Ozito ACK-PRO Instruction Manual

AIR
CHISEL
10.2mm Shank
INSTRUCTION MANUAL
SPECIFICATIONS
Max Air Pressure: 90psi (6Bar)
Av. Air Consumption: 113l/min (4cfm)
No Load Speed: 4,500 bpm
Chisel Shank (Round): 10.2mm (0.4")
Barrel Stroke: 43mm
Air Inlet: 1/4" BSP
Weight: 1.05kg
ACK-PRO
GENERAL AIR TOOL SAFETY WARNINGS
WARNING! Read all safety warnings and all instructions. Failure to follow the
warnings and instructions may result in electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference. The term "power tool" in the warnings
refers to your mains-operated (corded) power tool or battery-operated (cordless) power tool.
1. Work area safety
a. Keep work area clean and well lit. Cluttered or dark areas invite accidents.
b. Do not operate power tools in explosive atmospheres, such as in the presence of
flammable liquids, gases or dust. Power tools create sparks which may ignite the dust
or fumes.
c. Keep children and bystanders away while operating a power tool. Distractions can
cause you to lose control.
d. Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing
and gloves away from moving parts. Loose clothes, jewellery or long hair can be
caught in moving parts.
e. Check the maximum pressure rating of any tools or accessories that you intend using with
the compressor. The output pressure of the air from the compressor must be regulated so
that it never exceeds the rated pressure of the tool or accessory.
f. Always wear safety goggles or glasses when using the air compressor. Never point the
nozzle of an accessory towards any part of your body or towards another person.
g. Drain the moisture from the tank daily. It will help prevent corrosion.
AIR CHISEL SAFETY WARNINGS
WARNING! Use thick cushioned gloves and limit the exposure time by taking
frequent breaks.
• Vibration caused by the hammer action may be harmful to your hands and arms.
• When removing an accessory from the tool avoid contact with skin and use proper
protective gloves when grasping the bit or accessory. Accessories may be hot after
prolonged use.
• Always wear eye protection and a dust mask for dusty applications and when drilling/
chiselling overhead. Sanding particles can be absorbed by your eyes and inhaled easily
and may cause health complications.
DESCRIPTION OF SYMBOLS
Warning
Wear ear protection
Revolutions or
/min
reciprocation per minute
Read instruction
manual
Wear eye protection
n
o
No load speed
h. Use safety equipment including safety goggles or shield, ear protection, breathing respirator
mask and protective clothing.
i. Air tools should not be used in a potentialy explosive environment.
j. Use safety equipment including safety goggles or shield, ear protection, breathing or
respirator mask and protective clothing.
k. The tool must be used only for its prescribed purpose. Any use other than those mentioned
in this Manual will be considered a case of misuse. The user and not the manufacturer
shall be liable for any damage or injury resulting from such cases of misuse.
WARNING!
In the event that an air line is cut or broken, the air supply must be turned off
at the compressor. A broken air line which is not supported is extremely dangerous and
can whip around very quickly, both with the capability of striking people, and blowing foreign
particles into the air.
Do not attempt to catch the air line but immediately keep bystanders well clear and turn off the air
supply to the hose, turn off the compressor at the On / Off button, and then remove the hose from
the compressor.
This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless they
have been given the supervision or instruction concerning use of the appliance by a person
responsible for their safety.
Children should be supervised to ensure that they do not play with the appliance.
SPARE PARTS
Quick Change Spring SPACKPRO-07
Trigger SPACKPRO-08
Spare parts can be ordered from the Special Orders
Desk at your local Bunnings Warehouse.
For further information, or any parts not listed here, visit
www.ozito.com.au or contact Ozito Customer Service:
Australia 1800 069 486
New Zealand 0508 069 486
Email: enquiries@ozito.com.au
KNOW YOUR PRODUCT
1 Quick Change Spring
2 On/Off Trigger
3 Air Inlet
4 Air Regulator
