Hyun Won DAH 900 User Manual

Multi format digital audio player fm radio voice recorder
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Test Report No.: GETEC-E3-03-020
FCC Class B Certification
APPENDIX H
: USER'S MANUAL
EUT Type: MP3 Player
FCC ID : PCMDAH900

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DAH 900 and is the answer not in the manual?

Questions and answers

Related Manuals for Hyun Won DAH 900

Summary of Contents for Hyun Won DAH 900

  • Page 1 Test Report No.: GETEC-E3-03-020 FCC Class B Certification APPENDIX H : USER’S MANUAL EUT Type: MP3 Player FCC ID : PCMDAH900...
  • Page 2 DAH 900 Phone : 82-54-338-6000 Facsimile : 82-54-337-3075 Homepage : http://www.m-any.com FM Radio E-mail: call@hyunwoninc.com Voice Recorder Address :333-1 Shindae-Ri, Kumho-Eup, Youngcheon-City, KyoungBuk, South Korea Multi Format Digital Audio Player...
  • Page 3 Safety Warning and Precaution Please follow all warnings and safety precautions in this part to prevent any risk of electronic shock or property damage. This symbol indicates the possibility of the personal death or personal Warning hazardous damage. This symbol indicates the possibility of the personal injury hazard Caution or of the product damage.

  • Page 4: Table Of Contents

    About the Battery To keep the qualified function Specifications of DAH 900 and PC System Requirements Do not use the product under the hazardous conditions, such as extremely Accessories high or low temperature area, dusty area, or excessive wet area.

  • Page 5: Welcome To The World Of Dah 900

    The memory capacities vary from 64MB, 128MB, and to 256MB. Others DAH 900 is manufactured to be lawful with the copyrights as it is available to provide a new music format using Digital Signal Processor which also allows the player to be LCD Panel upgraded.

  • Page 6: What's Mp3 And Wma File

    What's the portable What's MP3 and WMA Files? digital audio player? -It is a portable player that store the digital audio file and retrieve it, which has What's MP3? been available in PC. It's a music file, which is condensed(1/12) in the MPEG1-Layer3 form from the CD music data, for the use at PC.It provides qualified sound as CD does.
  • Page 7 Battery Battery Icons indicating the remaining capacity of the battery Use a AAA size battery When initially operating, the icons of the remaining capacity may not readable. Open the battery cover by pushing in the direction (Battery usage time) (enough) (middle) (low) of the arrow.

  • Page 8: Specifications Of Dah 900 And Pc System Requirements

    Specifications of DAH 900 and Battery PC System Requirements Playing Time of a Battery PC System Requirements The following PC specifications are required for DAH 900 compatibility. Batteries Playing Time Microsoft (Windows 98. ME. 2000.XP ) Alkaline Battery 26 hours...

  • Page 9: Accessories

    Accessories Names of Parts Front Panel Included Components with your DAH 900 DAH 900 Accessory B. Earphones C. Manual A. Installation CD Necklace connector F. USB Cable D. Line-in E. AAA Battery 2EA LCD Window Cable Decrease Volume button. MODE button I.
  • Page 10 Names of Parts Names of Parts Side Panel USB Jack Earphone Audio Jack Hight Sensitive Microphone Encording Audio Jack...

  • Page 11: Listening To The Sample Music

    LCD Window Listening to Sample Music Sample MP3 files are stored in DAH 900 player. b c d e You can learn the usage of buttons by executing playback of the files. 1. Power On / Playback Press the PLAY ( )button more than 2 seconds to turn the player on.
  • Page 12 Listening to Sample Music Listening to Sample Music 2. Selecting Songs 3. Pause Function While playing, press the PAUSE ( button quickly to pause and press it again to play. :To select the previous song, press the REWIND button for seconds If REWIND button is pressed after 5sec from music is started, music start from beginning.

  • Page 13: User's Eq Mode

    Listening to Sample Music User’s EQ MODE 4. STOP and power Function Press the STOP( ) button to stop and hold it for more than 3seconds to power the player down. EQ MODE Live Dance Jazz Latin Rock User 1 User 2 The quality of sound can be deteriorated depending on music.

  • Page 14: Setup User Eq Mode

    SETUP USER EQ MODE SETUP USER EQ MODE USER1 MODE, USER2 MODE 3) Change EQ setting (USER1 EQ, USER2 EQ) - Change EQ setting is available when bars are displayed on LCD (5 Bands are available) 1) Get in USER EQ MODE - First Bar will blink when get in setting mode (Band 1 setting mode) USER EQ MODE is available only while playing music.

  • Page 15: Mode Setting

    MODE Setting MODE Setting Sectional Repeat Function Play MODE change REPEAT MODE(Repeat an interval of the current song) During playback, press MODE button for short time to change the mode, as it goes. 1) If you press mode button for a while when playing a song, NORMAL REPEAT REPEAT-ALL...

  • Page 16: Hold

    HOLD (Lock key) REC button Function HOLD(Lock key) RECORD MODE 1) Mode setting is possible in the STOP position. - Button is not recognized. 2) If you press the REC button and hold for seconds, “VOICE RECORD” will be displayed on the - When power is on, and HOLD is on, PLAY is not executed even if you press LCD window.
  • Page 17 REC button Function REC button Function Music Recording Press REC button quickly again to start voice recording. In the bottom of the LCD window, recording icon will be turned on and “Recording” displayed. Plug Line-in cable to player and plug other side to line-in jack of other audio device.

  • Page 18: Erase Mode

    REC button Function REC button Function Erase MODE Press STOP button to stop recording. Press PLAY button to play recorded files and the list of recorded files will appear Erase Mode is possible in the STOP position. on the LCD window as to E001, E002, E003, Press REC button for long time in MUSIC RECORD will display "ERASE MODE"...

  • Page 19: How To Install Cd

    " Erase? Yes:Rec No: Other" message will display on LCD. Notice After installing M-ANY Loader Plus, connect DAH 900 and PC by using USB Cable. 1. Insert M-ANY Loader Plus CD into CD-ROM drive. When CD is put in, Setup program is automatically executed and the screen below pops up.

  • Page 20: How To Use M-Any Loader Plus

    C. Memory Window This window shows the title, volume and type of file on DAH 900 memory. D. Folder Window This window enables a user to look at a specific file and select a music file more easily.

  • Page 21: How To Format Memory

    How to use M-ANY Loader Plus How to use M-ANY Loader Plus How to Format Memory. G. Functional Icons Method by using format icon Select the view for a basic memory of the body. Execute M-ANY Loader Plus and connect Add the selected file to Memory.

  • Page 22: How To Download Files

    If you want to move favorite file from PC to digital audio player, follow the instruction below. Purchase MP3 file on the Internet and save it in PC. Connect DAH 900 with USB Cable. Double-click M-ANY Loader Plus on the screen and execute the program.

  • Page 23: How To Upload Files

    How to download How to upload If you want to move file from DAH 900 to PC, follow the instruction below. Select MP3 file or data file that will be downloaded on file list window. Then, click ADD Note) MP3/WMA file cannot be uploaded under related laws.

  • Page 24: Error Message

    Please make sure that you finished installation process before connecting the USB cable. are as follows. To make the DAH 900 and your PC share Files, connect DAH 900 with the USB cable Please note this when error message pops up.

  • Page 25: Fm Radio Mode

    LCD Window FM RADIO MODE Entering FM RADIO MODE b c d e 1) RADIO MODE can be entered only at STOP mode of MP player. 2) If you press MODE button for a while, FM Radio" is displayed and you can enter RADIO MODE.

  • Page 26: Searching Frequency

    Searching frequency FM RADIO MODE Listen to radio at FM RADIO MODE (Frequency 87.5MHz ~ 108.0MHz) Searching frequency manually 1) After entering RADIO MODE, press PLAY button to listen to FM You can press FF/REW button briefly to search frequency. radio.(RADIO MODE ) (Frequency is increased or decreased by 0.1MHz.) - Searching is possible at STOP/PLAY MODE.

  • Page 27: Saving Your Favorite Frequency

    Searching frequency Saving your favorite frequency Saving frequency at Auto Set MODE(saving various frequency at once) Saving frequency with PreSet MODE 1) If you press MODE button for a while at PreSet MODE, Auto Set MODE is 1) Press MODE button for a while at PLAY mode, PreSet MODE is started. started.

  • Page 28: Erasing Saved Frequency

    Erasing saved frequency RADIO RECORD MODE Entering RADIO RECORD MODE Erasing PreSet frequency (erasing all 10 at one time) 1) If you press REC button for a while at RADIO MODE while playing, RADIO for a while 1) If you press MODE button at Auto Set MODE, All Erase icon is RECORD”...

  • Page 29: Remote Controller Manual

    RADIO RECORD MODE Remote Controller Manual 3) If you press STOP or REC button briefly while recording, the recording is stopped. After REC Stop" is displayed for 1 sec and then file names (E001, Earphone Jack E002, E003... ) are displayed for 1 sec. - File name: Identical to the name of music recording at MP Player MODE.

  • Page 30: Check Before Calling A/S

    Remote Controller Manual Check before calling A/S User EQ Settings. Status check follow instruction - Please press EQ/MODE button for long time to change EQ while a song is playing. (Icon will be displayed on set’s LCD on setting EQ.) No function of button after checking did you insert a battery...

  • Page 31: Troubleshooting Problems

    If you face with the following problems, you can fix them referring under articles ; Status check follow instruction 1. DAH 900 will not download digital files from the PC. No Mp3 file Play download a music file did you check a music file - Check the cable connection to the USB port.

  • Page 32: Warranty Service

    5. Installing the USB Driver manually - If a USB driver to control DAH 900 already exists in PC, there is no need to install a new driver. 3. Damage to or deformation of the outer case caused by organic solvents, - Insert installation CD into CD-ROM Drive (Do not execute the installation program.)

  • Page 33: Liability For Damages To The Customers

    Repair at charge Repair at charge CAUSE HARMFUL INTERFERENCE, AND (2) THIS DEVICE MUST ACCEPT ANY persons other than authorized engineers at Hyun Won't agents or service center. INTERFERENCE RECEIVED INCLUDING INTERFERENCE THAT MAY CAUSE NOTE : 1. We are not guarantee Lost of Data in player in case of customer's carelessness.
  • Page 34 MEMO WARRANTY FORM Product Name : Model Name : Date of Purchase: (date) (month) (year) Customer's Name: Phone: Address : Agent's Name : Phone: Address : This Warranty Form with the date of purchase must be presented for warranty service. Please keep this warranty form well. 1.
