setUP & InstallatIon
10. Determine which side of the sink
you want your System:
to position system to the leFt side
of your sink: Unthread Lid Assembly
from Filter Housing, then orient the Lid
Assembly to Filter Housing as shown.
Once positioned, thread
(fig. F, Step 1)
Lid Assembly clockwise onto the Filter
Housing until tightened.
(fig. F, Step 2)
to position system to the rIGHt side
of your sink: Unthread Lid Assembly
from Filter Housing, then orient the Lid
Assembly to Filter Housing as shown.
Once positioned, thread
(fig. G, Step 1)
Lid Assembly clockwise onto the Filter
Housing until tightened.
(fig. G, Step 2)
11. Press the elbow fitting on Diverter Valve Assembly
into the Filter Base.
(fig. H)
12. Insert Battery Shuttle (with included Battery) into Lid
Assembly. The Intelligent Monitor
(fig. I)
gREEN, yELLOW and RED five times. This resets
the rated capacity counter to zero gallons. Do not
remove Battery shuttle until it is time to replace
the Filter Cartridge. removing Battery shuttle
prematurely may result in a loss of data.
13. With System placed on the counter and positioned
so that water will flow into kitchen sink, turn the cold
water faucet "ON" and pull Diverter Pin.
will begin to fill the Filter Housing. Once water begins
to flow from the System, the Intelligent Monitor
begin flashing gREEN to indicate peak operational
performance. Check to see that all hose, lid and
housing connections are tight and do not leak.
14. Allow System to flush into sink for 15 minutes.
This will remove any fine, black carbon particles left
over from the manufacturing process, expel trapped
air and condition the Filter Cartridge for normal use.
(This water may be used to water plants.)
Important
Repeat flushing procedure each time a new Cartridge is installed.
Congratulations! your new WaterChef
4
www.waterchef.com
steP 1 steP 2 leFt Placement
line up
Front
of Lid
Assembly
with hose
outlet
F
steP 1 steP 2 rIGHt Placement
line up
spout
BaCK
facing
of Lid
Assembly into sink
with hose
outlet
G
will flash
™
H
Water
(fig. J)
™ will
I
J
Filtration system is ready!
®
The most important part of maintaining your WaterChef Filtration System is replacing the
Filter Cartridge (and Battery) on a regular service interval. To insure your System continues to
perform as stated in the Performance Data Sheet, the Filter Cartridge should be replaced
upon the first occurrence of the following:
spout
facing
into sink
- Annually
- When the flow rate diminishes
- When you notice a taste or odor recurrence
- When the rated capacity of the Filter Cartridge has been reached
- When the Intelligent Monitor
Important
Be sure to use only genuine WaterChef
have been tested and certified by NSF International to insure the performance represented in the Performance
Data Sheet.
1. Remove the Lid Assembly by turning counterclockwise
until it separates from the Filter Housing. As you
remove the Lid Assembly, the Filter Cartridge will
remain attached to the Lid Assembly.
recommendatIon
Rubber gloves should be worn to avoid direct contact with filtered
contaminants.
2. Hold the Lid Assembly and rotate the Filter Cartridge
counterclockwise to remove. Discard the used Cartridge
with your regular refuse.
3. Wash the inside of Filter Housing and Lid Assembly
with warm water, a mild dish washing detergent and
a clean cloth.
cautIon
Do NOT use abrasive pads or other abrasive materials to clean
Filtration System.
4. Remove the plastic sanitary wrap from your new Filter
Cartridge. Thread the new Cartridge clockwise onto
the threaded post on the Lid Assembly until you
feel resistance. Make an additional quarter turn.
Do not over-tighten.
(continued on next page)

rePlaCInG tHe FIlter CartrIdGe

™ begins flashing RED
® CR70 Filter Cartridges with this System. Only WaterChef Filter Cartridges
(fig. K)
(fig. L)
(fig. M)
K
l
M
5
