Energenie EG-SMS User Manual

Programmable power outlet strip with gsm interface

Advertisement

Quick Links

USER MANUAL
HANDBUCH
HANDLEIDING
EG-SMS
MANUEL DESCRIPTIF
PROGRAMMABLE POWER OUTLET STRIP
РУКОВОДСТВО ПОЛЬЗОВАТЕЛЯ
WITH GSM INTERFACE
КЕРІВНИЦТВО КОРИСТУВАЧА

Advertisement

loading
Need help?

Need help?

Do you have a question about the EG-SMS and is the answer not in the manual?

Questions and answers

Summary of Contents for Energenie EG-SMS

  • Page 1 USER MANUAL HANDBUCH HANDLEIDING EG-SMS MANUEL DESCRIPTIF PROGRAMMABLE POWER OUTLET STRIP РУКОВОДСТВО ПОЛЬЗОВАТЕЛЯ WITH GSM INTERFACE КЕРІВНИЦТВО КОРИСТУВАЧА...
  • Page 2 EG-SMS PROGRAMMABLE POWER OUTLET STRIP WITH GSM INTERFACE PROGRAMMABLE POWER OUTLET STRIP WITH GSM INTERFACE PROGRAMMIER- UND STEUERBARE STECKDOSENLEISTE MIT GSM -ANSCHLUSS PROGRAMMEERBARE POWER OUTLET STRIP MET GSM INTERFACE BOÎTIER COMMANDÉ À DISTANCE ET PROGRAMMABLE AVEC PRISE GSM ПРОГРАММИРУЕМЫЙ УДЛИНИТЕЛЬ С GSM ИНТЕРФЕЙСОМ...
  • Page 3 WITH GSM INTERFACE 1. Introduction Congratulations with your purchase of this Programmable power outlet strip. Your EG-SMS is an advanced power outlet strip with power management features. Four sockets are individually manageable via the GSM interface. The sockets can be switched on/off by a timer schedule, by user or different events.
  • Page 4 EG-SMS PROGRAMMABLE POWER OUTLET STRIP WITH GSM INTERFACE  The manageable sockets can then be switched on and off by the schedule, simple typical applications could be: “switch my peripherals on every working day at 8:50 AM” etc  64-bit password protected secure access ...
  • Page 5: Specifications

    EG-SMS PROGRAMMABLE POWER OUTLET STRIP WITH GSM INTERFACE 1.2. Specifications  Input voltage: 220 – 230 VAC, 50 – 60 Hz  Maximum load: 10 A  Power consumption: up to 4.5 W  GSM 850/900/1800/1900 MHz network support ...
  • Page 6 EG-SMS PROGRAMMABLE POWER OUTLET STRIP WITH GSM INTERFACE 1.3. Hardware requirements  GSM-900 or GSM-1800 network  GSM SIM card  Mobile phone supporting SMS or Smart phone running Android 2.3 OS or newer or iPhone, iPad running iOS 6.0 or newer 1.4.
  • Page 7 EG-SMS PROGRAMMABLE POWER OUTLET STRIP WITH GSM INTERFACE Indicators and controls of the EG-SМS Side panel #2 Figure #1 Non manageable socket Manageable socket 4 Main rocker switch Manageable socket 3 Power indicator Manageable socket 2 Indicator Manageable socket 1...
  • Page 8 EG-SMS PROGRAMMABLE POWER OUTLET STRIP WITH GSM INTERFACE 2.1. Side panel #1 Figure #2 Temperature sensor socket Network status/Schedule Indicator Water/Locker sensors socket Antenna socket Reset Button Password GSM SIM card Button All brands and logos are registered trademarks of their respective owners...
  • Page 9 WITH GSM INTERFACE 2.2. Indicators  Main rocker switch (Figure #1) is lit – this means that EG-SMS is connected to the power supply and active  The indicator Socket 1 (2,3,4) (Figure #1) is lit – this means that this particular socket is switched on ...
  • Page 10 Connect EG-SMS to the wall socket first and connect the GSM antenna  EG-SMS can now be switched on and off by means of the Main rocker switch.  Two (the first and the last) sockets of EG-SMS are marked with the symbol .
  • Page 11 NOTE: If the total power consumption (or peak power) of the  devices, connected to EG-SMS exceeds 2200 Watts, the circuit breaker may power EG-SMS off. In this case, please, remove the excessive load All brands and logos are registered trademarks of their respective owners...
  • Page 12 WITH GSM INTERFACE first and then press the Main rocker switch on to restore the power supply (Figure #3). To be able to use EG-SMS you will now have to complete its configuration. 3.2. Power Manager software installation For initial configuring EG-SMS it needs to carry out the following: ...
  • Page 13 “Password” button. Shortly after that an SMS with same password will be received by the mobile phone. Access password is succesfully applied. The device is ready to work. 4. Operating EG-SMS with simple mobile phone by SMS 4.1 Controlling the sockets. Send SMS with text: PASSWORD200A0B0C0D PASSWORD –...
  • Page 14 EG-SMS PROGRAMMABLE POWER OUTLET STRIP WITH GSM INTERFACE SWITCH – response to the SWITCH command ON /OFF – socket state for socket 1..4 respectively POWER OK – power from power mains is present Example SMS: Gembird12001000001 Device action: switch Socket1 ON, Socket2 OFF, Socket3 OFF, Socket4 ON, Gembird1 is password.
  • Page 15 25 Apr 2013 11:52:44 GMT. ( Time stamp is optional for input ). ТTTTTTTT=1D197951 Note: If EG-SMS is powered off for some hours (more than 2 hours) internal timer can be timed out. Then it shall be set again by this SMS.
  • Page 16: Temperature Sensors

    EG-SMS PROGRAMMABLE POWER OUTLET STRIP WITH GSM INTERFACE For clearing all alarms send SMS to the device: PASSWORD03 Response SMS: ALARMS CLEARED 4.3 Control socket autonomously by WATER, LOCKER, TEMPERATURE sensors First, enable the corresponding sensors and set temperature limits, as it is written in p4.2.
  • Page 17 EG-SMS PROGRAMMABLE POWER OUTLET STRIP WITH GSM INTERFACE SLLL– low temperature limit, in degrees C. S is sign – or +. Example: -001 equals to -1 degree C. SHHH – high temperature limit, in degrees C F – LOCKER sensor is controlling the socket. 1 – yes, 0 - no G –...
  • Page 18 EG-SMS PROGRAMMABLE POWER OUTLET STRIP WITH GSM INTERFACE Response SMS: SENSORS SCHEDULE CLEARED For viewing control socket send SMS to the device: PASSWORD520A A – Socket number , 0 for Socket 1, 1 for Socket 2 , etc. Response SMS: 520A0B0CSLLLSHHH0F0G0H0I 4.4 Monitoring socket sensor states...
  • Page 19 EG-SMS PROGRAMMABLE POWER OUTLET STRIP WITH GSM INTERFACE 4.5 Monitoring enable/disable sensor This SMS message gives response SMS with information about enabled/disabled sensors, response sms, temperature limits and device timestamp: PASSWORD11 Response SMS (example): SENSOR SET: TEMP LOCKER WATER ACKNOWLEDGE ON, RANGE+005+030, TIME78563412...
  • Page 20 Use BACK button to return. If you have LAN or WLAN product, which is tied to account in Energenie service, you can press “Online settings” (Figure 1), then input login and password of that account to control the devices (Figure 2).
  • Page 21 10). Status of all LAN and WLAN in the list can be updated by tapping “Sync” menu, but not EG-SMS devices that need individual SMS sending. The log of commands sent to device, and it’s replies can be opened “Log” menu. (Figure 25) Long-tap invokes pop-up menu of the device (Figure 9).
  • Page 22 Tap sensor info lines or “Device setup” from menu (Figure 12) for configuring sensors and device time. (Figure 13) Note: If EG-SMS is powered off for some hours (more than 2 hours) internal timer can be timed out. Then device time shall be set again.
  • Page 23 EG-SMS PROGRAMMABLE POWER OUTLET STRIP WITH GSM INTERFACE Each socket can be switched according to the change of temperature or if LOCKER, WATER sensors are triggered. (Figure 22,23) Events info of the socket can be also downloaded from device by pressing “Download events”...
  • Page 24 EG-SMS PROGRAMMABLE POWER OUTLET STRIP WITH GSM INTERFACE Figure 1-3 Figure 4-6 All brands and logos are registered trademarks of their respective owners...
  • Page 25 EG-SMS PROGRAMMABLE POWER OUTLET STRIP WITH GSM INTERFACE Figure 7-9 Figure 10-12 All brands and logos are registered trademarks of their respective owners...
  • Page 26 EG-SMS PROGRAMMABLE POWER OUTLET STRIP WITH GSM INTERFACE Figure 13-15 Figure 16-18 All brands and logos are registered trademarks of their respective owners...
  • Page 27 EG-SMS PROGRAMMABLE POWER OUTLET STRIP WITH GSM INTERFACE Figure 19-21 Figure 22-24 All brands and logos are registered trademarks of their respective owners...
  • Page 28 EG-SMS PROGRAMMABLE POWER OUTLET STRIP WITH GSM INTERFACE Figure 25-27 All brands and logos are registered trademarks of their respective owners...
  • Page 29: Troubleshooting

    EG- automatically. SMS should be disconnected. 1) There is no power supply to the EG-SMS and battery is exhausted. Make sure the EG- SMS is connected to the power supply and the rocker switch is switched on.
  • Page 30 EG-SMS PROGRAMMABLE POWER OUTLET STRIP WITH GSM INTERFACE This product is tested and complies with the essential requirements of the laws of member states concerning LVD(2006/95/EC), EMC(2004/108/EC). The CE declaration can be found under www.gembird.eu Dieses Produkt wurde getestet und stimmt mit den grundlegenden Anforderungen der Richtlinie LVD(2006/95/EC), EMC(2004/108/EC) überein.
  • Page 31 EG-SMS PROGRAMMABLE POWER OUTLET STRIP WITH GSM INTERFACE Waste disposal: Entsorgungshinweise: Do not deposit this equipment with the Werfen Sie dieses Gerät nicht in den household waste. Improper disposal can harm Hausmüll. Unsachgemäße Entsorgung kann both the environment and human health. For...
  • Page 32: Warranty Conditions

    EG-SMS PROGRAMMABLE POWER OUTLET STRIP WITH GSM INTERFACE WARRANTY CONDITIONS GARANTIE BEDINGUNGEN The receipt must clearly list the date of purchase Die Garantie beträgt 24 Monate ab and the part number, in addition it should be Verkaufsdatum an den Endverbraucher. Das printed.
  • Page 33: Conditions De Garantie

    EG-SMS PROGRAMMABLE POWER OUTLET STRIP WITH GSM INTERFACE GARANTIE VOORWAARDEN CONDITIONS DE GARANTIE Op de aankoopbon moeten de aankoopdatum en Le talon de garantie doit énumérer clairement la date d'achat et le type d'appareil. productomschrijving duidelijk vermeld staan. Conservez le reçu d'achat pendant toute la durée de la Gelieve de aankoopbon de gehele garantie car elle est nécessaire pour toute réclamation.
  • Page 34 EG-SMS PROGRAMMABLE POWER OUTLET STRIP WITH GSM INTERFACE ГАРАНТИЙНЫЙ ТАЛОН УМОВИ ГАРАНТІЙНОГО ОБСЛУГОВУВАННЯ 1. Гарантийное обслуживание предоставляется в течение 1. Гарантійне обслуговування надається протягом терміну срока гарантии, при наличии правильно и четко заполненного гарантії, при наявності Гарантійного талону, заповненого гарантийного талона, и изделия в полной комплектации.
