Customer panel material:
RECOMMENDED CUSTOMER PANEL CUT-OUT
A: The distance between the shielding surface and the bottom of the screw hole is 8 mm.
!
Warning!
Please select the proper screws!
Please use four M4 screws diameter with proper length to mount your monitor.
Please note: the mounting stand must be able to support at least 13.2 lbs (6Kg).
518.4 mm
214.0 mm
180.0 mm
A
7
A
A
A
