Planet Networking & Communication WRT-414 User Manual page 44

Enable 802.1x Authentication
After configuration complete, please click "Apply" button to save the configuration. Then you will see a
screen to prompt you the settings are save successfully. You may press "Continue" for configure other
settings or "Apply" to restart WRT-414 with new configuration.
5.4.3.2 802.1x
IEEE 802.1x is an authentication protocol. Every user must use a valid account to login to this Access
Point before accessing the wireless LAN. The authentication is processed by a RADIUS server. This
mode only authenticates user by IEEE 802.1x, but it does not encryption the data during communication.
It is suggested to enable 802.1x and WEP at the same time.
Parameter
Encryption
Enable 802.1x Authentication
RADIUS Server IP Address
RADIUS Server Port
RADIUS Server Password
128-bit WEP: input 26-digit Hex values (in the "A-F", "a-f" and "0-9"
range) or 10-digit ASCII characters as the encryption keys.
Check this box if you want to enable 802.1x authentication with WEP
encryption. You may refer to section 5.4.3.2 to enter the correct setting
of the fields.
Description
If you want to use 802.1x only, keep this setting in "Disable".
Please check this option to enable 802.1x function.
Enter RADIUS Serer IP address.
Leave the default port setting or assign a new port number for this
option.
Please enter the password that is configured in RADIUS Server.
- 38 -
