Thank you for purchasing WRT-414. This manual guides you on how to install and properly use the
WRT-414 in order to take full advantage of its features.
1.1 Package Contents
Make sure that you have the following items:
•
One WRT-414
•
One AC Power Adapter
•
One User's Manual CD
•
One Quick Installation Guide
•
One External Dipole Antenna
Note:
If any of the above items are missing, contact your supplier for support.
1. 2 Features
Compliant with 802.11g / 802.11b standard
Allow multiple users to share a single Internet connection
Internet Access via Cable or xDSL modem
Access Private LAN Servers from the Public Network
AP / AP Client / WDS / Bridge modes supported
Equipped with four LAN ports (10/100M) and one WAN port (10/100M), Auto-MDI/MDI-X supported
Support DHCP Server for easy setup
System status monitoring including Active DHCP Client, Security Log and Device/Connection
Status
Easy to use Web-based GUI for configuration and management purposes
Remote Management allows configuration and upgrades from a remote site (over the Internet)
DHCP/PPPoE/PPTP/L2TP/Fixed IP allocation
MAC/IP filter access control, URL blocking
SPI firewall + DoS prevention protection
Support UPnP function
Supports 64/128-bit WEP, WPA-PSK, WPA, WPA2 Encryption to protect the wireless data
transmissions
1.4 Specification
Standard
IEEE 802.11g/802.11b Compliant
Signal Type
DSSS (Direct Sequence Spread Spectrum)
Modulation
OFDM/ QPSK / BPSK / CCK
Chapter 1 Introduction
- 1 -
