keyboard and mouse. If the keyboard and mouse are not working properly, see Chapter 6 Troubleshooting for tips on how to solve your problem.
  • Page 12: Using The Keyboard And Mouse

    5 Using the Keyboard and Mouse 5.1 Using the Keyboard Besides the usual keys, this keyboard also has extra-dedicated keys, which provide the following ACPI, multimedia and Internet functionality: ACPI Keys: Your keyboard has the power management keys that are Power off, Sleep, and Wake up three keys.
  • Page 13 Multimedia Keys There is a row of multimedia keys on the top of keyboard. The functions are described as below: Help Display the help file on the screen. Provide you to create an easy access to the documents and programs you use most Shortcut often.
  • Page 14: Using The Mouse

    Stop Previous/ Fast Backward Next/ Fast Forward Eject 5.2 Using the Mouse After plugging the receiver in your computer and setting the mouse ID as described in chapter 3- Hardware Installation, you can take advantage of this optical mouse immediately when you start up the computer. Stop the playing.
  • Page 15: Troubleshooting

    6 Troubleshooting If you are experiencing problems with your keyboard or mouse please check the following: Take out the receiver’s connector and check the receiver’s plug for possible broken pins. If the plugs appear normal then reinsert the plugs on your PC. Check to see if the batteries in the keyboard and mouse are installed correctly.
  • Page 17 FCC GUIDELINES This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions may cause harmful interference to radio communications.
  • Page 19 封底內頁...
  • Page 20 封底 3100505100 v1.3 May 2003 Printed in China...
