Summary of Contents for Neo Car Audio HD1
- Page 1 Expand Your Factory Radio iPod ® Owner’s Manual Neo Gateway Enjoy the Music...
-
Page 2: Table Of Contents
Table of Contents Pages 1. Introduction 2. Precautions 3. Compatibility Notes 4. Dipswitch Settings 5. Installation 6. iPod Operation 7. HD Radio Operation (if equipped) Selecting AUX Input Selecting Factory Satellite (if equipped) Troubleshooting Warranty Info... - Page 3 Neo Gateway & Optional Add-ons Factory Radio Not Included iPod Neo Gateway Harness Not Included Neo Gateway 11Ft. iPod Cable 3Ft. HD Radio Cable (sold with HDRT) HD Radio Tuner...
-
Page 4: Introduction
2. Precautions UPDATING iPod FIRMWARE For proper operation of the Neo Gateway, your iPod must be updated with the most recent version of firmware from Apple. This is done on your computer. To update the software on the iPod go to: http://www.apple.com/ipod/download/. -
Page 5: Compatibility Notes
This section will inform you of the specific requirements for your factory radio to be compatible with the Neo Gateway. These notes will inform you of any issues or circumstances that can affect the compatibility of our product with your radio, audio system, or accessories. -
Page 6: Installation
Radio tuner. Connect the factory antenna cable into the antenna connection on the HD Radio tuner (HDRT). 6. Plug the male connector on the HD1 harness into the 14-pin port on the back of the radio. Next, connect the factory 14-pin harness (if present) into the female connector on the HD1 harness. -
Page 7: Ipod Operation
6. iPod Operation Entering Mode Select Menu Leave and re-enter the XM source to enter the mode select menu. This can be accomplished by pressing the “AM/FM” button to switch to FM, AM and then “XM or “AUX” to switch back to “XM”. Once in the mode select menu, turn the rotary knob until “iPod”... - Page 8 Browse by Artist Press Preset 6 to enter the browse menu. ”PL: LIST” will appear on your display. Turn the rotary tune knob until ARTIST is displayed. Press Preset 6 to select browse by Artist. The list of Artists on your iPod will be displayed one at a time in alphabetical order.
- Page 9 Browse by Album Press Preset 6 to enter the browse menu. ”PL: LIST” will appear on your display. Turn the rotary tune knob until ALBUM is displayed, Press Preset 6 to select browse by Album. The Albums on your iPod will be displayed one at a time in alphabetical order.
- Page 10 The Albums from the selected Artist will be displayed one at a time in alphabetical order. “AL” will be displayed in front of the name of the album to indicate you are searching for an album. Turn the rotary tune knob to cycle through the albums. Once the desired album is displayed, Press Preset 6 to select the desired Album.
-
Page 11: Hd Radio Operation (If Equipped)
7. HD Radio Operation Entering Mode Select Menu Leave and re-enter the XM source to enter the mode select menu. This can be accomplished by pressing the “AM/FM” button to switch to FM, AM and then again to switch back to “XM”. Once in the mode select menu, turn the rotary knob until “HD Radio”... -
Page 12: Selecting Aux Input
8. Selecting AUX Input Entering Mode Select Menu Leave and re-enter the XM source to enter the mode select menu. This can be accomplished by pressing the “AM/FM” button to switch to FM, AM and then again to switch back to “XM”. Once in the mode select menu, turn the rotary knob until “AUX 1”... -
Page 13: Troubleshooting
Radio shows “DEV Gateway device is This only occurs the first time the Neo INIT” initializing is powered on. Wait a few minutes, cycle ignition off and on then enter SAT Mode. -
Page 14: Warranty Info
Within the first 12 months from date of purchase, subject to the conditions above, will repair or replace the product at their discretion, if it is defective in material or workmanship providing it is returned to an Authorized Neo Car Audio dealer, with PROOF OF PURCHASE from an authorized dealer. - Page 15 Notes ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________ _ ____________________________________________________...
