Hyun Won DAH-1500 Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Page 1
DAH-1500
User's Manual
Sharp-cut organic EL LCD/ 6-mode & user-set EQ/ unlimited folders and file-navigation system/
easy & convenient clock system/ removable disk/ FM radio and recoding/ built-in Li-ion battery/
resume function in second/ easy firmware upgrade
Page 2/3
View Index
Safety
Precautions/
Designations/ Buttons/ LCD/ Recharge/ Power/ Connection with PC/ Disconnection
Navigation/ Hold/ Clock/ Auto Power-off
Listening to FM Radio/ Tuning in Radio Frequency/ Saving FM Frequencies/ Preset Mode/
Deleting Frequencies/ Recording FM Radio
Menu List/ Menu Buttons/ Mode Change/ Music Set/ Screen Set/ Other Sets
This is not a trouble!
Customer Support & After-sales Service
Indemnification
Page 5
Special
Features/
Page 23
Page 27
Page 33
Page 43
Page 57
Page 65
Technical
Specifications/
Accessories/
Parts

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DAH-1500 and is the answer not in the manual?

Questions and answers

Related Manuals for Hyun Won DAH-1500

Summary of Contents for Hyun Won DAH-1500

  • Page 1: Table Of Contents

    Page 1 DAH-1500 User’s Manual Sharp-cut organic EL LCD/ 6-mode & user-set EQ/ unlimited folders and file-navigation system/ easy & convenient clock system/ removable disk/ FM radio and recoding/ built-in Li-ion battery/ resume function in second/ easy firmware upgrade Page 2/3...

  • Page 2: Before Starting

    Warranty Card Page 4/5 1. Before Starting Safety Precautions Special Features Technical Specifications Accessories Parts Designations Buttons Recharge Power Connection with PC Disconnection Page 6/7 Safety Precautions Avoid humidity or dusty area Don’t disassemble or modify the product. Don’t put the product close to any heating device or under direct sunlight Avoid the product from dropping or excessive shock Never use any chemical or cleanser.
  • Page 3 Page 8/9 Safety Precautions Safety matters for AC adaptor Don’t open the case of AC adaptor to avoid electric shock. Please be fully aware of this user’s manual to avoid any unexpected trouble. Warning! Prevent the AC adaptor from contacting water to avoid fire or electric shock. Use enclosed adaptor in the package only to ensure the safety.
  • Page 4 between black background and blue texts. This organic EL LCD provides you very sharp-cut color, comfortable-to-eye display and elegant high-end screen quality. 6 Mode & User-set EQ According to music genres it provides 6 selectable modes; Normal/ Rock/ Jazz/ Classic/ X-Live to satisfy your taste as well as user-set mode which enables you set the tone as per your own preference.
  • Page 5 S/N Ratio 50dB Antenna Headset/earphone code antenna Audio Frequency Characteristics 20Hz ~ 20KHz Headset Output Max. 7.5mW(16Ω) Max Volume S/N ratio 90dB Supporting Files File format MP3, WMA Bit rate MP3: 8~320Kbps WMA: 32~192Kbps Download speed 6Mbps (USB Ver 1.1) Recording period radio 1040...
  • Page 6 Bottom Reset button Lateral sides Necklace link pin Power/ Play/ Pause FF/ REW/ VOL+/- Necklace link pin MENU/Navigation Hold/ Clock button Page 16-17 Buttons Power ON/OFF File Play/ Pause Move to Submenu/ Menu Set-value Save Searching Previous/Next File Move to Left/Right Menu Move to Navigation sub/preceding Folder Volume Up/Down Move to Upper/lower Menu...
  • Page 7 B: Displays file status (Play/ Pause/ Stop) C: Displays play mode D: Displays hold E: Displays battery status F: Displays file title G: Displays file elapsing time H: Displays current file No./ total file number I: Displays EQ J: Displays volume FM Mode A: Receiving sensitivity (Antenna) B: Displays search/ preset mode...
  • Page 8 1) 15 hours in below conditions; MP3: 128Kbps, 44.1Khz Vol 15 Power Volume not in use Recharge the battery in following cases; 1) “Low Battery” appears on LCD 2) Button is not functioning correctly 3) LCD is not activated by pushing the power button. Page 20-21 Connection with PC Note!

  • Page 9: Basic Operations

    Open “My Computer” or “Windows Search” and choose “Removable Disk.” Choose “Remove” using the right button of mouse and then remove the USB cable. Note! Removing the cable without following above instruction will display a warning message and may cause a fatal error in PC or the product. Removing the cable while downloading or uploading files, or formatting the product may cause a fatal error in PC or the product.

  • Page 10: Convenient Functions

    At “Stop” or “Pause”; Press (picture) to play the file Stop In playing; Press (picture) to stop the file Volume control Press (picture) shortly to increase or decrease the volume by steps. Press (picture) for longer seconds to increase or decrease the volume continuously. Page 26-27 Playing Music File Selection...
  • Page 11 Note! Push to REW direction to move to upper-leveled folder Press (picture) to get out of the Navigation mode. (picture) Folder icon (picture) File icon Hold Holding Functions Press (picture) once for longer seconds to hold the functions. Press the button once again to release it.
  • Page 12 이상 1500설명서 1...
  • Page 13 Page 32-33 4 FM Radio Listening to FM Radio Tuning in Radio Frequency35 Saving Frequencies Preset Mode Deleting Frequencies Recording FM Radio Page 34-35 Listening to FM Radio 누름(Press) 탐색(Search) – Entering FM mode you can listen to the radio! Note! Earphone also performs antenna function.
  • Page 14 Auto Channel Save 주파수프?? 주파수자?? Note! Press (picture) in auto frequency search to halt the process. Preset Stop Level When searching frequencies by pressing the button to FF/REW direction the frequency stop points are variable according to preset stop levels (4 to 12) 프리셋정? Note! When the level is set close to 4 higher stop frequency is expected.
  • Page 15 Press (picture) for longer seconds to get out of Delete mode Page 40-41 Recording FM Radio Recording FM sound source In FM receiving status 길게누름: Press for seconds 녹음시작: Recording Start 녹음정지: Recording Stop Note! Recorded sound source is saved in MP3 format in FM folder with following sequence; F00001.MP3, F00002.MP3…..
  • Page 16 Other Sets Page 44-45 Menu List Menus available in the product are as follows; Menu Music Play FM Radio Music Set Equalizer Normal Rock Jazz Classic X-Live User Set User EQ Base Treble Play Sequence Repeat all files Repeat files in the folder Random play for all files Random play in the folder Power Volume...

  • Page 17: Fm Radio

    Auto Power Off Sleep mode Initialization Main menu: There are all five main menus in the program. Sub menu: Set menu: There are sub menus under each main menu. 화면설정: Screen set Backlight/ 밝기설정: Brightness Set/ Language Page 46-47 Menu Buttons Basic uses of menu buttons 1.
  • Page 18 Music Set Choose “Music Set” from the main menu. Equalizer This function enables you to listen to various types of sound tones according to settings (Normal, Rock, Jazz, Pop, Classic, Live, User Set) Music Set Equalizer File Play Normal Rock Jazz 사용자이? User Set EQ You can enjoy your own tones by adjusting the base (0-30) and treble (0-30).
  • Page 19 Page 50-51 Music Set Play Sequence This function sets the file play modes (Repeat all files, Repeat files in the folder, Random play in sequence, Random play in the folder). Music Set Equalizer File Play All Files Files 사용자이 folder All files Repeat all files: all music files are repeatedly played in sequence.
  • Page 20 Choose “Screen Set’ from the main menu Backlighting period It enables you set backlighting periods of LCD among 5, 15, 30 seconds and always ON. Screen Set Backlight Brightness Set Language Backlighting Brightness Set This function let you set the brightness of LCD from 1 to 10 levels. Screen Set Backlight Brightness Set Language Brightness...

  • Page 21: Program

    It enables you set time, day, date, month and year. Other Sets Firmware Time Set Auto Power Band Move Level Set Note! Press (picture) to view set time in Play and FM Radio modes. Auto Power OFF The function turns off the power automatically when there has been no button manipulation for set period (30 seconds/ 1minute/ 2minutes/ 5minutes/ 10minutes or disabled) in Pause or Stop.
  • Page 22 (Additional hard disk may be needed for saving music files) USB port available Mac. 9.X-X Installing Program CD Note! This Mass Storage type product can upload or download files without installing extra software. In case of using Windows 98SE: Please install the program CD supplied with the product before upload or download files.

  • Page 23: Support

    Page 62-63 Format Note! Removed files can not be recovered after formatting the device! 1. Choose “format” using right mouse button on removable disk folder in PC Windows. 2. Click on Start button when format window pops up. Check if file system is set for FAT32 Be very careful at format! 3.
  • Page 24 Check the earphone. It functions as an antenna. Use the product away from peripheral electric devices. Page 68-69 This is not a trouble! Followings may not be troubles, please carefully examine symptoms. 5. Trouble with file downloading? Check USB cable connection. Check the available memory capacity.
  • Page 25 E. Mail to Mail If you ask for Peer to Peer service we will promptly reply to your email. Please inform us of the correct model name of your device with as much trouble details as possible. F. Using Board You may also use board for your queries.
  • Page 26 Defects or Damages Warranty Detail Within Warranty After the Period Expiration Functional or When it is required to repair within Replacement or Repair at cost performance error 10 days from the purchase full refund under normal When it is required to repair major Replacement operating components within 1 month from...
  • Page 27 Hyunwon is not responsible for the loss of data caused by careless use of the product. Items not specified above shall follow the Customer Protection regulations. Warranty Card Warranty Term: 1 year from the date of purchase Product Name: Model: Date of Purchase: m-d-y Name of Customer:...
  • Page 28 FCC Compliance Statements NOTE : This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
