Summary of Contents for Vivitek D91X Series

  • Page 2 Copyright This publication, including all photographs, illustrations and software, is protected under international copyright laws, with all rights reserved. Neither this manual, nor any of the material contained herein, may be reproduced without written consent of the author. © Copyright 2013 Disclaimer The information in this document is subject to change without notice.

  • Page 3: Important Safety Information

    DLP Projector—User’s Manual Important Safety Information Important: It is strongly recommended that you read this section carefully before using the projector. These safety and usage instructions will ensure that you enjoy many years of safe use of the projector. Keep this manual for future reference. Symbols Used Warning symbols are used on the unit and in this manual to alert you of hazardous situations.

  • Page 4: Projector Installation Notice

    Preface Projector Installation Notice  Place the projector in a horizontal position The tilt angle of the projector should not exceed 15 degrees, nor should the projector be installed in any way other than the desktop and ceiling mount, otherwise lamp life could decrease dramatically, and may lead to other unpredictable damages.
  • Page 5 DLP Projector—User’s Manual Verify Installation Location  To supply power, the 3-blade (with earthing lead) socket should be used to ensure proper grounding and equalized ground potential for all of the equipment in the Projector System.  The power code provided with the Projector should be used. In case of any missing item, other qualified 3-blade (with earthing lead) power cord can be used as substitution;...
  • Page 6 Preface Power Safety  Only use the supplied power cord.  Do not place anything on the power cord. Place the power cord where it will not be in the way of foot traffic.  Remove the batteries from the remote control when storing or not in use for a prolonged period. Replacing the Lamp Replacing the lamp can be hazardous if done incorrectly.

  • Page 7: Main Features

    DLP Projector—User’s Manual Main Features  Lightweight unit, easy to pack away and transport.  Compatible with all major video standards including NTSC, PAL, and SECAM.  A high brightness rating allows for presentations in daylight or in lit rooms. ...

  • Page 8: Table Of Contents

    Preface Table of Contents GETTING STARTED..............................1 .............................1 ACKING HECKLIST ..........................2 IEWS OF ROJECTOR ARTS Front-right View ...............................2 Top view—On-screen Display (OSD) buttons and LEDs................3 Rear view.................................4 Bottom view ..............................6 .............................7 EMOTE ONTROL ARTS ........................9 EMOTE ONTROL PERATING ANGE .......................9 ROJECTOR AND EMOTE ONTROL UTTONS...
  • Page 9 DLP Projector—User’s Manual SPECIFICATIONS..............................55 ..............................55 PECIFICATIONS ......................57 ROJECTION ISTANCE VS ROJECTION Projection Distance and Size Table ......................57 ............................59 IMING ABLE ............................61 ROJECTOR IMENSIONS REGULATORY COMPLIANCE ...........................62 FCC W ..............................62 ARNING ................................62 ANADA .............................62 AFETY ERTIFICATIONS APPENDIX I .................................63 RS-232C P ............................63 ROTOCOL —...

  • Page 10: Getting Started

    DLP Projector—User’s Manual ETTING TARTED Packing Checklist Carefully unpack the projector and check that the following items are included: DLP P ROJECTOR WITH EMOTE CONTROL CABLE OWER CORD AAA B WITH ATTERIES CD-ROM ARRYING CASE UICK TART UIDE ARRANTY ’ PTIONAL S MANUAL Contact your dealer immediately if any items are missing, appear damaged, or if the unit does not work.

  • Page 11: Views Of Projector Parts

    DLP Projector—User’s Manual Views of Projector Parts Front-right View ABEL ESCRIPTION EE PAGE IR receiver Receive IR signal from remote control Lens Projection Lens Focus ring Focuses the projected image Zoom ring Enlarges the projected image See Top view—On-screen Display (OSD) buttons Function keys and LEDs.

  • Page 12: Top View-On-Screen Display (Osd) Buttons And Leds

    DLP Projector—User’s Manual Top view—On-screen Display (OSD) buttons and LEDs ABEL ESCRIPTION EE PAGE MENU Opens and exits OSD menus Navigates in the OSD Quick Menu – For Keystone SOURCE Enter the Source menu Navigates and changes settings in the OSD Enter or confirm highlighted OSD menu item AUTO Optimizes image size, position, and resolution...

  • Page 13: Rear View

    DLP Projector—User’s Manual Rear view 3 4 5 6 7 8 ABEL ESCRIPTION EE PAGE AC IN Connect the POWER cable VGA IN Connect the RGB cable from a computer VGA IN Connect the RGB cable from a computer Connect the USB cable from a computer (USB) VGA OUT Connect the RGB cable to a display...
  • Page 14 DLP Projector—User’s Manual Note: If your video equipment has both S-VIDEO and RCA jacks (composite video) connect to the S-VIDEO connector. S-VIDEO provides a better quality signal. Warning: As a safety precaution, disconnect all power to the projector and connecting devices before making connections.

  • Page 15: Bottom View

    DLP Projector—User’s Manual Bottom view ABEL ESCRIPTION EE PAGE Contact your dealer for information on mounting the projector on a Ceiling support holes ceiling Tilt adjustor Rotate adjuster lever to adjust angle position. Note: When installing, ensure that you use only UL Listed ceiling mounts. For ceiling installations, use approved mounting hardware and M4 screws with a maximum screw depth of 12 mm (0.47 inch).

  • Page 16: Remote Control Parts

    DLP Projector—User’s Manual Remote Control Parts Important: 1. Avoid using the projector with bright fluorescent lighting turned on. Certain high-frequency fluorescent lights can disrupt remote control operation. 2. Be sure nothing obstructs the path between the remote control and the projector. If the path between the remote control and the projector is obstructed, you can bounce the signal off certain reflective surfaces such as projector screens.
  • Page 17 DLP Projector—User’s Manual ABEL ESCRIPTION EE PAGE IR transmitter Transmits signals to projector Status LED Lights when the remote control is used Laser Press to operate the on-screen pointer Up arrow when connected through USB to a PC Right Right arrow when connected through USB to a PC Down Down arrow when connected through USB to a PC Page Down...

  • Page 18: Remote Control Operating Range

    DLP Projector—User’s Manual Remote Control Operating Range The remote control uses infrared transmission to control the projector. It is not necessary to point the remote directly at the projector. Provided you are not holding the remote perpendicular to the sides or the rear of the projector, the remote will function well within a radius of about 7 meters (23 feet) and 15 degrees above or below the projector level.

  • Page 19: Inserting The Remote Control Batteries

    DLP Projector—User’s Manual Inserting the Remote Control Batteries Remove the battery compartment cover by sliding the cover in the direction of the arrow. Insert the battery with the positive side facing up. Replace the cover. Caution: 1. Only use AAA batteries (Alkaline batteries are recommended). 2.

  • Page 20: Setup And Operation

    DLP Projector—User’s Manual ETUP AND PERATION Starting and Shutting down the Projector Connect the power cord to the projector. Connect the other end to a wall outlet. POWER LED on the projector light. Turn on the connected devices. Ensure the POWER LED not a flashing.
  • Page 21 DLP Projector—User’s Manual When the “Power Off? /Press Power again” message appears, press the POWER button. The projector turns off. Caution: 1. Be sure to remove the lens cap before starting projector. 2. Do not unplug the power cord until the POWER LED stops flashing–indicating the projector has cooled down.

  • Page 22: Setting An Access Password (Security Lock)

    DLP Projector—User’s Manual Setting an Access Password (Security Lock) You can use the four (arrow) buttons to set a password and prevent unauthorized use of the projector. When enabled, the password must be entered after you power on the projector. (See Navigating the OSD on page 17 and Setting the OSD Language on page 18 for help on using OSD menus.) Important: Keep the password in a safe place.
  • Page 23 DLP Projector—User’s Manual You can use the cursor buttons ▲▼◄► either on keypad or IR remote control for password entry. You can use any combination including the same arrow five times, but not less than five. Press the cursor buttons in any order to set the password.

  • Page 24: Adjusting The Projector Level

    DLP Projector—User’s Manual Adjusting the Projector Level Take note of the following when setting up the projector:  The projector table or stand should be level and sturdy.  Position the projector so that it is perpendicular to the screen. ...

  • Page 25: Adjusting The Zoom, Focus And Keystone

    DLP Projector—User’s Manual Adjusting the Zoom, Focus and Keystone Use the Image-zoom control (on the projector only) to resize the projected image and screen size Use the Image-focus control (on the projector only) to sharpen the projected image Use the KEYSTONE buttons (on the projector or the remote control) to correct...

  • Page 26: On-Screen Display (Osd) Menu Settings

    DLP Projector—User’s Manual (OSD) M CREEN ISPLAY ETTINGS OSD Menu Controls The projector has an OSD that lets you make image adjustments and change various settings. Navigating the OSD You can use the remote control cursor buttons to navigate and make changes to the OSD. 1.

  • Page 27: Setting The Osd Language

    DLP Projector—User’s Manual Setting the OSD Language Set the OSD language to your preference before continuing. 1. Press the MENU button. Press the cursor ◄► button to navigate to Settings 1. Press the cursor ▲▼ button to move to the Advanced 1 menu. 2.

  • Page 28: Osd Menu Overview

    DLP Projector—User’s Manual OSD Menu Overview Use the following illustration to quickly find a setting or determine the range for a setting. Image Display Mode Presentation, Bright, Game, Movie, TV, sRGB, Blackboard, User Brightness Contrast Computer Horizontal Position Vertical Position Frequency Tracking Auto Image...

  • Page 29: Image Menu

    DLP Projector—User’s Manual Image Menu Attention ! All of display mode parameters when changed will be saved to user mode. Press the MENU button to open the OSD menu. Press the cursor ◄► button to move to the Image Menu. Press the cursor ▲▼ button to move up and down in the Image menu. Press ◄► to enter and change values for settings.

  • Page 30: Computer Menu

    DLP Projector—User’s Manual Computer Menu Press the MENU button to open the OSD menu. Press ◄► to move to the Image menu. Press ▲▼ to move to the Computer menu and then press Enter or ►. Press ▲▼ to move up and down in the Computer menu.

  • Page 31: Advanced Feature

    DLP Projector—User’s Manual Advanced Feature Press the Menu button to open the OSD menu. Press ◄► to move to the Image menu. Press ▼▲ to move to the Advanced menu and then press Enter or ►. Press ▼▲ to move up and down in the Advanced menu.

  • Page 32: Color Manager

    DLP Projector—User’s Manual Color Manager Press the Menu button to open the OSD menu. Press ◄► to move to the Image menu. Press ▼▲ to move to the Color Manager menu and then press Enter or ►. Press ▼▲ to move up and down in the Color Manager menu.

  • Page 33: Settings 1 Menu

    DLP Projector—User’s Manual Settings 1 Menu Press the MENU button to open the OSD menu. Press the cursor ◄► button to move to the Settings 1 menu. Press the cursor ▲▼ button to move up and down in the Settings 1 menu. Press ◄►...

  • Page 34: Audio

    DLP Projector—User’s Manual Audio Press the Menu button to open the OSD menu. Press ◄► to move to the Settings 1 menu. Press ▼▲ to move to the Audio menu and then press Enter or ►. Press ▼▲ to move up and down in the Audio menu.

  • Page 35: Advanced 1 Feature

    DLP Projector—User’s Manual Advanced 1 Feature Press the Menu button to open the OSD menu. Press ◄► to move to the Settings 1 menu. Press ▲▼ to move to the Advanced 1 menu and then press Enter or ►. Press ▲▼ to move up and down in the Advanced 1 menu.
  • Page 36 DLP Projector—User’s Manual 3D Setting ESCRIPTION Press the cursor ◄► button to enter and select different 3D mode. 3D Sync Invert Press the cursor ◄► button to enter and enable or disable 3D Sync Invert. 3D Format Press the cursor ◄► button to enter and enable or disable different 3D Format. Note: 1.

  • Page 37: Advanced 2 Feature

    DLP Projector—User’s Manual Advanced 2 Feature Press the Menu button to open the OSD menu. Press ◄► to move to the Settings 1 menu. Press ▲▼ to move to the Advanced 2 menu and then press Enter or ►. Press ▲▼ to move up and down in the Advanced 2 menu.

  • Page 38: Settings 2 Menu

    DLP Projector—User’s Manual Settings 2 Menu Press the MENU button to open the OSD menu. Press the cursor ◄► button to move to the Settings 2 menu. Press the cursor ▲▼ button to move up and down in the Settings 2 menu. ESCRIPTION Press the cursor ◄►...

  • Page 39: Status

    DLP Projector—User’s Manual Status Press the cursor ▲▼ button to move up and down in the Settings 2 menu. Select the Status menu and press Enter or ► to enter. ESCRIPTION Active Source Display the activated source. Displays resolution/video information for RGB source and color standard for Video Video Information source.

  • Page 40: Advanced 1 Feature

    DLP Projector—User’s Manual Advanced 1 Feature Press the Menu button to open the OSD menu. Press ◄► to move to the Settings 2 menu. Press ▲▼ to move to the Advanced 1 menu and then press Enter or ►. Press ▲▼ to move up and down in the Advanced 1 menu.
  • Page 41 DLP Projector—User’s Manual Lamp Hour Reset Please refer to Resetting the Lamp on page 47 to reset the lamp hour counter. Network ESCRIPTION Network State Displays the network connection status. Press ◄► to turn DHCP On or Off. DHCP Note: If you select DHCP Off, complete the IP Address, Subnet Mask, Gateway, and DNS fields.
  • Page 42 DLP Projector—User’s Manual LAN_RJ45 Wired LAN Terminal functionalites Remote control and monitoring of a projector from a PC (or Laptop) via wired LAN is also possible. Compatibility with Crestron / AMX (Device Discovery) / Extron control boxes enables not only collective projector management on a network but also management from a control panel on a PC (or Laptop) browser screen.
  • Page 43 DLP Projector—User’s Manual LAN_RJ45 1. Connect an RJ45 cable to RJ45 ports on the projector and the PC (Laptop). 2. On the PC (Laptop), select Start → Control Panel → Network Connections. — 34 —...
  • Page 44 DLP Projector—User’s Manual 3. Right-click on Local Area Connection, and select Properties. 4. In the Properties window, select the General tab, and select Internet Protocol (TCP/IP). 5. Click Properties. 6. Click Use the following IP address and fill in the IP address and Subnet mask, then click OK. –...
  • Page 45 DLP Projector—User’s Manual 7. Press the Menu button on the projector. Select Settings2→ Advanced1 → Network After getting into Network, input the following:  DHCP: Off  IP Address: 10.10.10.10  Subnet Mask: 255.255.255.0  Gateway: 0.0.0.0  DNS Server: 0.0.0.0 10.
  • Page 46 DLP Projector—User’s Manual ATEGORY NPUT ENGTH IP Address Crestron Control IP ID Port Projector Name Projector Location Assigned To DHCP (Enabled) (N/A) IP Address Network Configuration Subnet Mask Default Gateway DNS Server Enabled (N/A) User Password New Password Confirm Enabled (N/A) Admin Password New Password...
  • Page 47 DLP Projector—User’s Manual Preparing Email Alerts 1. Make sure that user can access the homepage of LAN RJ45 function by web browser (for ex- ample, Microsoft Internet Explorer v6.01/v8.0). 2. From the Homepage of LAN/RJ45, click Alert Settings. 3. By default, these input boxes in Alert Settings are blank. —...
  • Page 48 DLP Projector—User’s Manual 4. For Sending alert mail, input the following:  T he SMTP field is the mail server for sending out email (SMTP protocol). This is a required field. 　  T he To field is the recipient’s email address (for example, the projector administrator). This is a 　...
  • Page 49 DLP Projector—User’s Manual RS232 by Telnet Function Besides projector connected to RS232 interface with “Hyper-Terminal” communication by dedicated RS232 command control, there is alternative RS232 command control way, so called “RS232 by TELNET” for LAN/RJ45 interface. Quick Start-Guide for “RS232 by TELNET” Check and get the IP-Address on OSD of the projector.
  • Page 50 DLP Projector—User’s Manual Input the command format like the below: telnet ttt.xxx.yyy.zzz 23 (“Enter” key pressed) (ttt.xxx.yyy.zzz: IP-Address of the projector) If Telnet-Connection ready, and user can have RS232 command input, then “Enter” key pressed, the RS232 command will be workable. How to have TELNET enabled in Windows VISTA / 7 By default installation for Windows VISTA, “TELNET”...
  • Page 51 DLP Projector—User’s Manual Select “Turn Windows features on or off” to open Have “Telnet Client” option checked, then press “OK” button. Specsheet for “RS232 by TELNET” : 1. Telnet: TCP 2. Telnet port: 23 (for more detail, kindly please get contact with the service agent or team) 3.

  • Page 52: Advanced 2 Feature

    DLP Projector—User’s Manual Advanced 2 Feature Press the Menu button to open the OSD menu. Press ◄► to move to the Settings 2 menu. Press ▲▼ to move to the Advanced 2 menu and then press Enter or ►. Press ▲▼ to move up and down in the Advanced 2 menu.
  • Page 53 DLP Projector—User’s Manual Source Filter Press the ENTER button to enter the Source Filter sub menu. ESCRIPTION HDMI Press the cursor ◄► button to enter and enable or disable the HDMI source. Press the cursor ◄► button to enter and enable or disable the DisplayPort source. VGA1 Press the cursor ◄►...

  • Page 54: Maintenance And Security

    DLP Projector—User’s Manual AINTENANCE AND ECURITY Replacing the Projection Lamp The projection lamp should be replaced when it burns out. It should only be replaced with a certified replacement part, which you can order from your local dealer. Important: a. The projection lamp used in this product contains a small amount of mercury. b.
  • Page 55 DLP Projector—User’s Manual Remove the lamp compartment cover. Remove the three screws from the lamp module. Lift the module handle up. Pull firmly on the module handle to remove the lamp module. Reverse steps 1 to 5 to install the new lamp module.

  • Page 56: Resetting The Lamp

    DLP Projector—User’s Manual Resetting the Lamp After replacing the lamp, you should reset the lamp hour counter to zero. Refer to the following: Press the MENU button to open the OSD menu. Press the cursor ◄► button to move to the Settings 2 menu. Press the cursor button to move down to Advanced 1 and press enter.

  • Page 57: Cleaning The Projector

    DLP Projector—User’s Manual Cleaning the Projector Cleaning the projector to remove dust and grime will help ensure trouble-free operation. Warning: 1. Be sure to turn off and unplug the projector at least 30 minutes before cleaning. Failure to do so could result in a severe burn.

  • Page 58: Using The Kensington ® Lock & Using The Security Bar

    DLP Projector—User’s Manual ® Using the Kensington Lock & Using the Security Bar ® Using the Kensington Lock If you are concerned about security, attach the projector to a permanent object with the Kensington slot and a security cable. Note: Contact your vendor for details on purchasing a suitable Kensington security cable.

  • Page 59: Troubleshooting

    DLP Projector—User’s Manual ROUBLESHOOTING Common problems and solutions These guidelines provide tips to deal with problems you may encounter while using the projector. If the problem remains unsolved, contact your dealer for assistance. Often after time spent troubleshooting, the problem is traced to something as simple as a loose connection.

  • Page 60: Led Error Messages

    DLP Projector—User’s Manual LED Error Messages OWER RROR ESSAGES Lamp Ready Start Flashing Cooling Flashing Over Temperature T1 error 3 blinks 1 blinks Thermal Break Sensor error 4 blinks G794 error 4 blinks 4 blinks Lamp fail 5 blinks Ballast temp over 5 blinks 1 blinks Ballast circuit short...

  • Page 61: Lamp Problems

    DLP Projector—User’s Manual 2. Press the Auto button on the remote control. 3. Ensure the projector-to-screen distance is within the specified range. 4. Check that the projector lens is clean. Problem: The image is wider at the top or bottom (trapezoid effect) 1.

  • Page 62: Audio Problems

    DLP Projector—User’s Manual Audio Problems Problem: There is no sound 1. Adjust the volume on the remote control. 2. Adjust the volume of the audio source. 3. Check the audio cable connection. 4. Test the source audio output with other speakers. 5.

  • Page 63: Hdmi Q & A

    DLP Projector—User’s Manual HDMI Q & A Q. What is the difference between a “Standard” HDMI cable and a “High-Speed” HDMI cable? Recently, HDMI Licensing, LLC announced that cables would be tested as Standard or High- Speed cables. ˙Standard (or “category 1”) HDMI cables have been tested to perform at speeds of 75Mhz or up to 2.25Gbps, which is the equivalent of a 720p/1080i signal.

  • Page 64: Specifications

    DLP Projector—User’s Manual PECIFICATIONS Specifications Model D910HD D912HD Display type TI DMD 0.65" 1080p Resolution 1080p 1920x1080 Projection distance 1 m~ 10 m Projection screen size 23.5" ~ 300" Projection lens Manual Focus/Manual Zoom Zoom ratio 1.2x Vertical keystone +/- 40 Degree Projection methods Front, Rear, Desktop/Ceiling (Rear, Front) VGA, SVGA, XGA, WXGA, SXGA, SXGA+, UXGA, WUXGA, Mac...
  • Page 65 DLP Projector—User’s Manual Specifications Model D865W D867 Display type TI DMD 0.65" WXGA TI DMD 0.55" XGA Resolution WXGA 1280x800 XGA 1024x768 Projection distance 1.2 m~ 10 m Projection screen size 25.9" ~ 324.97" Projection lens Manual Focus/Manual Zoom Zoom ratio 1.1x 1.2x Vertical keystone...

  • Page 66: Projection Distance Vs. Projection Size

    DLP Projector—User’s Manual Projection Distance vs. Projection Size Projection Distance and Size Table D910HD / D912HD ROJECTION ROJECTION MAGE IAGONAL ISTANCE ISTANCE MAGE IDTH MAGE IGHT FFSET ( MM ) （ ） （MM） （MM） INCH INCH INCH 52.29 29.42 2098.7 2550.3 112.1 61.01...
  • Page 67 DLP Projector—User’s Manual D865W ROJECTION ROJECTION MAGE IAGONAL ISTANCE ISTANCE MAGE IDTH MAGE IGHT FFSET （MM） （MM） （ ） ( MM ) INCH INCH INCH 50.9 31.8 1990.2 2209.9 113.1 59.4 37.1 2321.9 2578.2 131.9 61.1 38.2 2388.3 2651.9 135.7 67.8 42.4 2653.6...

  • Page 68: Timing Mode Table

    DLP Projector—User’s Manual Timing Mode Table DP/HDMI OMPOSITE IGNAL ESOLUTION OMPONENT ( KH IDEO NALOG IGITAL NTSC 15.734 ○ － － － － PAL/SECAM 15.625 ○ － － － － 720 x 400 31.5 70.1 ○ ○ － － VESA 720 x 400 37.9 85.04...
  • Page 69 DLP Projector—User’s Manual DP/HDMI OMPOSITE IGNAL ESOLUTION OMPONENT ( KH IDEO NALOG IGITAL 1440 x 900 55.9 ○ ○ － － 1440 x 900 70.6 ○ ○ － － 1600 x1200 ○ ○ － － 1680 x 1050 64.7 59.9 ○...

  • Page 70: Projector Dimensions

    DLP Projector—User’s Manual Projector Dimensions – 61 –...

  • Page 71: Regulatory Compliance

    DLP Projector—User’s Manual EGULATORY OMPLIANCE FCC Warning This equipment has been tested and found to comply with the limits for a Class B digital device pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.

  • Page 72: Rs-232C Protocol

    DLP Projector—User’s Manual PPENDIX RS-232C Protocol RS232 Setting Baud rate: 9600 Parity None check: Data bit: Stop bit: Flow None Control Minimum delay for next command: 1ms Control Command Structure Header code Command code Data code End code Command Data ASCII ‘V’...

  • Page 73: Command Group 01

    DLP Projector—User’s Manual Command Group 01 ASCII Function Description Return Value VXXG0101 56h Xh Xh 47h 30h 31h 30h 31h 0Dh Get Brightness n=0~100 Pn/F VXXS0101n 56h Xh Xh 53h 30h 31h 30h 31h nh 0Dh Set Brightness n=0~100 VXXG0102 56h Xh Xh 47h 30h 31h 30h 32h 0Dh Get Contrast n=0~100...

  • Page 74: Command Group 03

    DLP Projector—User’s Manual Command Group 03 ASCII Function Description Return Value 0:Fill 1:4:3 2:16:9 VXXG0301 56h Xh Xh 47h 30h 33h 30h 31h 0Dh Get Scaling Pn/F 3:Letter Box 4:Native 5:2.35:1 0:Fill 1:4:3 2:16:9 VXXS0301n 56h Xh Xh 53h 30h 33h 30h 31h nh 0Dh Set Scaling 3 Letter Box 4:Native 5:2.35:1...

  • Page 75: Function Description

    DLP Projector—User’s Manual Command Group 03 ASCII Function Description Return Value 0:Off VXXG0315 56h Xh Xh 47h 30h 33h 31h 35h 0Dh 1:DLP-Link Pn/F 2:IR 0:Off VXXS0315n 56h Xh Xh 53h 30h 33h 31h 35h nh 0Dh 3D 1:DLP-Link 2:IR 0:Off VXXG0316 56h Xh Xh 47h 30h 33h 31h 36h 0Dh...
