3. Back Panel

M2TECH
OUT 1 OUT 2
PALMER POWER STATION
BATTERY LOW-NOISE POWER SUPPLY
RATING: 100-240V - 50/60H
AC Z
POWER CONSUMPTION: 60VA
FUSE: 2 x 2.5A Slow BLOW
MADE IN ITALY
!
WA RNING!
NO USER SERVICEABLE PARTS INSIDE
S/N:
REFER ALL SERVICING TO QUALIFIED PERSONNEL
5 5 6 7
5) Outputs. Connect the supply cable provided in the package. Positive is the upper hole,
negative is the lower hole.
6) Charge indicator. Fuses holder. Contains two 2.5A slow blow 5x20mm fuses.
7) Mains socket. Connect the power cord included in the package.
