Attaching the L-Brackets

Depending on your mounting scheme, alternately, you may use the L-brackets to mount your
displays onto your wall or device.
Find a suitable location for attaching L-brackets.
A. The left and right sides
B. The Top and bottom sides
Bracket
Bracket
OR
Bracket
Bracket
Note:
You will need a screwdriver to attach the L-brackets.
Your kiosk touch monitor included two L-brackets (and four screws, M4x6).
This equipment is intended to be mounted in accordance with the proper hardware and the
installation instructions supplied with the product. Use of mounting brackets or screws other
than those specifi ed in the installation instructions may cause a hazard.
5
