- Page 1 COLOR VERIFOCAL DOME CAMERA MODEL: TFD-CSH26AI12/TFD-CSH26AI2412 TFD-CSH38AI12/TFD-CSH38AI2412 Serial No: OPERATING INSTRUCTIONS...
- Page 2 RISK OF ELECTRIC SHOCK CAUTION DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE, REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of un-insulated “dangerous voltage”...
- Page 3 NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to CE regulations. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. The equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications.
- Page 4 The serial number of this product may be found on the top of the unit. You should note the serial number of this unit in the space provided and retain this instruction as a permanent record of your purchase to aid identification in the event of theft.
-
Page 5: Main Features
MAIN FEATURES 1. Lead (Pb) Free RoHS Compliance 2. Equipped with Sony HQ1 DSP 3. 1 / 3 –inch color CCD camera designed for use in video surveillance system. 4. The camera features a super high picture quality of 525 TVL with varifocal auto iris lens, and easy mounting on the ceiling or wall. - Page 6 5. Do not attempt to disassemble the camera. To prevent electric shock, do not remove screws or covers. There are no user-serviceable parts inside. 6. Handle the camera with care. Do not abuse the camera. Avoid striking, shaking, etc. The camera could be damaged by improper handling or storage. 7.
-
Page 7: Major Operating Controls And Their Function
2.5” LCD service monitor TLM-0251i for adjusting the camera image and loop-through this image to another monitor at the same time. 6. Power Cable/Connector Supplies 24Vac or 12Vdc power (TFD-CSH26AI12 and TFD-CSH38AI12 input 12Vdc only) to camera from an external power source. - Page 8 5 – Video cable 6 – Power cable 1 – Dome Base 2 – Pan/Tilt Table 4 – Zoom Lever 3 – Focus Lever...
- Page 9 7. DC LEVEL ADJ: This VR is used for adjusting the iris level of an auto iris lens. 8. AES/OFF Switch: (auto electronic shutter) When an auto iris lens is used, the AES should be off. When a manual iris lens is used: OFF: the shutter speed is1/60 sec (NTSC) ON: the shutter speed will be adjusted automatically from 1/60 to 1/100,000 sec.
- Page 10 8, 9, 10, 11...
-
Page 11: Installation
INSTALLATION Read all the instructions before installation To mount the camera on the drop ceiling 1. From local hardware store procure 3 or 5 of flat head M4 x 30 mm mechanical screws which are matched with the nut thread on the ceiling top plate. - Page 12 -11-...
- Page 13 3. Turn the dome base fully clockwise to fasten the dome camera on the camera mounting plate. 4. Triview wall mount TWM-CH3801 is strong recommended for installing the dome on the wall. This way the camera can be easily adjusted to any angle horizontally and vertically.
- Page 14 -13-...
- Page 15 CONNECTIONS The recommended cable length for 24 Video Output Connection: Vac are: Connect the video output connector Cooper wire size (AWG) Cable length to the DVR, monitor, or other system AWG#24 (0.22mm²) 300 ft (90 m) equipment with the coaxial cable. AWG#22 (0.33mm²) 500 ft (150 m) The recommended maximum cable...
-
Page 16: Image Adjustment
IMAGE ADJUSTMENT 3. Pan/tilt adjustment: Note: To watch the image adjustment, you may Adjust the pan and tilt angle of the connect the camera video output to a checking camera towards what you need to monitor. However, the video output will be watch. -
Page 17: Specifications
Horizontal Resolution: 525 TVL Sensitivity: 0.25 Lux, F1.2 S/N Ratio: More than 50 dB, AGC Off Horizontal Frequency: 15.734 KHz Vertical Frequency: 59.94 Hz Power Supply 12Vdc/0.2A± 5% TFD-CSH26AI12/TFD-CSH38AI12 24Vac or 12Vdc TFD-CSH26AI2412/TFD-CSH38AI2412 Synchronization: Internal AES: On/Off AGC: On/Off -16-... - Page 18 Flicker less: On/Off Lead Free: Video Output: 1.0 Vp-p, 75Ω Lens: Standard f3.8~f9.5 mm/F1.2 Aspherical auto iris Optional f2.6~f6.0 mm/F1.3 Aspherical auto iris Optional f9~f22.0 mm/F2.0 Auto iris Operating Temperature: -10ºC to +50ºC Operating Humidity: 20% to 85% RH (NC) Dimensions: 118 (DIA) x 88 (H) mm Weight:...
