1. Input
Input jack socket (TS 6,3" jack) to
connect the guitar to the amplifier.
2. Clean Gain
Sensitivity of the clean and crunch
channel. Since the same knob works
for both channels, the volume of each
one has been
compensate the difference between
them. Though, it's possible to change
the volume balance moving the knob –
it maximum setting the clean channel
might be louder then crunch and the
other way around.
HINT: To set correct volume balance
between clean
between them and turn the knob until
reaching the expected balance.
3. Crunch switch
It allows to switch between clean or
crunch channel.
Both channels share the same knobs:
Gain and Character. When the amp is
LABOGA – The Beast 30 Plus

FRONT PANEL

Combo version :
Head version:
set separately
and crunch, switch
switched to the drive channel, then
pressing
Clean/Crunch
background and the amp stays on the
Drive.
It
unplugged from the Footswitch socket.
When pressed the drive channel is on –
to then the red light is on.
4. Character
This knob is a unique version of tone
control. It is like a 3-band stack in one
knob, so it works as a "tone selector".
Each "Character" setting, from "0" to
"10",
Bass, Middle and Treble knobs.
So, In every position of the knob, a
different tone is obtained - not the
same as the regular guitar "tone"
regulator,
Everything works only for the clean
channel.
HINT: Move the knob from "0" to "10"
and find your best setting. Don't be
afraid of settings close to "0".
this button
channel
works only when
represents different
which only
changes the
only in
the Jack is
setup of
cuts treble.
Page 6
