  • Page 1 Dual SD Card and USB MP3 Player with built-in Mixer USER MANUAL...

  • Page 2: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS 1. Read these instructions. 2. Keep these instructions. 3. Heed all warnings. 4. Follow all instructions. 5. Do not use the apparatus near water. 6. Clean only with dry cloth. 7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. 8.

  • Page 3: Top Panel Controls And Functions

    MAIN FEATURES Auto cue Auto BPM Pitch display 100% Anti-shock Real time cue Built-in audio mixer Fast Track Search Music Master tempo SD & SDHC cards available Mp3 Track Listings, ID3 Tags 1/75th second frame search Jog Wheel Pitch Bend +/-100% Big LCD Display with Backlight USB mass storage device supported Folder Search, Multi-Cue Function...
  • Page 4 CONTROLS AND FUNCTIONS TOP PANEL 1. SOURCE SELECT BUTTON – This button lets you toggle between USB Port and SD Card slots. This lets you choose which music source device to play on either side. The LEDs will show which source is activated.
  • Page 5 CONTROLS AND FUNCTIONS TOP PANEL 11. CHANNEL EQUALIZER – All of the channels include a two-band signal EQ. These controls are used to increase or decrease the LOW and HIGH of the output signal. (only available when MIXER OUTPUT is ON) HIGH frequency control This knob is used to adjust the high levels of a channel allowing for a maximum high gain of 10dB or maximum decrease of –26dB.

  • Page 6: Rear Panel

    CONTROLS AND FUNCTIONS TOP PANEL 23. RELOOP BUTTON – If a SEAMLESS LOOP has been made, but the Player is not actively in SEAMLESS LOOP mode (a loop is not playing), pressing the RELOOP BUTTON will instantly reactivate the SEAMLESS LOOP mode. To exit loop, press the OUT BUTTON. LOOP and RELOOP will appear in the LCD DISPLAY when the RELOOP function is available.

  • Page 7: Lcd Display

    CONTROLS AND FUNCTIONS LCD DISPLAY 1. CUE INDICATOR – This indicator will glow when the device is in CUE mode and will flash every time a new CUE POINT is set. 2. FOLDER INDICATOR – Indicates the number of the currently playing folder. 3.

  • Page 8: Basic Operation

    BASIC OPERATION SOURCE SELECT functions MUSIC SOURCE DEVICE SELECT There is a SOURCE SELECT BUTTON to select the music source playback in each PLAYER by your desires. You have three different choices as below: (a) THE SAME CARD PLAYBACK To play the same card in both player 1 and player 2; insert the card into either SDA or SD B slot.
  • Page 9 BASIC OPERATION FOLDER KNOB serves 2 functions depending on which mode you are working in 1. The LCD will display the playing folder name whenever you press the FOLDER knob. 2. You can also search the folders in music source device by turning the FOLDER knob. The playing folder name will display in the LCD Turning the FOLDER knob you can search the whenever you press the FOLDER knob.

  • Page 10: Frame Search

    BASIC OPERATION FRAME SEARCH This feature allows you to scroll through a track frame by frame, allowing you to find and set a starting cue or loop point. To use the scroll function you must first be in Pause Mode or Cue Mode. Once you are in Pause or Cue mode, turn the JOG WHEEL to scroll through the track.
  • Page 11 BASIC OPERATION SEAMLESS LOOP 1. CREATING AND PLAYING A SEAMLESS LOOP A seamless loop is a sound loop that plays continuously without sound interruption. You can use this loop to create dramatic effect in your mixing. This loop has no time limit and you could actually loop the entire length of the current folder.

  • Page 12: Editing A Loop

    BASIC OPERATION 4. EDITING A LOOP You can edit your seamless loop you obviously must first have created a seamless loop to edit. If you haven’t created a SEAMLESS LOOP, follow the instructions in step 1 to create a loop. There are three methods as below: (1) Edit a seamless loop’s ending point You can edit the end point of the loop to make your loop shorter or...

  • Page 13: Storing A Cue Point

    BASIC OPERATION STORING A CUE POINT: Once you have set your CUE Point, you may store your cue point in one of the CUE BANK BUTTONS. Either a CUE POINT or a Loop can be stored into a CUE BANK BUTTONS. (1) Press the MEMORY BUTTON as right Figure.

  • Page 14: Tempo Lock

    BASIC OPERATION STUTTER EFFECT When a loop is playing you can press RELOOP button to restart the loop at once. You can also press this button when a track is not playing in loop. Every time the RELOOP button is pressed, it will restart the pre-programmed loop.

  • Page 15: System Setting

    SYSTEM SETTING SETUP MODE Press the SEARCH button for more than 2 seconds to enter system setting mode. At this time, LCD display “PRESET” and the SETUP LED will lit. Note: System setting will be closed automatically when there is no user input more than 10 seconds.
  • Page 16 SYSTEM SETTING Once enter the SETUP mode you can browse the items by turning FOLDER knob, and pressing FOLDER knob to on or off item selection, see more details of the different submenus and options as below: TIME MODE: You can select different time display by pressing the FOLDER knob to switch between elapsed and remaining.

  • Page 17: Firmware Version

    SYSTEM SETTING FIRMWARE VERSION You may display the unit firmware version Firmware is the unit internal programming code. Once enter setup mode and then turn the FOLDER KNOB until Vxx.xx is displayed. “x’s” are the version number. FIRMWARE upgrade: Step1: Copy the controller code or DSP code from PC and then save into memory device (Files must be in root directory).

  • Page 18: Specification

    SPECIFICATION MODEL: U1 Station ,Dual SD Card and USB MP3 Player with built-in Mixer (compatible with USB mass storage device 1.0/1.1/2.0) DIMENSIONS: 482 (W) x 132 (H) x 79.2 (D) mm POWER SOURCE: DC 6V, 2A WEIGHT: 2.5kg GENERAL: Display Pitch control range Within +/-4%, +/-8%, +/-16% Pitch accuracy...
  • Page 19 SPECIFICATION MP3 FORMAT SD/USB Format File system FAT12/16/32 Applicable file extensions mp3. MP3. mP3. Mp3 Max. number of Folders Max. number of files max. 999 files MP3 Format MPEG 1 Layer 3 standard (ISO/IEC 11172-3), 32/40/48/56/80/96/112/128/160/192/224/256/3 which provides for single channel (‘mono’) and 20 kbps two-channel (‘stereo’) coding at sampling rates of Xing/VBRI VBR...
