When the configuration finished please click "OK" to next step or click "Back" to previous step. After
press "OK", you will see a web screen to prompt you the configurations save successfully. Please refer
to section 4.2.7 for the information of this screen.
4.2.6

Telstra Big Pond

Select Telstra Big Pond if you are live in Australia and your ISP requires this protocol to connect to the
Internet. Your ISP should provide all the information required in this section.
Parameters Description
User Name Enter the User Name provided by your ISP for the connection.
Password Enter the Password provided by your ISP for the connection.
User Decide login If you ISP has provide the login server IP address to you, please check this box and
server manually enter the Login Server IP address below.
Login Server Please enter the Login Server IP address here.
When the configuration finished please click "OK" to next step or click "Back" to previous step. After press
"OK", you will see a web screen to prompt you the configurations save successfully. Please refer to
section 4.2.7 for the information of this screen.
4.2.7

Save Settings Successfully

When you press "OK" in above configuration, the settings will be saved and the screen appears as below.
Before WRT-414 restart, the settings are saved, but not function yet. You can also click "Continue" to
configure other settings, this web page will appear when you save the settings in each configuration
screen. Press "Apply" to restart the WRT-414 for the change to take effect immediately.
