Summary of Contents for Touch Revolution K17A Series
- Page 1 USER’s GUIDE K17A Series Touch Screen LCD Monitors Rev.A...
- Page 2 The information contained in this document is subject to change without notice. This document contains proprietary information that is protected by copyright. All rights are reserved. No part of this document may be reproduced,translated to another language or stored in a retrieval system, or transmitted by any means, electronic, mechanical, photocopying, recording, or otherwise, without prior written permission.
-
Page 3: Table Of Contents
Table of Contents Usage Notice Precautions..........................1 Introduction About K17A Series ......................... 2 Touch Screen for K17A Series ....................2 Package Overview ......................... 3 Installation Product Overview ......................4 Front View ....................... 4 Bottom View ......................4 Attaching the L-Brackets ....................5 Side Mount for Your Monitor .................. -
Page 4: Usage Notice
Usage Notice ! Warning - To prevent the risk of fi re or shock hazards, do not expose this product to rain or moisture. ! Warning - Please do not open or disassemble the product as this may cause electric shock. Precautions Follow all warnings, precautions and maintenance as recommended in this user’s manual to maximize the life of your unit. -
Page 5: Introduction
Introduction About K17A Series The K17A Series is a 17" fl at panel screen with an active matrix, thin-fi lm transistor (TFT) liquid crystal display (LCD). Features include: • Direct Analog signal input • Active matrix TFT LCD technology • 1280x1024 SXGA resolution •... -
Page 6: Package Overview
Package Overview VGA Signal Cable LCD Display Power Cord Brackets USB Cable ( A to B ) DC Power Supply Remote Key Quick Start Guide Screws (sold separately) -
Page 7: Installation
Installation Product Overview • Front View • Bottom View DC IN RJ-11... -
Page 8: Attaching The L-Brackets
Attaching the L-Brackets Depending on your mounting scheme, alternately, you may use the L-brackets to mount your displays onto your wall or device. Find a suitable location for attaching L-brackets. A. The left and right sides B. The Top and bottom sides Bracket Bracket Bracket... -
Page 9: Side Mount For Your Monitor
Side Mount for Your Monitor This monitor can be mounted to the wooden or concrete wall with 4 screws and a pair brackets on the opposites. 174.0 mm 10.0 mm 186.0 mm 11.0 mm... -
Page 10: Customer Panel Material
Customer panel material: 1. Wooden wall: Ø4.5mm thru holes for M4 screws w/nuts, or no thru holes, screws for wood 4mm. 2. Sheet metal: concealed head threaded studs M4 w/nuts. RECOMMENDED CUSTOMER PANEL CUT-OUT 403.0 mm 174.0 mm 87.0 mm 380.8 *A: The distance between the shielding surface and the bottom of the screw hole is 8 mm. -
Page 11: Connecting The Display (Figure 9.1)
Connecting the Display (Figure 9.1) To setup this display, please refer to the following fi gure and procedures. 1. Be sure all equipment is turned off. 2. Connect the DC adapter to the power connector on the monitor and the other end into an electrical outlet (9.1). -
Page 12: (Figure 9.1)
(Figure 9.1) (Optional) -
Page 13: User Controls
User Controls Back Panel Controls Power Enter Down Menu Menu off status Menu on status Menu appear Menu disappear/return to main item Brightness Main item select up/Adjust up Contrast Main item select down/Adjust down Enter/Select sub-item function Power On/Off... -
Page 14: How To Use The Osd Menus
How to Use the OSD Menus Icon Key Name Menu Down Enter Power 1. Press the “MENU” button to pop up the “on-screen menu” and press “Up” or “Down” button to select among the fi ve functions in the main menus. 2. -
Page 15: On-Screen Display Menus
On-Screen Display Menus Main OSD Menu: ITEM CONTENT The monitor luminance level control. Contrast The monitor backlight level control. Brightness Fine-tune the image to full screen automatically. Auto Adjust Moving screen image horizontal position to left or right. Left/Right Moving screen image vertical position to up or down. Up/Down The screen image horizontal dot clock adjustment. -
Page 16: Appendix
Appendix Troubleshooting If you are experiencing trouble with the LCD display, refer to the following. If the problem persists, please contact your sales representative or our service center. Problem: No image appears on screen. ► Check that all the I/O and power connectors are correctly and well connected described in the “Installation”... -
Page 17: Warning Signal
Warning Signal If you see warning messages on your LCD screen, this means that the LCD display cannot receive a clean signal from the computer graphics card. Below are the three kinds of Warning Signal. Please check the cable connections or contact your sales representative or our service center for more information. -
Page 18: Product Dimensions
Product Dimensions 394.0 mm 389.4 mm 3.0 mm 54.1 mm 338.9 mm Front View Side View 100.0 mm 75.0 mm 8-M4 Back View... -
Page 19: Compatibility Modes
Compatibility Modes Mode Resolution H-Frequency(khz) V-Frequency(hz) IBM VGA 720X400 31.47 IBM VGA 640X480 31.47 Apple MacII 640X480 35.00 VESA VGA 640X480 37.86 VESA VGA 640X480 37.50 VESA SVGA 800X600 35.16 VESA SVGA 800X600 37.88 VESA SVGA 800X600 48.08 VESA SVGA 800X600 46.88 Apple Mac... -
Page 20: Touch Screen Driver Installation
USB touch screen interface. No additional software driver is required for general operation of the touch screen. 2. For K17A Series, the system requires 15 seconds for Windows 7 to install/uninstall the touch drivers while turning power on/off or plugging/unplugging USB cable.
