Abocom ARM904 Quick Install Manual

Abocom multi-function wireless router quick installation guide
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Multi-Function Wire-
less Router
Wireless Access Point
Broadband Internet Access
4-Port Switching Hub

Quick Install Guide

This guide covers only the most common
situations. Please refer to the full User Manual
on the CD-ROM if your LAN has any of the
following:
• Router
• Existing DHCP Server
• PCs using Fixed (Static) IP Addresses
M73-APO09-560

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ARM904 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Abocom ARM904

Summary of Contents for Abocom ARM904

  • Page 1: Quick Install Guide

    Multi-Function Wire- less Router Wireless Access Point Broadband Internet Access 4-Port Switching Hub Quick Install Guide This guide covers only the most common situations. Please refer to the full User Manual on the CD-ROM if your LAN has any of the following: •...

  • Page 2: Physical Installation

    Requirements • DSL or Cable modem for broadband Internet access. • Standard Network cables. • TCP/IP network protocol installed on each PC. • Wireless Access Point requires Wireless devices compliant with the IEEE 802.11g specifications. Setup Physical Installation 1. Ensure the Wireless Router and the DSL/Cable modem are powered OFF before commencing.
  • Page 3 4. Connect the supplied Power Adapter and power on. 5. Check the LEDs • The Power, Internet, and WLAN LEDs should be ON. • For each active LAN (PC) connection, the LAN LED should be ON. Configuration The Wireless Router can "Plug and Play" if your DSL/Cable modem connec- tion uses only a dynamic IP address.

  • Page 4: Manual Configuration

    Manual Configuration 1. Start your PC. If it is already started, restart it. It will then obtain an IP Address from the Wireless Router's DHCP Server. 2. Start your WEB browser. In the Address box, enter the following: The default user name is 〝admin〞, the default password is left blank. 3.
  • Page 5 PC Setup - Windows TCP/IP Setup • If using the default Wireless Router settings, and the default Win- dows TCP/IP settings, no changes need to be made. • If using a specified (fixed) IP address on your PC, refer to the user man- ual for details of the required changes: •...

  • Page 6: Internet Access

    4. The option "Obtain an IP address automatically" should be selected, as shown above. Internet Access For Windows 9x/ME/2000 1. Select Start Menu - Settings - Control Panel - Internet Options. 2. Select the Connection tab, and click the Setup button. 3.
  • Page 7 For Windows XP 1. Select Start Menu - Control Panel - Network and Internet Connections. 2. Select Set up or change your Internet Connection. 3. Select the Connection tab, and click the Setup button. 4. Cancel the pop-up "Location Information" screen. 5.

  • Page 8: Macintosh Setup

    Macintosh Setup Internet Access 1. Open the TCP/IP Control Panel. 2. Select Ethernet from the Connect via pop-up menu. 3. Select Using DHCP Server from the Configure pop-up menu. The DHCP Client ID field can be left blank. 4. Close the TCP/IP panel, saving your settings. Note: If using manually assigned IP addresses instead of DHCP, the required changes are:...
  • Page 9 Linux Setup using X Windows Internet Access Follow this procedure to set your system to act as a DHCP client, obtaining an IP Address and related data from the Wireless Router's DHCP Server. 1. Start your X Windows client. 2. Select Control Panel - Network 3.

  • Page 10: Wireless Access Point Setup

    Wireless Access Point Setup In order to use the Access Point, other Wireless devices must use the same SSID and WEP settings as the Wireless Router. The Wireless Router's default settings are as follows. Setting Wireless Router SSID Default value: Untitled This may be changed on the Wireless screen, on the Wireless Router's main menu.
