  • Page 2 Copyright This publication, including all photographs, illustrations and software, is protected under international copy- right laws, with all rights reserved. Neither this manual, nor any of the material contained herein, may be reproduced without written consent of the author. © Copyright 2012 Disclaimer The information in this document is subject to change without notice.
  • Page 3 — ’ — ’ — ’ Important Safety Information Important: It is strongly recommended that you read this section carefully before using the projector. These safety and usage instructions will ensure that you enjoy many years of safe use of the projector. Keep this manual for future reference.
  • Page 4 Projector Installation Notice Place the projector in a horizontal position The tilt angle of the projector should not exceed 15 degrees, nor should the projector be in- stalled in any way other than the desktop and ceiling mount, otherwise lamp life could decrease dramatically, and may lead to other unpredictable damages.
  • Page 5 — ’ — ’ — ’ Verify Installation Location Verify if the voltage is stable, grounded properly and there is no electricity leakage. Measure total power consumption which should not higher the safety capacity and avoid safety is- sue and short circuit. Turn on Altitude Mode when located in high altitude areas The projector can only be installed upright or inverted.
  • Page 6 Power Safety Only use the supplied power cord. Do not place anything on the power cord. Place the power cord where it will not be in the way of foot traffic. Remove the batteries from the remote control when storing or not in use for a prolonged period. Replacing the Lamp Replacing the lamp can be hazardous if done incorrectly.
  • Page 7 — ’ — ’ — ’ Main Features • Lightweight unit, easy to pack away and transport. • Compatible with all major video standards including NTSC, PAL, and SECAM. • A high brightness rating allows for presentations in daylight or in lit rooms. •...

  • Page 8: Table Of Contents

    Table of Contents GETTING STARTED................................1 ................................1 ACKING HECKLIST ............................... 2 IEWS OF ROJECTOR ARTS Front-right View ................................2 Top view—On-screen Display (OSD) buttons and LEDs..................3 Rear view..................................4 Bottom view................................... 5 ..............................6 EMOTE ONTROL ARTS ..........................8 EMOTE ONTROL PERATING...
  • Page 9 — ’ — ’ — ’ ................................52 UDIO ROBLEMS ..........................52 AVING THE ROJECTOR ERVICED SPECIFICATIONS ................................53 ................................. 53 PECIFICATIONS ........................54 ROJECTION ISTANCE VS ROJECTION Projection Distance and Size Table......................... 54 ................................ 55 IMING ABLE ..............................57 ROJECTOR IMENSIONS REGULATORY COMPLIANCE............................

  • Page 10: Getting Started

    ETTING TARTED Packing Checklist Carefully unpack the projector and check that the following items are included: DLP P ROJECTOR EMOTE CONTROL CABLE OWER CORD OMPONENT (WITH TWO AAA DAPTER PTIONAL BATTERIES) CD-ROM ARRYING CASE ARRANTY ’ S MANUAL Contact your dealer immediately if any items are missing, appear damaged, or if the unit does not work. It is recommend that you keep the original packing material should you ever need to return the equipment for warranty service.

  • Page 11: Views Of Projector Parts

    — ’ — ’ — ’ Views of Projector Parts Front-right View ABEL ESCRIPTION EE PAGE Height-adjuster button Push to release height adjuster Height adjuster Adjusts level of projector Lens cap Protect lens when not in use Lens Projection Lens IR receiver Receive IR signal from remote control Focus ring...

  • Page 12: Top View-On-Screen Display (Osd) Buttons And Leds

    Top view—On-screen Display (OSD) buttons and LEDs ABEL ESCRIPTION PAGE Turns the projector On or Off. (Power button) BLANK Displays a blank screen and mutes audio ◄ (Left cursor) / Navigates and changes settings in the OSD Volume Quick Menu – For Volume Enter Enter or confirm highlighted OSD menu item MENU...

  • Page 13: Rear View

    — ’ — ’ — ’ Rear view 9 10 11 ABEL ESCRIPTION EE PAGE AC IN Connect the POWER cable (USB) Connect the USB cable from a computer Connect the RGB cable to a display VGA OUT (Loop Thru only for VGA IN-1) Connect a LAN cable from Ethernet VGA IN –...

  • Page 14: Bottom View

    Bottom view ABEL ESCRIPTION EE PAGE Tilt adjustor Rotate adjuster lever to adjust angle position. Contact your dealer for information on mounting the projector on a Ceiling support holes ceiling Adjuster drops down when adjuster button is Height adjustor pushed. Height adjustor button Push to release adjustor.

  • Page 15: Remote Control Parts

    — ’ — ’ — ’ Remote Control Parts Important: 1. Avoid using the projector with bright fluorescent lighting turned on. Certain high-frequency fluo- rescent lights can disrupt remote control operation. 2. Be sure nothing obstructs the path between the remote control and the projector. If the path be- tween the remote control and the projector is obstructed, you can bounce the signal off certain reflective surfaces such as projector screens.
  • Page 16 ABEL ESCRIPTION EE PAGE IR transmitter Transmits signals to projector Status LED Lights when the remote control is used Laser Press to operate the on-screen pointer Up arrow when connected through USB to a PC Right Right arrow when connected through USB to a PC Down Down arrow when connected through USB to a PC Page Down...

  • Page 17: Remote Control Operating Range

    — ’ — ’ — ’ Remote Control Operating Range The remote control uses infrared transmission to control the projector. It is not necessary to point the remote directly at the projector. Provided you are not holding the remote perpendicular to the sides or the rear of the projector, the remote will function well within a radius of about 7 meters (23 feet) and 15 degrees above or below the projector level.

  • Page 18: Setup And Operation

    ETUP AND PERATION Inserting the Remote Control Batteries Remove the battery compartment cover by sliding the cover in the di- rection of the arrow. Insert the battery with the positive side facing up. Replace the cover. Caution: 1. Only use AAA batteries (Alkaline batteries are recommended). 2.

  • Page 19: Starting And Shutting Down The Projector

    — ’ — ’ — ’ Starting and Shutting down the Projector Connect the power cord to the pro- jector. Connect the other end to a wall outlet. POWER and READY LEDs on the projector light. Turn on the connected devices. Ensure the READY LED displays a solid red and not a flashing red.
  • Page 20 When the “Power Off? /Press Power again” message appears, press the POWER button. The projector turns off. Caution: 1. Be sure to remove the lens cap before starting projector. 2. Do not unplug the power cord until the POWER LED stops flashing–indicating the projector has cooled down.

  • Page 21: Setting An Access Password (Security Lock)

    — ’ — ’ — ’ Setting an Access Password (Security Lock) You can use the four (arrow) buttons to set a password and prevent unauthorized use of the projector. When enabled, the password must be entered after you power on the projector. (See Navigating the OSD on page 17 and Setting the OSD Language on page 18 for help on using OSD menus.) Important: Keep the password in a safe place.
  • Page 22 You can use the cursor buttons ▲▼◄► either on keypad or IR remote control for password entry. You can use any combination including the same arrow five times, but not less than five. Press the cursor buttons in any order to set the password.

  • Page 23: Adjusting The Projector Level

    — ’ — ’ — ’ Adjusting the Projector Level Take note of the following when setting up the projector: • The projector table or stand should be level and sturdy. • Position the projector so that it is perpendicular to the screen. •...

  • Page 24: Adjusting The Zoom Ring, Focus And Keystone

    Adjusting the Zoom ring, Focus and Keystone Use the Image-zoom control (on the projector only) to resize the pro- jected image and screen size Use the Image-focus control (on the projector only) to sharpen the projected image Use the KEYSTONE buttons (on the projec- tor or the remote control) to correct im-...

  • Page 25: Adjusting The Volume

    — ’ — ’ — ’ Adjusting the Volume Press the Volume +/- buttons on the remote control. The volume control appears on the display. Press the Left or Right Cursor buttons on the keypad to adjust Vol- ume +/-. Press the MUTE button to turn off the volume (This feature is avail-...

  • Page 26: On-Screen Display (Osd) Menu Settings

    (OSD) M CREEN ISPLAY ETTINGS OSD Menu Controls The projector has an OSD that lets you make image adjustments and change various settings. Navigating the OSD You can use the remote control cursor buttons or the buttons on the top of the projector to navigate and make changes to the OSD.

  • Page 27: Setting The Osd Language

    — ’ — ’ — ’ Setting the OSD Language Set the OSD language to your preference before continuing. 1. Press the MENU button. Press the cursor ◄► button to navigate to Installation I. 2. Press the cursor ▲▼ button until Language is highlighted. 3.

  • Page 28: Osd Menu Overview

    OSD Menu Overview Use the following illustration to quickly find a setting or determine the range for a setting. English, French, German, Spanish, Portuguese, Simplified Chinese, Traditional Chinese, Italian, Norwegian, Swedish, Dutch, Russian, Polish, Finnish, Greek, Korean, Hungarian, Czech, Arabic, Turkish, Vietnamese, Japanese, Thai, Farsi –...

  • Page 29: Osd Sub-Menu Overview

    — ’ — ’ — ’ OSD Sub-Menu Overview Mini, RCA, HDMI — 20 —...

  • Page 30: Image Menu

    Image Menu Press the MENU button to open the OSD menu. Press the cursor ◄► button to move to the Image Menu. Press the cursor ▲▼ button to move up and down in the Image menu. Press ◄► to change values for settings.

  • Page 31: Advanced Feature

    — ’ — ’ — ’ Advanced Feature Press the Menu button to open the OSD menu. Press ◄► to move to the Image menu. Press ▼▲ to move to the Advanced menu and then press Enter or ►. Press ▼▲ to move up and down in the Advanced menu.

  • Page 32: Color Manager

    Color Manager Press (Enter) / ► to enter the Color Manager sub menu. ESCRIPTION Select to enter the Red Color Manager. Press the ◄► buttons to adjust the Hue, Saturation, and Gain. Select to enter the Green Color Manager. Green Press the ◄►...

  • Page 33: Computer Menu

    — ’ — ’ — ’ Computer Menu Press the MENU button to open the OSD menu. Press the cursor ◄► button to move to the Com- puter menu. Press the cursor ▲▼ button to move up and down in the computer menu. Press ◄► to change values for settings.

  • Page 34: Video/Audio Menu

    Video/Audio Menu Press the MENU button to open the OSD menu. Press the cursor ◄► button to move to the Video/Audio menu. Press the cursor ▲▼ button to move up and down in the Video/Audio menu. Press ◄► to change values for settings. ESCRIPTION Press the ◄►...

  • Page 35: Audio

    — ’ — ’ — ’ Audio Press (Enter) / ► to enter the Audio sub menu. ESCRIPTION Press the ◄► buttons to adjust the audio volume. Volume (Range: 0 ~ 8) Mute Press the ◄► buttons to turn on or off the speaker. Press the cursor ◄►...

  • Page 36: Installationi Menu

    Installation I Menu Press the MENU button to open the OSD menu. Press the cursor ◄► button to move to the Installa- tion I menu. Press the cursor ▲▼ button to move up and down in the Installation I menu. Press ◄►...

  • Page 37: Advanced Feature

    — ’ — ’ — ’ Advanced Feature Press the Menu button to open the OSD menu. Press ◄► to move to the Installation I menu. Press ▲▼ to move to the Advanced menu and then press Enter or ►. Press ▲▼ to move up and down in the Advanced menu.

  • Page 38: Installation Ii Menu

    Installation II Menu Press the MENU button to open the OSD menu. Press the cursor ◄► button to move to the Installa- tion II menu. Press the cursor ▲▼ button to move up and down in the Installation II menu. ESCRIPTION Auto Source Press the cursor ◄►...

  • Page 39: Advanced Feature

    — ’ — ’ — ’ Advanced Feature Press the Menu button to open the OSD menu. Press ◄► to move to the Installation II menu. Press ▲▼ to move to the Advanced menu and then press Enter or ►. Press ▲▼ to move up and down in the Advanced menu.

  • Page 40: Osd Menu Setting

    OSD Menu Setting ESCRIPTION Menu Position Press ◄► button to select different OSD location. Translucent Menu Press ◄► button to select OSD background translucent level. Menu Display Press ◄► button to select OSD timeout delay. Peripheral Test ESCRIPTION Remote Control Press (Enter) / ►...

  • Page 41: Lamp Hour Reset

    — ’ — ’ — ’ Lamp Hour Reset Please refer to Resetting the Lamp on page 47 to reset the lamp hour counter. — 32 —...
  • Page 42 ESCRIPTION Press the cursor ◄► button to select different 3D mode. 3D Sync Invert Press the cursor ◄► button to enable or disable 3D Sync Invert. Note: 1. The 3D OSD menu item is gray if there is no appropriate 3D source. This is the default setting. 2.

  • Page 43: Network

    — ’ — ’ — ’ Network ESCRIPTION Network State Displays the network connection status. Press ◄► to turn DHCP On or Off. DHCP Note: If you select DHCP Off, complete the IP Address, Subnet Mask, Gateway, and DNS fields. IP Address Enter a valid IP address if DHCP is turned off.
  • Page 44 For simplicity and ease of operation, the projector provides diverse networking and remote management features. The LAN/RJ45 function of the projector through a network, such as remotely manage: Power On/Off, Brightness and Contrast settings. Also, projector status information, such as: Video-Source, Sound-Mute, etc .
  • Page 45 — ’ — ’ — ’ 3. Right-click on Local Area Connection, and select Properties. 4. In the Properties window, select the General tab, and select Internet Protocol (TCP/IP). 5. Click Properties. 6. Click Use the following IP address and fill in the IP address and Subnet mask, then click OK. —...
  • Page 46 7. Press the Menu button on the projector. Select Advanced Setup → Network Settings → Control By → RJ45 option After getting into Network Status, input the following: DHCP: Off IP Address: 10.10.10.10 Subnet Mask: 255.255.255.0 Gateway: 0.0.0.0 DNS Server: 0.0.0.0 10.
  • Page 47 — ’ — ’ — ’ ATEGORY NPUT ENGTH IP Address Crestron Control IP ID Port Projector Name Projector Location Assigned To DHCP (Enabled) (N/A) IP Address Network Configuration Subnet Mask Default Gateway DNS Server Enabled (N/A) User Password New Password Confirm Enabled (N/A)
  • Page 48 RS232 by Telnet Function Besides projector connected to RS232 interface with “Hyper-Terminal” communication by dedicated RS232 command control, there is alternative RS232 command control way, so called “RS232 by TELNET” for LAN/RJ45 interface. Quick Start-Guide for “RS232 by TELNET” Check and get the IP-Address on OSD of the projector. Make sure that laptop/PC can access the web-page of the projector.
  • Page 49 — ’ — ’ — ’ Input the command format like the below: telnet ttt.xxx.yyy.zzz 23 (“Enter” key pressed) (ttt.xxx.yyy.zzz: IP-Address of the projector) If Telnet-Connection ready, and user can have RS232 command input, then “Enter” key pressed, the RS232 command will be workable. How to have TELNET enabled in Windows VISTA / 7 By default installation for Windows VISTA, “TELNET”...
  • Page 50 Select “Turn Windows features on or off” to open Have “Telnet Client” option checked, then press “OK” button. – 41 –...
  • Page 51 — ’ — ’ — ’ Specsheet for “RS232 by TELNET” 1. Telnet: TCP 2. Telnet port: 8000 3. Telnet utility: Windows “TELNET.exe” (console mode) 4. Disconnection for RS232-by-Telnet control normally: Close Windows Telnet utility directly after TELNET connection ready 5.

  • Page 52: Factory Reset

    Factory Reset Press the cursor ▲▼ button to move up and down in the Installation II menu. Select the Factory Reset sub menu and press (Enter) / ► to reset all the menu items to the factory default values (expect Language and Security Lock). Status Press the cursor ▲▼...

  • Page 53: Maintenance And Security

    — ’ — ’ — ’ AINTENANCE AND ECURITY Replacing the Projection Lamp The projection lamp should be replaced when it burns out. It should only be replaced with a certified replacement part, which you can order from your local dealer. Important: a.
  • Page 54 Remove the lamp com- partment cover. Remove the three screws from the lamp module. Lift the module handle up. Pull firmly on the module handle to remove the lamp module. – 45 –...
  • Page 55 — ’ — ’ — ’ Reverse steps 1 to 5 to in- stall the new lamp module. While installing, align the lamp module with the connector and ensure it is level to avoid damage. Note: The lamp module must sit securely in place and the lamp connector must be connected properly before tightening the...

  • Page 56: Resetting The Lamp

    Resetting the Lamp After replacing the lamp, you should reset the lamp hour counter to zero. Refer to the following: Press the MENU button to open the OSD menu. Press the cursor ◄► button to move to the Installation II menu. Press the cursor button to move down to Advanced.

  • Page 57: Cleaning The Projector

    — ’ — ’ — ’ Cleaning the Projector Cleaning the projector to remove dust and grime will help ensure trouble-free operation. Warning: 1. Be sure to turn off and unplug the projector at least 30 minutes before cleaning. Failure to do so could result in a severe burn.

  • Page 58: Using The Kensington ® Lock & Using The Security Bar

    ® Using the Kensington Lock & Using the Security Bar If you are concerned about security, attach the projector to a permanent object with the Kensington slot and a security cable. Note: Contact your vendor for details on purchasing a suitable Kensington security cable. The security lock corresponds to Kensington’s MicroSaver Security System.

  • Page 59: Troubleshooting

    — ’ — ’ — ’ ROUBLESHOOTING Common problems and solutions These guidelines provide tips to deal with problems you may encounter while using the projector. If the problem remains unsolved, contact your dealer for assistance. Often after time spent troubleshooting, the problem is traced to something as simple as a loose con- nection.

  • Page 60: Led Error Messages

    LED Error Messages OWER EADY RROR ESSAGES LINK LINK LINK Over temperature G794 fail T1 fail Lamp error Fan1 error (Burner Fan) Fan2 error (Lamp Fan) Fan3 error (Power Fan) Fan4 error (DMD Fan) Lamp door open DMD error Color wheel error Ballast error Ballast communication error In the event of an error, please disconnect the AC power cord and wait for one (1) minute before re-...

  • Page 61: Lamp Problems

    — ’ — ’ — ’ Problem: The color of the projected image does not match the source image. Adjust the Color Temperature and Gamma settings on the Image menu of the OSD. Lamp Problems Problem: There is no light from the projector 1.

  • Page 62: Specifications

    PECIFICATIONS Specifications Model D965 TI DMD 0.7” XGA Display type XGA 1024x768 Native Resolution 3.75 kg (8.27 lbs) Weight 1 meters ~ 10 meters Projection distance 23.4”~300” Projection screen Manual Focus/Manual Zoom Projection lens 1.15 Zoom ratio +/- 15 degrees, 40 steps Vertical keystone Front, Rear, Desktop/Ceiling (Rear, Front) Projection methods...

  • Page 63: Projection Distance Vs. Projection Size

    — ’ — ’ — ’ Projection Distance vs. Projection Size Projection Distance and Size Table Distance (m) 1.28 3.41 4.27 8.53 1.46 2.93 3.66 10.97 Diagonal (inches) Keystone (degree) 12.55 12.55 12.55 12.55 14.56 14.56 14.56 14.56 Image Height (mm) 457.2 1219.2 1524...

  • Page 64: Timing Mode Table

    Timing Mode Table The projector can display several resolutions. The following table outlines the resolutions that can be displayed by the projector. DVI/ OMPOSITE HDMI IGNAL ESOLUTION OMPONENT / S-V IDEO ANALOG DIGITAL — NTSC — 15.734 60.0 － － —...
  • Page 65 — ’ — ’ — ’ DVI/ OMPOSITE HDMI IGNAL ESOLUTION OMPONENT / S-V IDEO ANALOG DIGITAL 720p 37.5 50.0 — — 720p 45.0 60.0 — — 1080i 33.8 60.0 — — HDTV 1080i 28.1 50.0 — — 1080p 67.5 60.0 —...

  • Page 66: Projector Dimensions

    Projector Dimensions – 57 –...

  • Page 67: Regulatory Compliance

    — ’ — ’ — ’ EGULATORY OMPLIANCE FCC Warning This equipment has been tested and found to comply with the limits for a Class B digital device pur- suant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.

  • Page 68: Rs-232C Protocol

    PPENDIX RS-232C Protocol RS232 Setting Baud rate: 9600 Parity None check: Data bit: Stop bit: Flow Con- None trol Minimum delay for next command: 1ms Control Command Structure Header code Command code Data code End code Command Data ｀V’ ASCII Command Data Operation Command...
  • Page 69 — ’ — ’ — ’ VXXG0102 56h Xh Xh 47h 30h 31h 30h 32h 0Dh Get Contrast n=0~100 Pn/F VXXS0102n 56h Xh Xh 53h 30h 31h 30h 32h nh 0Dh Set Contrast n=0~100 VXXG0103 56h Xh Xh 47h 30h 31h 30h 33h 0Dh Get Color n=0~100 Pn/F...
  • Page 70 Command Group 03 ASCII Function Description Return Value 0: Fill 1: 4:3 2: 16:9 VXXG0301 56h Xh Xh 47h 30h 33h 30h 31h 0Dh Get Scaling Pn/F 3 :Letter Box 4 :Native 5: 2.35:1 0: Fill 1: 4:3 2: 16:9 VXXS0301n 56h Xh Xh 53h 30h 33h 30h 31h nh 0Dh Set Scaling 3 :Letter Box 4 :Native...
  • Page 71 — ’ — ’ — ’ Command Group 04 (Remote Control) ASCII Function Description Return Value VXXS0401 56h Xh Xh 53h 30h 34h 30h 31h 0Dh UP arrow VXXS0402 56h Xh Xh 53h 30h 34h 30h 32h 0Dh DOWN arrow VXXS0403 56h Xh Xh 53h 30h 34h 30h 33h 0Dh LEFT arrow...
