ProdUCt sPeCIFICatIons

WATERCHEF COUnTERTOP FILTRATIOn SySTEM
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Countertop
Particle Retention Size . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Sub-Micron
Intelligent Monitor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . LED
Rated Capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1,000 gallons (US)
Rated Service Flow. . . . . . . . . . . . . . . . . . . . . . . . . . . 0.65 gal/min @ 60 psi
Maximum Working Pressure . . . . . . . . . . . . . . . . . . . . . . . 100 psig (689.5 kPa)
Minimum Working Pressure . . . . . . . . . . . . . . . . . . . . . . .
Maximum Operating Temperature . . . . . . . . . . . . . . . . . . . . . . . . 100˚ F / 38˚ C
Minimum Operating Temperature . . . . . . . . . . . . . . . . . . . . . . . . . 34˚ F / 1˚ C
Replacement Filter Cartridge
(includes Battery)
EPA Establishment Number . . . . . . . . . . . . . . . . . . . . . . . . . . 63018-NV-001
Protected under U.S. Patent #: D408,494
Refer to Performance Data Sheet for actual contaminant and substance reduction capabilities.
System Tested and Certified by NSF International against NSF/ANSI Standard 42 for the reduction of Chloramine, Chlorine
Taste and Odor, and nominal Particulate Class I and NSF/ANSI Standard 53 for the reduction of Cysts, Lead, VOC and MTBE.

rePlaCeMent Parts dIreCtory

IteM
1
1
2
1
2
3
2
3
3
4
4
5
5
5
6
6
2
www.waterchef.com
(Model: C7000)
30 psig (206.8 kPa)
. . . . . . . . . . . . . . . . . . . . . . CR70
Part # desCrIPtIon
1215-55-05 Lid Assembly
(White)
1215-41-01 Lid Assembly
(Black)
4-104-0052-02 Battery Shuttle
(White) (includes Battery)
4-104-0052-01 Battery Shuttle
(Black) (includes Battery)
1215-10-37 Housing Assembly
(White
1215-20-40 Housing Assembly
(Black)
CR70 Filter Cartridge
(includes Battery)
0581-03-02 3/8" Diverter Valve Assembly
0581-03-15 3/8" Diverter Valve Assembly
9-904-0023 Faucet Adapter Kit
(3 pieces)
1. Open the shipping carton, remove all System parts
and place them on your kitchen counter.
2. Compare them with the parts shown in this guide to be
certain all items were included (see inside front cover).
3. Unthread and remove the aerator from the end of your
kitchen faucet if it has one.
note
This System is not recommended for installation on pull-out faucets.
4. Thread the Diverter Valve directly onto your kitchen
faucet. Do not over-tighten.
5. If the threads to the Diverter Valve do not directly
attach to your kitchen faucet, use one of the three
Adapters provided
6. Most kitchen faucets with external threads will directly
attach to the Diverter Valve. In some instances the
Diverter Valve may be smaller than your kitchen faucet.
In this case use the adapter with internal threads and
thread it directly to your kitchen faucet. Next, thread
the Diverter Valve to the Adapter.
7. If your kitchen faucet has internal threads, thread
one of the two Adapters with external threads directly
to your kitchen faucet. Next, thread the Diverter Valve
to the Adapter.
8. If your kitchen faucet does not have threads, measure
the inside diameter of the kitchen faucet and call
WaterChef Customer Care at 1.800.879.8909
(int'l +1.775.359.9500)
9. If your kitchen faucet does not fit any of the Adapters
provided, send your threaded aerator to:
WaterChef Customer Care
) 3760 Barron Way
Reno, NV 89511
Include a note requesting an Adapter that fits your threads.
(continued on next page)
(White)
(Black)
setUP & InstallatIon
(fig. A)
(fig. B)
. (fig. C)
(fig. D)
(fig. E)
to request an Expandable Adapter.
a
B
C
d
e
3
