DECORATIVE OPEN GAS FIRE
Installation, Servicing and Operation Manual
INSTALLER: These instructions must be left with the owner.
SIENNA
Models:
KGF260-002
KGF260-005
KGF260-003
KGF260-006
KGF260-004
KGF260-007
.
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the SIENNA KGF260-002 and is the answer not in the manual?

Questions and answers

Summary of Contents for KENT SIENNA KGF260-002

  • Page 1 SIENNA DECORATIVE OPEN GAS FIRE Models: KGF260-002 KGF260-005 KGF260-003 KGF260-006 KGF260-004 KGF260-007 Installation, Servicing and Operation Manual INSTALLER: These instructions must be left with the owner.
  • Page 2 Caution: FOR YOUR SAFETY This Decorative Open Gas Fire is designed and approved for insertion into an existing masonry fireplace and chimney, wall cavity or false chimney provided that the installation procedures in these instructions are followed precisely. Failure to follow the installation instructions correctly may lead to over-temperature conditions arising which may lead to damage and or loss to house and property.
  • Page 3: Specifications

    SPECIFICATIONS Model Gas Type Burner Pressure Gas Consumption KGF260-002 1.00 kPa 30.5 MJ/h KGF260-003 2.00 kPa 30.5 MJ/h KGF260-004 1.00 kPa 35 MJ/h KGF260-005 2.00 kPa 35 MJ/h KGF260-006 0.80 kPa 40 MJ/h KGF260-007 2.00 kPa 40 MJ/h * Note that this drawing and dimensions do not include the fascia trim.
  • Page 4: Installation

    INSTALLATION NOTE THAT GAS CONNECTION AND FLUEING OF THIS INSERT MUST BE MADE BY AN AUTHORISED PERSON, AND MUST COMPLY WITH THE REQUIREMENTS OF THE GAS ACT AND GAS REGULATIONS, AND THE GAS APPLIANCE INSTALLATION CODE NZS 5261:2003. Installation General Points: The insert must have a 300mm wide non-combustible hearth fitted in front of it.
  • Page 5 Note: The fascia is not shown in these views. The flange on the front of the insert is partially shown in the front view. The 980mm dimension given for the opening is for 900mm model only. Installation into an existing fireplace/chimney: This insert may be installed into an existing masonry fireplace and chimney if it is sound and in good condition, and is large enough for the model selected.
  • Page 6 Gas Connection and Adjustment: Once the gas pipe has been connected, it will be necessary to check the gas circuit for soundness and for correct operating pressure. • The pressure is measured at HIGH rate at the test point on the burner injector fitting, accessed by removing the large front cover panel under the burner.
  • Page 7: Operation

    OPERATION Lighting Procedure: 1. Push in the control knob and turn anti-clockwise to the pilot position. The ignition unit should spark as this is done. Check if the pilot light has ignited. If not, repeat step one. Once the pilot has lit, continue to hold in the control knob for approximately 20 seconds.
  • Page 8 SERVICE SERVICE WORK ON THIS APPLIANCE MUST BE CARRIED OUT BY AN AUTHORISED PERSON ONLY. This fireplace should be serviced annually to ensure continued optimum performance and safe operation. Disconnect the electrical cord from the power supply outlet before servicing the appliance. •...
  • Page 9 Drawing Part No Description FE190-001 Dec Fire inlet gas pipe - 700 FE190-002 Dec Fire inlet gas pipe - 800/900 FE190-005 Dec Fire Maxitrol regulator LPG FE190-006 Dec Fire Maxitrol regulator NG FE190-008 Dec Fire manual control valve FE190-011 Dec Fire pilot gas pipe - mod 700 FE190-012 Dec Fire pilot gas pipe - mod 800/900 FE190-013...
  • Page 10 GUIDE TO DURATION OF WARRANTY 1. Appliances will be free from defects in material and workmanship under normal use and service when installed and used in accordance with all applicable local laws and regulations. 2. If, during the warranty period, a product fails to operate properly due to defects in workmanship or materials, Aber will either, at its option, repair or replace the product without charge to the purchaser.
  • Page 11: Warranty Claim Procedures

    Gas controls, gas burners, ceramic logs 2 year b) Heat exchanger 5 year For full warranty terms & conditions please refer to our website: www.kent.co.nz Distributed by: Aber, P O Box 10095, Te Rapa, Hamilton Ph: 0800 161 161 Fax: 0800 163 163 email: sales@aber.co.nz...
