Inspiration Pursuit Exercise Cycle Owner's Manual page 7

ASSEMBLY INSTRUCTIONS
Step 1. Attach the stabilizers
1. Attach the front and rear stabilizers with the nuts, bolts
and washers as shown in the diagram.
2. Be sure to fit the parts in the same order as the diagram.
Make sure the bolts are fully tightened with the spanner.
STEP A
Put the cable in the opening.
The silver part of the cable can be
This is how it looks when fixed in
position.
STEP C
NOTE: Turn tension to
highest level.
pushed away from the
control unit to allow it to fit
inside the front post.
STEP D
STEP B
Part No. 16 x 4 Part No. 18 x 4
65mm carriage bolt Curve washer
Step 2. Attach the front post
1. Attach the tension control to the front post with the
screw. Turn the tension control to highest level to give
maximum length of cable for fitting the front post. Hook
the tension cables together as shown. (You may have to
pull firmly downwards on the upper cable to make it fit
underneath the bracket of the lower cable)
2. Connect the computer cable as shown and make sure it's
fully connected.
3. Slide the front post tube over the front post mounting.
4. Secure in place using the bolts and washers as shown
and be sure to fit them in the same order as the diagram.
Make sure the bolts are fully tightened with the allen key.
Part No. 12 x 1 Part No. 18 x 4
50mm machine screw Curve washer
Part No. 20 x 4 Part No. 19 x 4
Spring washer Cap nut
Part No. 21 x 4 Part No. 20 x 4
15mm round allen head bolt Spring washer
7
