TRIVIEW TFD-S36FI12IR Operating Instructions

Indoor spiral color dome camera with ir illuminators

Advertisement

INDOOR SPIRAL COLOR DOME CAMERA
WITH IR ILLUMINATORS

OPERATING INSTRUCTIONS

CAUTION
RISK OF ELECTRIC
SHOCK DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF
ELECTRIC SHOCK, DO NOT REMOVE COVER
(OR BACK). NO USER-SERVICEABLE PARTS
INSIDE, REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
The lightning flash with arrowhead
symbol, within an equilateral triangle,
is intended to alert the user to the
presence of un-insulated "dangerous
voltage" within the product's
enclosure that may be of sufficient
magnitude to constitute a risk of
electric shock to persons.
The exclamation point within an
equilateral triangle is intended to alert
the user to the presence of important
operating and maintenance (servicing)
instructions in the literature
accompanying the appliance.
WARNING: To prevent fire or electric shock hazard, do not expose this appliance to rain
or moisture.
The apparatus shall not be exposed to dripping or splashing and that no
objects filled with liquids, such as vases, shall be placed on the apparatus.
NOTE: This equipment has been tested and found to
comply with the limits for a Class B digital device,
pursuant to CE regulations. These limits are designed to
provide reasonable protection against harmful interference
when the equipment is operated in a commercial
environment. The equipment generates, uses, and can
radiate radio frequency energy and, if not installed and
used in accordance with the instruction manual, may cause
harmful interference to radio communications.
Operation of this equipment in a residential area is likely to
cause harmful interference in which case the user will be
required to correct the interference at his own expense.
CE Caution: To assure continued compliance, (example –
use only shielded interface cables when connecting to
computer or peripheral devices), any changes or
modifications not expressly approved by the party
responsible for compliance could void the user's authority
to operate this equipment.
The serial number of this product may be found on the
bottom of the unit.
You should note the serial number of this unit in the space
provided and retain this instruction as a permanent record
of your purchase to aid identification in the event of repair.
Model No.
Serial No.
MODEL: TFD-S36FI12IR
