VARIABLE SPEED JIGSAW

SEt uP AnD OPERAtInG InStRuctIOnS

Visit our website at: http://www.harborfreight.com
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE thIS MAnuAL.
©
Copyright
2001 by Harbor Freight Tools
contained herein may be reproduced in any shape or form without the express written consent of
Harbor Freight Tools. Diagrams within this manual may not be drawn proportionally. Due to continuing
improvements, actual product may differ slightly from the product described herein. Tools required for
assembly and service may not be included.
For technical questions or replacement parts, please call 1-800-444-3353.
Manual Revised 10d
Model
46055
®
. All rights reserved. No portion of this manual or any artwork

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 46055 and is the answer not in the manual?

Questions and answers

Summary of Contents for Drill Master 46055

  • Page 1: Set Up And Operating Instructions

    Harbor Freight Tools. Diagrams within this manual may not be drawn proportionally. Due to continuing improvements, actual product may differ slightly from the product described herein. Tools required for assembly and service may not be included.
  • Page 2: Important Safety Information

    Unmodified plugs and matching outlets injury. will reduce risk of electric shock. Avoid body contact with grounded surfaces such as pipes, radiators, REV 10d Page 2 For technical questions, please call 1-800-444-3353. SKU 46055...
  • Page 3 Ensure the switch is in the off- switch does not turn it on and off. Any power tool that cannot be controlled position before connecting to power source and/or battery pack, picking REV 10d SKU 46055 For technical questions, please call 1-800-444-3353. Page 3...
  • Page 4: Jigsaw Safety Warnings

    These carry important safety users. information. If unreadable or missing, Maintain power tools. check for contact Harbor Freight Tools for a misalignment or binding of moving replacement. parts, breakage of parts and any Avoid unintentional starting. Prepare to other condition that may affect the begin work before turning on the tool.
  • Page 5: Vibration Safety

    It must be understood by the operator To reduce vibration, maintain the tool that common sense and caution are as explained in this manual. If any REV 10d SKU 46055 For technical questions, please call 1-800-444-3353. Page 5...
  • Page 6 Tools marked with “Grounding Required” Standard Association, and the National have a three wire cord and three prong Electrical Code. grounding plug. The plug must be connected to a properly grounded outlet. REV 10d Page 6 For technical questions, please call 1-800-444-3353. SKU 46055...
  • Page 7: Extension Cords

    Make sure the extension cord is properly wired and in good electrical condition. Always replace a damaged extension cord or have it repaired by a qualified electrician before using it. REV 10d SKU 46055 For technical questions, please call 1-800-444-3353. Page 7...
  • Page 8: Specifications

    (21) with the hex Spanner (32). Refer to Figure 1. Insert the end (with holes) of the Blade between the Blade Stock and the Blade Clamp. Hold the Blade level while REV 05b, 10d Page 8 For technical questions, please call 1-800-444-3353. SKU 46055...
  • Page 9: Operation

    See Figure 3. See Figure 5. note: Make sure the bottom base is level with the workpiece, or the blade could break. note: Unplug tool before making adjustments. SKU 46055 For technical questions, please call 1-800-444-3353. Page 9...
  • Page 10: Maintenance

    BUYER ASSUMES ALL RISK AND LIABILITY ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT PARTS THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION OF REPLACEMENT PARTS THERETO. Page 10 For technical questions, please call 1-800-444-3353. SKU 46055...
  • Page 11: Parts List And Diagram

    Blade Clamp Hex Spanner Carbon Brush and Holder Screw Saw Blade nOtE: Some parts are listed and shown for illustration purposes only and are not available individually as replacement parts. SKU 46055 For technical questions, please call 1-800-444-3353. Page 11...
  • Page 12: Limited 90-Day Warranty

    To take advantage of this warranty, LIMItED 90 DAY WARRAntY the product or part must be returned to us Harbor Freight Tools Co. makes every with transportation charges prepaid. Proof effort to assure that its products meet of purchase date and an explanation of the high quality and durability standards, and complaint must accompany the merchandise.
