Hyun Won DAH-1100 User Manual

Direct-connect usb flash mp3 player with graphic lcd
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Direct -Connect USB Flash
MP3 Player with Graphic LCD

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DAH-1100 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Hyun Won DAH-1100

Summary of Contents for Hyun Won DAH-1100

  • Page 1 Direct -Connect USB Flash MP3 Player with Graphic LCD...

  • Page 2: Safety Instructions

    Safety Instructions Warning To reduce danger of fire or electric shock, do not expose the product to rain or moisture. Do not release or distribute the music files formatted in WMA or MP3 from the product to the public. (As this would violate Copyright laws.) The software contained on the installation CD-ROM is for personal use only and it not to be distributed.

  • Page 3: Table Of Contents

    Feature and Capacity of Products Feature Digital Audio Player which supports multi-format 1) MP3: 8~320Kbps 2) WMA: supporting over 8Kbps Graphic LCD and EL backlight. Multi Language Support. (Korean/English/Japanese/Chinese) Firmware upgrade by the Internet. Portable USB store equipment. low power consumption : It's possible to play 11 hours continuos playback. It provides a variety of Menu for suiting customer's taste.

  • Page 4: Confirm The Contents

    1. Confirm the contents Install CD Earphone USB Combo USB extension cable battery(AAA_1) User Manual Neck Strap 2. Look at the title of the each part USB terminal Neck Strap hanger The next track/ Battery case previous track/ all the track/ menu button Turn on/ Play/ Stop button...

  • Page 5: Put In The Battery

    3. Put in the battery Remove the battery Put in the battery Push and close the cover by pushing adjusting to plus/ battery cover to an the battery cover to minus polarity. arrow direction an arrow direction. adjusting to the groove.

  • Page 6: File Download/Upload

    5. File download/upload If USB drive connects to the computer, new portable drive is added. You can use it such as adding or deleting the data on the hard disk by Windows explorer Note: Music files(MP3, WMA) are just shown on LCD and the data files are shown on Windows explorer Possible to add the portable drive...

  • Page 7: Look At The Title Of The Part Of Lcd

    7. Look at the title of the part of LCD MP3/WMA display The section repetition display Playback status display Bit rate display Playing song number/ Total song number Playing song Title display Volume display The left capacity of the Hold display EQ mode display FLAT ROCK...

  • Page 8: Control The Volume

    8. Look at the basic function of the digital audio player 8.3 Control the volume Volume control button Playback status. It's possible to control the volume from 0 to 30 Volume(0):VOLUME MUTE Volume(30):VOLUME MAX If there is no key input after controlling the volume for 3sec, the normal status is returned.

  • Page 9: Set Up The Sound Effect

    8. Look at the basic function of the digital audio player 8.6 Set up the sound effect What's the sound effect? It's the function that you want to listen to the specific sound with emphasis. If you push the Menu button with long(over 700ms), the function of Menu is returned.

  • Page 10: Set Up The Power Saving

    8. Look at the basic function of the digital audio player 8.10 Set up the power saving What's the power saving? It's the function that the player is turned off at the no input. After searching the lightening using 'Next song/previous song' at Menu you push 'Menu‘button with short.

  • Page 11: Fm Radio Mode

    9. FM Radio mode Choose F.M Radio on the menu item and Press "Menu" button quickly once to get in F.M. Radio mode. Press button for long time or if there's input, player go back to play/pause mode. 1. Change preset - Use "FF/REW"...

  • Page 12: Install A Software

    11. Install a software The customers who use a window 98/98SE should install a software and use this machine. The customer who use a window ME/XP/2000 need not to install a software. Click the Next button Double click a Setup.exe file after inserting a CD into the CD ROM Click the Next button Click the Yes button...

  • Page 13: Format

    12. Format Caution: In the case of a format, the user of window 98/98SE/ME/XP/2000 should install a software provided by the company. In the case of using a existing format of computer such a FAT32, NTFS, it is possible that this machine does not operate normally.

  • Page 14: Troubleshooting Problems

    14. Troubleshooting Problems If you encounter any of the problems listed below, follow the suggested solutions. 1.No Power. - Is the battery inserted correctly? - Is hold switch OFF? - Is the player combined with USB credle? - Is the battery empty? 2.No Playback.

  • Page 15: Fcc Rf Interference Statement

    16. FCC RF INTERFERENCE STATEMENT Note This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
