P R E M I U M W A T E R F I L T R A T I O N
INSTALLATION, USE & CARE GUIDE
WHOLE HOUSE
Water Filtration System
IMPORTANT
Read & Save These Instructions.
System installation requires the
services of a licensed plumber.
QUESTIONS?
1.800.879.8909
(int'l +1.775.359.9500)
MON - FRI 8 AM - 5 PM PST
My System Serial #:
Serial Number is located on filter housing base.
System Certified by IAPMO R&T
against NSF/ANSI Standard 53 and
CSA B483.1 for the reduction of Lead,
Cysts, Perfluorooctanoic Acid (PFOA)
and Perfluorooctane Sulfonate (PFOS).
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for WaterChef EVO100
Summary of Contents for WaterChef EVO100
- Page 1 P R E M I U M W A T E R F I L T R A T I O N INSTALLATION, USE & CARE GUIDE WHOLE HOUSE Water Filtration System IMPORTANT Read & Save These Instructions. System installation requires the services of a licensed plumber.
-
Page 2: Table Of Contents
Product Registration ............. . . 13 WHAT’S IN THE BOX [MODEL: EVO100]... -
Page 3: Introduction
INTRODUCTION Congratulations on the purchase of your new WaterChef Premium Whole House Water Filtration System! ® WaterChef Filtration Systems are crafted using the finest materials and workmanship, and will serve you reliably for many years to come when operated and maintained according to the directions contained in this guide. You have made a wise investment in providing quality water for you and your loved ones. Now please take a few minutes to learn about all the features and benefits your new System has to offer! IMPORTANT USE GUIDELINES • Read this manual completely before attempting to install or use this product. If system is not maintained and operated as specified in this manual, there is a risk of exposure to contaminants. • Testing was performed under standard laboratory conditions, actual performance may vary. Actual performance is dependent on influent water quality, flow rates, system design and application. For optimal performance, replace your Filter Cartridge upon the first occurrence of the following:... -
Page 4: Product Specifications And Performance
WHOLE HOUSE WATER FILTRATION SYSTEM ® (Model: EVO100) Installation ....Whole House Replacement Filter Cartridge ... . . EVR1 Particle Retention Size . -
Page 5: System Installation
Outlet Side (right). Note the flow direction Drain Valve arrow on meter body. PART IDENTIFICATION 6 Straight or 90º Elbow 1” MNPT Connectors (2 each) Filter Housing Bottom Inlet/Outlet Cap Assembly 7 3/8” Drain Valve Assembly with Shut-Off 8 Umbrella Cover (with Monitor Assembly and Battery Backup) Reducer Tees (2) (1 plugged fitting) Flow Meter Assembly NOT SHOWN: Power Supply Flow Control Valve waterchef.com... -
Page 6: Filter Cartridge Installation
Button pushed down until ALL air is released and water starts to come out of the Button. Release Button. (fig. E) Bottom, Center Opening 9. Seat Umbrella Cover on top of Housing Assembly (fig. F) check for leaks. 10. Flush System by running water through System for 10 minutes before use. Pressure Release Button IMPORTANT Repeat flushing procedure each time a new Filter Cartridge is installed. Umbrella Cover waterchef.com... -
Page 7: Replacing The Filter Cartridge
Reset Button confirm reset. (fig. G) 3. Depressurize the System by pushing down on the RED Pressure Pressure Release Release Button on the Top Cap of the Housing until ALL the air or Button water pressure is completely released. (fig. H) 4. Press down on the Top Cap with both hands to unseat the Snap Ring. Remove the Snap Ring by carefully grasping the (fig. I) handle and pulling inward, then upward. The Ring should slide completely out of the groove. (fig. J) Top Cap 5. Remove the Top Cap from the Housing by lifting up on the Cap Handles. Remove the old Filter Cartridge. 6. Connect 3/8” O.D. Tubing (included with EVO100 System) to the Drain Valve that connects to the inlet side of the Filtration System. Run the hose to a floor drain or bucket then OPEN the Drain Valve and flush out the bottom of the System. (continued on following page) Snap Ring waterchef.com... - Page 8 Button. Release Button. Pressure 13. Seat Umbrella Cover on top of Housing Assembly (fig. N) Release Button check for leaks. 14. Flush System by running water through System for 10 minutes before use. If lights are not flashing GREEN, see step 2. IMPORTANT Umbrella Repeat flushing procedure each time a new Filter Cartridge is installed. Cover waterchef.com...
- Page 9 LEDs Simple color-coded LED notifications display the usage status of the filter cartridge: GREEN 100%-10% of filter life remains Under 10% of filter life remains YELLOW End of filter life has been reached If there is flow, LEDs should alternately blink in the following pattern: 1-2-3-2 (repeat). The frequency that the LEDs blink corresponds to the flow rate received from the Monitor. For every revolution from the Monitor, the LED pattern should be incremented to turn off the next LED. If there are no revolutions for 2 seconds, all LEDs will turn on solid. If the batteries are low, the middle LED will turn WHITE. The battery level is checked once an hour to minimize the battery drain from checking the voltage. Reset Button The Reset Button allows for the Intelligent Monitor to be reset. ™ To reset the Intelligent Monitor , press and hold the Reset Button for 3 seconds. Once reset, the LEDs should ™ flash green 3 times to confirm reset. Power Monitoring and Battery Mode In addition to monitoring water usage, the Intelligent Monitor also monitors the System’s 12V DC power ™ and battery power. If there is a power failure and no batteries are installed, the Monitor’s value will be saved to non-volatile memory. When power is resumed, the gallon count will resume from where it left off when power was lost. If there is a power failure and batteries are installed, the Monitor goes into battery mode. During battery mode, the LEDs should shut off. If the Monitor is in the YELLOW or RED state, or if the battery voltage gets low, the LEDs will flash on in the appropriate color for .125 seconds every 4 seconds. If the Reset Button is pressed in battery mode, the LEDs will turn on for 4 seconds and then return to battery mode. waterchef.com...
- Page 10 P R E M I U M W A T E R F I L T R A T I O N EVO100 WHOLE HOUSE WATER FILTRATION SYSTEM 5-YEAR LIMITED WARRANTY WaterChef warrants that this filtration system will be free from defects in materials and workmanship in ®...
- Page 11 DATE OF PURCHASE: PURCHASED FROM: Sign me up for WaterChef Updates, Special Promotions & Exclusive Discounts! Please send me Courtesy Email Notifications when it’s time to replace my filter cartridge. We value your privacy and will not sell or share your information with anyone. You may unsubscribe from updates and cartridge reminder notifications at any time.
- Page 12 WaterChef 3760 Barron Way · Reno, NV 89511 tel 1.800.879.8909 int’l +1.775.359.9500 ® email customercare@waterchef.com | web waterchef.com 1-404-0122 r19.10...
