- Page 1 Rotary Tool Kit 135 Watt Operation Manual 3 Year Replacement Warranty RTG-920VK 0209 www.ozito.com.au To view the full range visit:...
- Page 2 SPECIFICATIONS - MODEL NO. RTG-920VK Motor Size: 135W Collet Size: 3.2mm No Load Speed: 8,000 – 30,000 rpm Features: Spindle Lock Accessible Brushes Variable Speed Type: This Rotary Tool has been designed to comply with the following Australian / International Standards and any other applicable standards referenced therein: AS/NZS 3160: 1996 Approval and Test Specification –...
-
Page 3: Safety Instructions
We aim to provide quality tools at an affordable price. We hope you will enjoy using this tool for many years. Your Rotary Tool RTG-920VK has been designed with the hobbyist in mind. It has a wide variety of applications... - Page 4 ELECTRICAL SAFETY (cont.) Note: Double insulation does not take the place of normal safety precautions when operating this tool. The insulation system is for added protection against injury resulting from a possible electrical insulation failure within the tool. Using an Extension Lead Always use an approved extension lead suitable for the power input of this tool.
- Page 5 GENERAL (cont.) 12. Use appropriate tool. The intended use is described in this instruction manual. Do not force small tools or attachments to do the job of a heavy duty tool. The tool will do the job better and safer at the rate for which it was intended.
-
Page 6: Tool Operation
ADDITIONAL SAFETY INSTRUCTIONS FOR ROTARY TOOLS DANGER! Keep hands away from the cutting area. Never use the spindle lock when the machine is operating. Make sure the collet diameter is the same as the shaft diameter of the accessory. TOOL OPERATION On / Off Switch Your tool is supplied with an on / off switch, to turn the tool on depress the “I”... - Page 7 REMOVAL AND INSTALLATION OF ACCESSORIES (cont.) With the spindle lock engaged use the wrench provided to loosen the collet nut. Insert the accessory into the collet nut as far as possible; this will limit runout of the accessory. With the spindle lock engaged finger tighten the collet nut until the accessory shank is gripped by the collet.
- Page 8 REMOVAL AND INSTALLATION OF ACCESSORIES (cont.) High speed cutter, Diamond wheel point and Drill: Material Speed setting Stone, shell Steel Aluminium, brass 6 Plastic Abrassive disc: Material Speed setting Steel Aluminium, brass 3 Plastic Flexible Shaft Warning! Disconnect the plug from the power source before assembling, making any adjustments or changing accessories.
-
Page 9: Maintenance
Replace both at the same time. Note: Ozito Industries will not be responsible for any damage or injuries caused by the repair of the rotary tool by an unauthorised person or by mishandling of... -
Page 10: Caring For The Environment
Reuse of recycled material decreases pollution in the environment. Please recycle packaging where facilities exist. Check with your local council authority for recycling advice. CONTENTS 1 x Rotary Tool RTG-920VK 1 x Extension Rod 1 x Flexible Shaft 1 x Desk Stand... -
Page 11: Warranty
PURCHASED FROM: ________________________________________________ DATE PURCHASED: ________________________________________________ 3 YEAR REPLACEMENT WARRANTY Your Ozito tool is guaranteed for a period of 36 months from the original date of purchase and is intended for DIY (Do it yourself) use only. WARNING The following actions will result in the warranty being void.
