TRIVIEW TFD-2210 Operation Instruction

Vandal Resist IR Dome Camera
OPERATION INSTRUCTION
PRODUCT FEATURES
•
1/3" Sony HAD II CCD
•
540TVL
•
2.8-10mm / F1.2 Varifocal Auto Iris Lens
•
Mechanical IR Push Filter (ICR)
SAFETY PRECAUTIONS
•
The installation should be made by a qualified service person and should be complied with
all local codes.
•
Only use class 2 regulated power supply as 12VDC power source.
•
To prevent fire or electrical shock, UL listed class 2 wiring should be used for the power
supply.
•
Make sure the ceiling / wall is strong enough to support the weight of the camera.
•
Do not attempt to disassemble the camera. There are no user-serviceable parts inside. The
warranty will be voided if the seal is broken.
•
Do not attempt to aim the camera directly at the sun or other extremely bright objects.
This can damage the image sensor.
•
Do not place the camera under the following locations.
1. Extremely high or low temperatures
(Operating temperature: -10°C to +50°C [10°F to 122°F])
2. High levels of humidity and dust
(Operating humidity: max 80% no condensation)
3. Locations where there are large amounts of water vapor and steam.
•
Avoid strong impacts or shocks. The camera could be damaged by improper handling or
storage.
•
Be sure to use the proper screws to mount the camera on the wall or ceiling.
CONTENT LIST
•
TFD-2201 1 pc
•
Operating Instruction 1 pc
•
Torx Wrench 1 pc
Model:
TFD-2210
•
12VDC/24VAC Dual Voltage
•
Dynamic Noise Reduction
•
3-axis design
•
Pigtail cable 1 pc
•
Tapping Screws 3 pcs
•
Plastic Anchors 3 pcs
Version: 20100406
PART DISCRIPTION
1. Far / Near
2. Wide / Tele
3. DC Level
Adjust the IRIS level of the Auto Iris Lens
4. Dip Switches
AES: Automatic Electronic Shutter
Turn off when Auto Iris lens is used
BLC: Backlight Compensation
Turn on when there is a strong backlight to enhance the foreground
AGC: Automatic Gain Control
Gain adjusted from 0 to 26dB automatically
FL: Flickerless
Change the shutter speed to 1/120sec
5. Secondary DC Power Input
6. Service Port
2nd video output for service monitor
7. Power Input
Support 12VDC or 24VAC
8. Video Output
DC LEVEL L.L V.P
F.L NOM
AGC OFF
BLC OFF
AES OFF
