Energenie EG-PMSU User Manual

Energenie programmable power strip
Hide thumbs Also See for EG-PMSU:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
USER MANUAL
HANDBUCH
HANDLEIDING
EG-PMSU
MANUEL DESCRIPTIF
РУКОВОДСТВО ПОЛЬЗОВАТЕЛЯ
ENERGENIE PROGRAMMABLE
КЕРІВНИЦТВО КОРИСТУВАЧА
POWER STRIP

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EG-PMSU and is the answer not in the manual?

Questions and answers

Related Manuals for Energenie EG-PMSU

Summary of Contents for Energenie EG-PMSU

  • Page 1 USER MANUAL HANDBUCH HANDLEIDING EG-PMSU MANUEL DESCRIPTIF РУКОВОДСТВО ПОЛЬЗОВАТЕЛЯ ENERGENIE PROGRAMMABLE КЕРІВНИЦТВО КОРИСТУВАЧА POWER STRIP...
  • Page 2 EG-PMSU ENERGENIE PROGRAMMABLE POWER STRIP PROGRAMMABLE POWER STRIP PROGRAMMIERBARE USB STECKDOSENLEISTE PROGRAMMEERBARE STEKKERDOOS STRIP DE PUISSANCE PROGRAMMABLE ПРОГРАММИРУЕМЫЙ ФИЛЬТР ПИТАНИЯ ПРОГРАМОВАНИЙ ФІЛЬТР ЖИВЛЕННЯ  Do not plug several sockets in line  Do not use if covered  De-energized only if power plug is unplugged ...
  • Page 3 ENERGENIE PROGRAMMABLE POWER STRIP 1. Introduction Congratulations with your purchase of this Energenie Power Manager. Your EG-PMSU is an advanced surge protector with power management features. Four sockets are individually manageable by the computer via USB interface. The sockets can be switched on/off by a timer schedule, by user or different events.

  • Page 4: Specifications

    Maximum current consumed from the computer USB port: 350 mA  Power cord: 1.2 m AWG14  Maximum quantity of EG-PMSU connected to one computer at the same time: no restrictions (only restricted by the maximum allowed quantity of the USB devices) ...

  • Page 5: Hardware Requirements

    EG-PMSU ENERGENIE PROGRAMMABLE POWER STRIP  Working temperature range: from +10 to +40 degrees Celsius  Dimensions: 420 x 60 x 52 mm  Net weight: 0.7 kg 1.3. Hardware requirements  Computer running Windows® 2000/XP/Vista/7/8 is required for using the Power Manager software ...

  • Page 6: Indicators And Controls Of Eg-Pmsu

    EG-PMSU ENERGENIE PROGRAMMABLE POWER STRIP 2. Indicators and controls of EG-PMSU Figure #1 Main rocker switch (Z) with self-restoring fuse and power indicator Socket indicators 1, 2, 3, 4 (lit up when appropriate socket is powered on) Non-manageable socket USB Connector...

  • Page 7: Installation

    2.1. Indicators  Main rocker switch Z with built in self recovering fuse (see Figure #1 above) is lit – this means that EG-PMSU is connected to the power supply and active.  The indicator Socket 1 (2,3,4) (see Figure #1 above) is lit – this means that this particular socket is switched on.

  • Page 8: Getting Started

    EG-PMSU can now be switched on and off by means of the Main rocker switch (Z).  The last socket of EG-PMSU is switched on and off by means of the Main rocker switch (Z) and cannot be managed by the computer – so it’s called non-manageable socket in this manual.

  • Page 9: Power Manager Installation

    NOTE: If the total power consumption (or peak power) of the devices, connected to EG-PMSU exceeds 1800 Watts, the circuit breaker may power EG-PMSU off. In this case, please, remove the excessive load first and then (after 2-3 minutes) press the main rocker switch (Z) to restore the power supply.

  • Page 10: Managing Eg-Pmsu

    EG-PMSU ENERGENIE PROGRAMMABLE POWER STRIP 4.1. Managing EG-PMSU Double click on the socket icon in the system tray or select Open from the popup menu, you will get the windows with device list (see Figure #2 below). Figure #2 Push the Device settings button (bottom right here) to set the device-...
  • Page 11 EG-PMSU ENERGENIE PROGRAMMABLE POWER STRIP Figure #3 Double click on the device and you will get the window of the main control panel shown on the Figure #4 below. All brands and logos are registered trademarks of their respective owners...
  • Page 12 EG-PMSU ENERGENIE PROGRAMMABLE POWER STRIP Figure #4 Double click on each socket will switch it on or off (green color means the socket is switched on; red color means the socket is switched All brands and logos are registered trademarks of their respective owners...
  • Page 13 EG-PMSU ENERGENIE PROGRAMMABLE POWER STRIP off). Click the Settings button for each socket to access the Settings dialog box (see Figure #5 below). Figure #5 You can choose a different device and another socket from the Device and Socket drop down list-boxes.
  • Page 14 EG-PMSU ENERGENIE PROGRAMMABLE POWER STRIP  It is possible to give a name to the device and socket (for example Printer or Scanner) using the Rename button  Check the System tray checkbox if you want to put the icon of the socket into the system tray.

  • Page 15: Setting Up The Hardware Schedule

    EG-PMSU ENERGENIE PROGRAMMABLE POWER STRIP 4.2. Setting up the hardware schedule Using the Hardware schedule button available from the Settings window you can create the hardware timer schedule (see Figure #6 below). To add a new record, click the Add button.
  • Page 16 EG-PMSU ENERGENIE PROGRAMMABLE POWER STRIP  The window Add entry will appear (see Figure #7 below). In the dialog box, specify the required time and the action Figure #7  To edit the record, select it and click the Edit button or just double click on the entry.
  • Page 17 EG-PMSU ENERGENIE PROGRAMMABLE POWER STRIP Figure #8  To remove the record, select it and click the Remove button (see Figure #6 above). You can select multiple entries using Ctrl and Shift keys. You can also remove all entries from the schedule by clicking the Clear button (see Figure #6 above) ...
  • Page 18 EG-PMSU ENERGENIE PROGRAMMABLE POWER STRIP Figure #9  After the schedule record has been created, click the Apply button (see Figure #6 above) to save the hardware timer schedule changes. In case of incorrect entries, these will be highlighted and an error message will appear.
  • Page 19 EG-PMSU ENERGENIE PROGRAMMABLE POWER STRIP  The new event time should be in the future  There can not be a duplicate entry  The total quantity of events can not exceed 16 per socket  The total quantity of events also depends on the total execution period of the schedule ...
  • Page 20 EG-PMSU ENERGENIE PROGRAMMABLE POWER STRIP 4.3. Setting up the software schedule Using the Software schedule button available from the Settings window you can create the software timer schedule (see Figure #10 below). NOTE: the software timer schedule will only be executed if the managing computer is on and the Power Manager is launched.
  • Page 21 EG-PMSU ENERGENIE PROGRAMMABLE POWER STRIP  To add a new task, click the Add button. The Add task window will appear (see Figure #11 below) Figure #11 In the Add task window, check Switch ON time and/or Switch OFF time checkboxes and specify the time to switch the socked on and/or off.
  • Page 22 EG-PMSU ENERGENIE PROGRAMMABLE POWER STRIP uncheck the Enabled checkbox and to enable the task again, re-check the checkbox.  To edit the task, select it (see Figure #10 above) and click the Edit button or just double click on the task. The Edit task window will...

  • Page 23: Setting Up Application Events

    EG-PMSU ENERGENIE PROGRAMMABLE POWER STRIP  To remove the task select it and click the Remove button (see Figure #9 above). You may select multiple tasks using Ctrl and Shift keys. You can also remove all tasks by clicking the Clear button HINT: Use the popup menu which can be activated by the right mouse button click over the table (see Figure #10 above).
  • Page 24 EG-PMSU ENERGENIE PROGRAMMABLE POWER STRIP Figure #13  To add a new program event, click the Add app button. The Add program event dialog will appear (see Figure #14 below) All brands and logos are registered trademarks of their respective owners...
  • Page 25 EG-PMSU ENERGENIE PROGRAMMABLE POWER STRIP Figure #14 Specify the application title and path to it using the Browse (…) button or typing it manually in the Title and Path name fields. If you use the Browse (…) button you can also select a shortcut to the application.
  • Page 26 EG-PMSU ENERGENIE PROGRAMMABLE POWER STRIP NOTE: The On run event will take place when the first window of the selected application is opened. The On exit event will take place when the last window of the application is closed. HINT: Your device is an advanced standby-killer. Using this feature you can for example switch your scanner on/off whenever Photoshop is started/closed.
  • Page 27 EG-PMSU ENERGENIE PROGRAMMABLE POWER STRIP Specify the path to the folder you would like to monitor using the Browse (…) button or typing it manually in the Path name field. Specify the File name mask using wildcard characters: *, ?. Check then On placing and/or On removal checkboxes and select the event and delay.
  • Page 28 EG-PMSU ENERGENIE PROGRAMMABLE POWER STRIP Figure #16  To remove the event, select it and click the Remove button (see Figure #13 above). You can select multiple events using Ctrl and Shift keys. You can also remove all events by clicking the Clear...

  • Page 29: Managing Eg-Pmsu Via Your Own Software

    EG-PMSU ENERGENIE PROGRAMMABLE POWER STRIP 5. Managing EG-PMSU via your own software To let you switch the sockets from your own applications the following command line interface syntax is supported:  pm.exe -[on | off] -device name -socket name Examples: ...

  • Page 30: Troubleshooting

    Check the grounding of EG-PMSU. If inductive load, like florescent lamps or Software reports "Device I/O motors are connected to EG-PMSU, it is request error" after switching recommended to use an extra USB hub to connect EG-PMSU to the managing computer.
  • Page 31 EG-PMSU ENERGENIE PROGRAMMABLE POWER STRIP All brands and logos are registered trademarks of their respective owners...
  • Page 32 EG-PMSU ENERGENIE PROGRAMMABLE POWER STRIP Waste disposal: Entsorgungshinweise: Do not deposit this equipment with the Werfen Sie dieses Gerät nicht in den household waste. Improper disposal can harm Hausmüll. Unsachgemäße Entsorgung kann both the environment and human health. For sowohl der Umwelt als auch der menschlichen...
  • Page 33 EG-PMSU ENERGENIE PROGRAMMABLE POWER STRIP WARRANTY CONDITIONS GARANTIE BEDINGUNGEN The receipt must clearly list the date of purchase Das Kaufdatum und der Gerätetyp sind durch and the part number, in addition it should be eine maschinell erstellte Kaufquittung zu printed. Keep the receipt for the entire warranty belegen.
  • Page 34 EG-PMSU ENERGENIE PROGRAMMABLE POWER STRIP GARANTIE VOORWAARDEN CONDITIONS DE GARANTIE Op de aankoopbon moeten de aankoopdatum en Le talon de garantie doit énumérer clairement la date d'achat et le type d'appareil. productomschrijving duidelijk vermeld staan. Conservez le reçu d'achat pendant toute la durée de la Gelieve de aankoopbon de gehele garantie car elle est nécessaire pour toute réclamation.
  • Page 35 EG-PMSU ENERGENIE PROGRAMMABLE POWER STRIP ГАРАНТИЙНЫЙ ТАЛОН УМОВИ ГАРАНТІЙНОГО ОБСЛУГОВУВАННЯ 1. Гарантийное обслуживание предоставляется в течение 1. Гарантійне обслуговування надається протягом терміну срока гарантии, при наличии правильно и четко заполненного гарантії, при наявності Гарантійного талону, заповненого гарантийного талона, и изделия в полной комплектации.
