Inspiration Pursuit Exercise Cycle Owner's Manual page 8

ASSEMBLY INSTRUCTIONS
Step 3. Attach the handlebars
1. Slide the computer wires through the hole on the
handlebar fixing bracket as shown.
2. Secure in place using bolt & screws as shown and be sure
to fit them in the same order as the diagram.
Make sure the bolts are fully tightened with the allen key.
Step 4. Attach the console
1. Connect the computer wires together as shown and
make sure it's fully connected.
2. Secure onto the bracket using screws as shown (Screw
are located in the back of the console).
8
Part No. 10 x 1
35mm round allen head bolt 8mm machine screw
Part No. 9 x 2
