Chord CAB41PK User Manual

Layout
1. Bass input
2. Master volume control
3. Bass control
4. Middle control
Setting Up and operation
 Your CAB41 bass is supplied with a guitar lead with a 6.3mm jack on each end
 Plug one end into the bass jack socket and the other end into the guitar input on the amplifier (1)
 The bass amplifier is supplied with IEC lead(s) for connecting to the mains
 Connect the IEC at the rear of the amplifier and the mains plug to an appropriate mains outlet

Turn Master volume (2) fully down and set Bass, Middle and Treble controls (3, 4, 5) to the 12 o'clock position
 Switch the power on (8)
 Play the bass with volume and tone controls turned fully up and gradually increase Master volume
 The tone of the bass can be changed by adjusting the Bass, Middle and Treble controls (3, 4, 5)
 A 3.5mm jack Aux input is provided for playing along to a track from an audio player
 Connect a an mp3 player, smart phone or other line level source to the Aux Input and press play
 Use volume controls on the playback device and bass to achieve the best volume balance of both
 If silent practice is preferred, plug headphones in via the other 3.5mm socket, which will mute the speaker
 After use, turn down Master volume and switch off power. Unplug from mains when not in use for long periods
Specifications
Power supply
Output power
Dimensions
Weight
230Vac, 50Hz (IEC) 18W
10Wrms
250 x 280 x 125mm
3.4kg
5. Treble control
6. Headphones output
7. Auxiliary input
8. Power switch
CAB41PK
10W BASS AMPLIFIER
User Manual
Errors and omissions excepted.
Copyright© 2013. AVSL Group Ltd.
