INSTALLER:
Leave this manual with the appliance.
CONSUMER:
Retain this manual for future reference.
WARNINGS
If the information in this manual is not followed exactly,
a fire or explosion may result causing property damage,
personal injury or loss of life.
Do not store or use gasoline or other flammable vapors
and liquids in the vicinity of this or any other appliance.
WHAT TO DO IF YOU SMELL GAS
Do not try to light any appliance.
Do not touch any electrical switch; do not use any phone
in your building.
Immediately call your gas supplier from neighbor's
phone. Follow the gas supplier's instructions.
If you cannot reach your gas supplier, call the fire de-
partment.
Installation and service must be performed by a qualified
installer, service agency or the gas supplier.
INSTALLATION INSTRUCTIONS
AND OWNER'S MANUAL
BLUE BAY
LOG SET MODELS
LS38DF-1
LS48DF-1
Log sets comply with ANSI Z21.11.2 Unvented Heaters and
also comply with ANSI Z21.60 Decorative Vented Appliances
for Solid Fuel Burning Fireplaces. State or local codes may
only allow operation of log sets in a vented configuration.
Check your state or local codes.
WARNING: If not installed, operated and maintained in ac-
cordance with the manufacturer's instructions, this product
could expose you to substances in fuel or from fuel combus-
tion which can cause death or serious illness.
GAS-FIRED
Page 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LS38DF-1 and is the answer not in the manual?

Questions and answers

Summary of Contents for Empire Comfort Systems LS38DF-1

  • Page 1 INSTALLATION INSTRUCTIONS EMPIRE EMPIRE AND OWNER'S MANUAL Comfort Systems BLUE BAY LOG SET MODELS LS38DF-1 LS48DF-1 GAS-FIRED INSTALLER: Leave this manual with the appliance. CONSUMER: Retain this manual for future reference. WARNINGS If the information in this manual is not followed exactly, a fire or explosion may result causing property damage, personal injury or loss of life.
  • Page 2: Important Installation Guidelines

    IMPORTANT INSTALLATION GUIDELINES Proper Log Placement Ceiling Fans, Portable Fans or Logs Installed Near Cold Air Log placement is critical to proper burner performance. Logs must Returns be correctly positioned onto the burner. The photos in this manual Ceiling fans or oscillating floor type fans need to be monitored show the proper pinned position for logs on this set.
  • Page 3: Log Identification

    LOG IDENTIFICATION PART NUMBER DESCRIPTION LOG IMAGE LS38DF LS48DF REAR LOG 30901 32823 RIGHT FRONT LOG 30904 30904 LEFT FRONT LOG 30902 32824 LEFT BRANCH 30903 30903 32819-0-0913 Page 3...
  • Page 4 Before you begin: Do not handle these logs with your bare hands! Always wear gloves to prevent skin irritation. After handling logs, wash your hands gently with soap and water. All Logs Properly positioning the logs is critical to the safe and clean operation of this heater.
  • Page 5 INSTALLATION Install locator plate over the burner cover assembly. Remove glass front from fireplace by lifting the glass front up, sliding it to the right, and then carefully angling left side out of the slots. See Figures 1 - 4. Figure 1 NOTE: TOP OF FIREBOX REMOVED FOR CLARITY.
  • Page 6: Rear Log

    Place Rear Log onto the rear two pins on the locator plate. TOP VIEW FRONT VIEW Page 6 32819-0-0913...
  • Page 7: Right Front Log

    Place Right Front Log onto the two front right pins on the locator plate. TOP VIEW FRONT VIEW 32819-0-0913 Page 7...
  • Page 8: Left Front Log

    Place Left Front Log onto the middle left front pin on the locator plate. The left end of the log should angle up and will rest against the glass. TOP VIEW FRONT VIEW Page 8 32819-0-0913...
  • Page 9: Left Branch

    Place the Left Branch on the left pin on the locator plate and the pin on the Left Front Log. TOP VIEW FRONT VIEW 32819-0-0913 Page 9...
  • Page 10 Replace the glass front into the fireplace by placing the right side into the slots in the firebox. Carefully angle in the left side of the glass and then slide the glass to the left. Settle the glass into the slots by gently lowering it. TOP VIEW Figure 6 Figure 8...
  • Page 11: Appliance Service History

    APPLIANCE SERVICE HISTORY Date Dealer Name Service Technician Name Service Performed/Notes 32819-0-0913 Page 11...
  • Page 12 Empire Comfort Systems Inc. EMPIRE EMPIRE 918 Freeburg Ave. Belleville, IL 62220 If you have a general question about our products, please e-mail us at info@empirecomfort.com. If you have a service or repair question, please contact your dealer. Comfort Systems www.empirecomfort.com...
