CONTROLS AND FUNCTIONS
11. CHANNEL EQUALIZER – All of the channels include a two-band signal EQ. These controls are used to
increase or decrease the LOW and HIGH of the output signal. (only available when MIXER OUTPUT is ON)
HIGH frequency control
This knob is used to adjust the high levels of a channel allowing for a maximum high gain of 10dB or maximum
decrease of –26dB. Turning the knob in a counterclockwise direction will decrease the amount of high
applied to a channel signal, turning the knob in a clockwise direction will increase the amount of high applied
to a channel signal.
LOW frequency control
This knob is used to adjust the low levels of a channel allowing for a maximum bass gain of 10dB or maximum
decrease of –26dB. Turning the knob in a counter- clockwise direction will decrease the amount of low
applied to a channel signal, turning the knob in a clockwise direction will increase the amount of low applied
to a channel signal.
12. IN BUTTON – This function allows you to set a CUE POINT without music interruption ("on the fly"). This
button also sets the starting point of a seamless loop.
13. OUT BUTTON – This button is used to set the ending point of a loop. A loop is started by pressing the IN
BUTTON. Pressing the OUT BUTTON set the loop ending point. The loop will continue to play until the
OUT BUTTON is pressed once again.
14. HEADPHONE JACK – This jack is used to connect your headphones to the mixer allowing you to monitor
the cue source. Always be sure the CUE LEVEL VOLUME is set to minimum before you put the
headphones on.
15. CUE PAN CONTROL – This function allows you to select which player to be monitored in your
headphones. When you turn the CUE PAN to the full left position, you will only hear the signal from Player
1; on the contrary you will only hear the signal from Player 2. If the CUE PAN KNOB is set to the center
position, you can cue both players.
16. CUE VOL CONTROL – This knob is used to adjust the headphone volume output level. Turn the knob in a
clockwise direction to increase the headphone volume.
17. PITCH ON/OFF BUTTON –This button has two functions as below:
This button is used to turn the PITCH SLIDER function on and off. The pitch percentage can be changed
between 4%, 8%, and 16%. 4% will allow the least amount of pitch manipulation and 16% will allow the
most amount of pitch manipulation.
Press and hold this button for more than 2 seconds to switch the TEMPO LOCK function on/off.
18. PITCH RANGE SELECTOR – Press this button to choose any pitch range percentages of 4%, 8%, and 16%.
19. TRACK KNOB – This knob is used to scroll backward and forward through tracks. Pushing this knob and
turning it at the same time will let you scroll forward or backward 10 tracks per "click" of the knob. Also,
when you press the knob it will toggle between artist, bitrate, title name, genre, and file name of the current
song playing showing on the player display.
20. FOLDER KNOB – This knob serves 2 functions depending on which mode you are working in.
(1) Press the FOLDER KNOB will show folder name of the current song playing on the display of the Player.
(2) Turning the knob will scroll through the folders found on a memory device.
21. BPM/TAP BUTTON – This button is used to override and manually set a track BPM. Occasionally the
built-in BPM meter may not function as desired. This button allows you to override the internal beat clock
and manually set a track BPMs. To manually set the BPMs; tap this button a few times to a tracks heavy
down beat, the unit will automatically calculate your tapping and translate it into a tracks BPMs. The BPM
READOUT is then displayed in the LCD. To return to the automatic BPM counter, press and hold down the
TAP BUTTON for at least 2 seconds and then release.
22. SEARCH BUTTON – This button has two functions:
SEARCH function: Press this button to toggle between fast search (LED lit) and slow search
(LED off). The fast search will automatically turn off if the jog Wheel is not used for more then 10
seconds.
SEARCH mode on – When the SEARCH function is activated you can use the jog Wheel to search
fast backward or forward through the current track whether in play mode or not.
SEARCH mode off – When the SEARCH function is not activated, you can use the jog Wheel to search
frame by frame or a slow search in pause mode and you can use the JOG WHEEL act as a PITCH BEND in
play mode.
Enter the SETUP MENU: Press the SEARCH button for more than 2 seconds to enter system setting mode.
4
TOP PANEL
